- Page 1 ASPECT Wi-Fi Solar Pro WEATHER STATION 1 of 24 User Guide...
-
Page 2: Table Of Contents
Contents Introduction Introduction Your Aspect Wi-Fi Solar Pro gathers and Precautions uploads accurate and detailed weather data to Overview Weather Underground. It offers professional weather Main Console observers or serious weather enthusiasts robust LCD Display performance. You will get your own local forecast, Hygro-Thermo Indoor Sensor high/lows, totals and averages for virtually all weather Solar Pro Outdoor Sensor... -
Page 3: Precautions
ΠEnsure your Main Console is installed near your power outlet and is easily accessible ΠThe contents of this manual may not be reproduced without the permission of Holman Industries ΠTechnical specifications and user manual contents for this product are subject to change without www.holmanindustries.com.au... -
Page 4: Overview
Overview Main Console BARO WIND ALARM / SNOOZE RAIN WI-FI SENSOR REFRESH CLOCK ALARM ALERT RESET OFF LO HI DC 5V 1. BAROMETER 19. ALERT 13. Wall mount 7. chevron- adjust Display brightness adjuster 2. WIND 14. REFRESH 20. OFF/HI/LO slider 8. -
Page 5: Hygro-Thermo Indoor Sensor
Overview (continued) Hygro-Thermo Indoor Sensor 1. Transmission status LED 2. Wall mount 3. Channel slider 4. RESET 917MHz 5. Battery compartment Solar Pro Outdoor Sensor 1. Wind vane 2. Wind cups 3. Antenna 4. Radiation shield 5. Thermo-hygro sensor 6. Mounting parts (to fit 35-40mm diameter pole) 7. -
Page 6: Installation And Setup
Installation and Setup Main Console Console Setup: Built-in Memory: 1. Power up the Main Console by plugging the ΠThe console has built-in flash memory that holds adaptor provided to the power jack at the back the vital settings including time zone, time sync status, Wi-Fi and weather server settings, 2. -
Page 7: Hygro-Thermo Indoor Sensor
Installation and Setup (continued) Hygro-Thermo Indoor Sensor Pairing with the Main Console: Synchronising Additional Indoor Sensors (Optional): 1. Remove the battery door of the sensor Œ The console can support up to seven additional 2. Insert 2 × AA size batteries into the battery Hygro-Thermo Indoor Sensors compartment. -
Page 8: Solar Pro Outdoor Sensor
Installation and Setup (continued) Solar Pro Outdoor Sensor Your outdoor sensor measures wind speed, wind ΠEnsure the battery door screw locked well direction, rainfall, UV index, temperature and humidity. ΠEnsure the transmission status LED is flashing every 12 seconds Southern Hemisphere Setup: The Solar Pro Outdoor Sensor is calibrated Installing the Solar Pro Outdoor Sensor: to point north. -
Page 9: Wi-Fi Connection Setup
Installation and Setup (continued) Wi-Fi Connection Setup Œ Your Main Console can upload weather data to 7. Click NEXT Weather Underground through a Wi-Fi router 8. Fill out the following prompts and click NEXT to Œ To connect your Main Console to Wi-Fi, it must complete registration of your weather station be registered with Weather Underground 9. - Page 10 Installation and Setup (continued) Wi-Fi Connection Setup (continued) Wi-Fi Connection Status: Œ After the dialogue confirms the setup wifi Main Console is in connection with Wi-Fi router process is complete, you can log back in to your home Wi-Fi network wifi Main Console is trying to connect Œ...
- Page 11 Installation and Setup (continued) Wi-Fi Connection Setup (continued) Time Server Connection Status: Calibration: After the Main Console has connected to the Click ADVANCED at the top of the setup interface to internet, it will attempt to connect to the internet time enter the advance setting page.
-
Page 12: Operation And Settings
Operation and Settings Reading your Data in Weather Underground To view your weather station data live in a web browser, visit https://www.wunderground.com/, and enter your STATION ID in the SEARCH LOCATIONS box at the top of the page. Your weather data should be visible on the following screen. -
Page 13: Setting Alarm Time
Operation and Settings (continued) Setting Alarm Time Temperature/Humidity Functions 1. In Normal Mode, press and hold ALARM The temperature and humidity reading are for two seconds until the alarm HOUR digit displayed in the OUT and IN (CH) sections. flashes to enter Alarm Time Setting Mode. Œ... -
Page 14: View Additional Indoor Channels
Operation and Settings (continued) View Additional Indoor Channels Wind Speed and Direction Real time wind The Main Console can pair with an Outdoor Sensor direction indicator and up to seven Indoor Sensors. Wind direction Past wind directions indicator of last 5 minutes Œ... -
Page 15: Weather Forecast
Operation and Settings (continued) Weather Index (continued) Heat Index: The heat index which is determined by the Outdoor Sensor temperature and humidity data when the temperature is between 26°C and 50°C Weather Forecast The built-in barometer continually monitors atmosphere pressure. Since variation in atmospheric pressure greatly affected by weather, it is possible to forecast the weather by measuring the changes in pressure. -
Page 16: Sun Data
Operation and Settings (continued) Rainfall (continued) Rain Rate Level Definition: Œ To reset the total rainfall record, in Normal Mode, press and hold HISTORY for two seconds Œ To ensure correct data, please reset all the rainfall records when installing your Outdoor Sensor to a new location Sun Data Œ... -
Page 17: Past 24 Hours History Data
Operation and Settings (continued) Max/Min Data Record (continued) Past 24 Hours History Data Œ To clear the max/min records, press and The Main Console automatically stores the hold MAX/MIN for two seconds weather data of the past 24 hours. Œ The LCD Display will also show the Œ... -
Page 18: Backlight
Operation and Settings (continued) Weather Alert Setting (continued) 2. Under the current alert reading, press and hold ALERT for two seconds, then the setting and alert reading will flash 3. Press chevron- adjust or chevron- INDEX to adjust the value or press and hold to change rapidly 4. -
Page 19: Maintenance
Maintenance Battery Replacement When low battery indicator battery- is displayed in the OUT or IN section of the LCD Display, indicates that the respective Outdoor or Indoor Sensor battery power is low. Please replace with new batteries. Solar Pro Outdoor Sensor 19 of 24... -
Page 20: Specifications
Specifications Main Console General Barometer Dimensions (W×H×D) 215 × 172 × 29mm Barometer unit hPa, inHg and mmHg 540 ~ 1100hPa (relative setting Weight 639g (with batteries) Measuring range range 930 ~ 1050hPa) Main power DC 5V, 1A adaptor (700 ~ 1100hPa ± 5hPa)/(540 ~ 3 ×... - Page 21 Specifications (continued) Wind Speed and Direction Weather Index Feels like, Wind Chill, Wind speed unit mph, m/s, km/h and knots Weather index mode Heat Index and Dew point Wind speed 0 ~ 112mph, 50m/s, 180km/h, 97knots Feels like display range -65 ~ 50°C display range mph, m/s, km/h and knots Dew point display range...
-
Page 22: Troubleshooting
Troubleshooting Outdoor Sensor connection is intermittent or non-existent Š Ensure the Outdoor Sensor is within the transmission range Š Reset the Outdoor Sensor and resynchronise with the Main Console Indoor Sensor connection is intermittent or non-existent Š Ensure the Indoor Sensor is within the transmission range Š... -
Page 23: Warranty
As well as your statutory rights referred to above and any other rights and remedies you have under any other laws relating to your Holman product, we also provide you with a Holman guarantee. Holman guarantees this product against defects caused by faulty workmanship and materials for 3 years domestic use from the date of purchase. - Page 24 We recommend registering your new product on our website. This will ensure we have a copy of your purchase and activate an extended warranty. Keep up to date to with relevant product information and special offers available through our newsletter. www.holmanindustries.com.au/product-registration/ Thanks again for choosing Holman...
