BEFORE YOU BEGIN

Thank you for selecting the innovative BOOTY FIRM™
lower body developer. The BOOTY FIRM lower body
developer is designed to let you enjoy a variety of fun
and effective exercises that firm, tone, and strengthen
the body.

ASSEMBLY

Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing materials until
assembly is completed.
Assembly requires a Phillips screwdriver
for assembly.
1. Slide the Upright (1) onto the Base (3). Attach
the Upright by tightening the Upright Knob (23)
into the Upright and the Base.
Next, secure the Upright (1) by tightening an M8
x 8mm Screw (31) into the Upright and the Base
(3). Note: If you plan to periodically remove the
Upright for transportation or storage, you may
choose not to attach the Screw.
2. Attach the Handle (5) to the Upright (1) with four
M4 x 15mm Screws (20).
3. Make sure that all parts are properly tight-
ened. Place a mat beneath the Base (3) to
protect the floor.
For your benefit, read this manual carefully before
you use this product. If you have questions after
reading this manual, please see the front cover of this
manual.
. To avoid damaging parts, do not use power tools
23
4
5
20
20
1
31
3
