Attach the battery module
1. Align the battery module to the processor socket to fit
the parts together.
Rechargeable battery modules—
align raised marker on battery
module with back of processing
unit
NUCLEUS 7 SOUND PROCESSOR USER GUIDE
592753_1-06_EN_CP1000_UG_EMEA.indd 9
DRAFT ONLY FOR CLINICAL TESTING
Disposable battery module—
align indents and lock on battery
module with back of processing
unit
2. Twist the battery module
NOTE
If you do not put your processor on your implant, it will turn
off automatically after two minutes, if enabled by your
clinician.
as shown to attach the
parts.
Your processor will turn
on automatically.
