Summary of Contents for Holman Aspect Wi-Fi Solar
- Page 1 WS5090W 1 of 12 User Guide...
-
Page 2: Table Of Contents
Cleaning the UV Sensor and Calibration Main Console Firmware Update Precautions Specifications Introduction Thank you for choosing our Aspect Wi-Fi Solar. This system gathers and automatically uploads accurate and Weather Underground, which detailed weather data to allows weather observers to upload their local weather data. -
Page 3: Overview
Overview Main Console 1. Wi-Fi/SENSOR 2. REFRESH/UPLOAD 3. 6-in-1 Wireless Outdoor Sensor status LED 4. Wireless Indoor Sensor status LED 5. Status LED 6. RESET 7. USB socket (for firmware update only) 8. Power jack 3 of 12... -
Page 4: 6-In-1 Wireless Outdoor Sensor
Overview (continued) 6-in-1 Wireless Outdoor Sensor 1. Wind vane 2. Wind cups 3. Antenna 4. Louvre shield 5. Pole mount (fit 35~40mm pole, not included) 6. Hygro-Thermo sensor 7. Battery door 8. RESET 9. Transmission status LED 10. Level gradienter 11. -
Page 5: Installation And Setup
Installation and Setup 6-in-1 Wireless Outdoor Sensor The 6-in-1 Wireless Outdoor Sensor Mounting guideline: measures Wind-Speed, Wind-Direction, Rainfall, UV Index, Temperature and Humidity. Pairing the 6-in-1 Wireless Outdoor Sensor MOUNTING POLE AND STAND MIN 1.5m NOT INCLUDED 1. Install the 6-in-1 Wireless Outdoor Sensor with the Main Console: at least 1.5m off the ground for better and more accurate wind measurements. -
Page 6: Main Console
The Main Console can back up the router and weather server settings. The wireless sensor connection status is also stored here. Wi-Fi Connection Setup To connect the Aspect Wi-Fi Solar to Wi-Fi, it Register with Weather Underground: Weather Underground. -
Page 7: Wi-Fi Connection Setup
On the next page, note it is essential to jot down the LONGITUDE/LATITUDE for your reference later. 3. After noting the LONGITUDE/LATITUDE, follow the prompts to complete registration of the Aspect Wi-Fi Solar with Weather Underground. After submitting your details, note it is 6. -
Page 8: Barometric Pressure Setup
Installation and Setup (continued) Barometric Pressure Setup Set UV Index Gain Barometric Pressure: Or atmospheric pressure, the The UV sensor manufacturer may have included a pressure at any location of the Earth caused by the gain or adjustment for a specific sensor technology or weight of the column of air above it. -
Page 9: Maintenance
Maintenance Cleaning the Rain Collector Main Console Firmware Update 1. Unscrew the rain collector by turning it 30° 1. Unzip the Update.zip file and copy the anti-clockwise. unzipped Update folder to a USB drive. 2. Gently remove the rain collector and clean and ... -
Page 10: Precautions
Maintenance (continued) Precautions Read and keep these instructions. When replacement parts are required, be sure the service technician uses replacement parts Do not subject the unit to excessive specified by the manufacturer that have the force, shock, or dust. same characteristics as the original parts. -
Page 11: Specifications
Specifications Main Console General Outdoor Humidity Dimensions (W×H×D) 79 × 157 × 41mm Measuring range 1 ~ 99% 1 ~ 90% RH ± 2.5% RH @ 25°C (77°F) Weight 130g Accuracy 90 ~ 99% RH ± 3.5% RH @ 25°C (77°F) Main power DC 5V 1A adaptor Resolution... - Page 12 Should you have any questions about this product or its operation please telephone our customer service helpline on 1300 716 188. Head Office/Service 11 Walters Drive, Osborne Park WA 6017 Ph: +61 8 9416 9999 Fax: +61 8 9416 9920 service@holmanindustries.com.au www.holmanindustries.com.au Copyright 2019 Holman Industries...
