- Page 1 One PCIe x 16 3.0 slot Backplane(412) OSS-412-BP User Manual SKU: OSS-BP-412 www.onestopsystems.com...
-
Page 2: Table Of Contents
Power Up the System ....................................12 Using any Third-party I/O device ................................12 Force Power ON ...................................... 12 Backplane - PWR / FAULT LED ................................13 Contacting Technical Support ............................14 Returning Merchandise to One Stop Systems ........................14 OSS-BP-412 | 2... -
Page 3: Overview
One Stop Systems Overview 1.1 Description The OSS target backplane supports a PCIe Gen3 target cable adapter installed in the OSS target slot and one PCIe x16 expansion card installed in the expansion / downstream slot. The slots are backward compatible and support Gen 1 and Gen 2 target adapters and expansion cards. Only target adapters with the OSS target slot configuration are supported. -
Page 4: Specifications
One Stop Systems 1.3 Specifications OSS-BP-412 1 PCIe x16 Gen 3 Target Slot backplane 412 (SKU : Dimension (H x L) 2.385” x 6.3” Power 12 VDC. Max:84 Watts, plus 84 watts with power extension 1 OSS target slot (Upstream Port) for target cable adapter only. -
Page 5: Component Identification
One Stop Systems 2 Component Identification 2.1 2slot Backplane The 2-Slot backplane can be installed in a separate enclosure to support the target adapter and I/O card Connector Pin-Outs OSS-BP-412 | 5... -
Page 6: Cable Adapter Cards
One Stop Systems 2.2 Cable Adapter Cards Use any compatible OSS cable adapter cards. Always use a pair of cable adapter cards, one as host and the other as target, when connecting the backplane to host computer. Below photos are few example cable adapter cards you can use. -
Page 7: Host Adapter Card
One Stop Systems 2.2.4 Host Adapter Card The Host card can only be installed in the computer motherboard of a host computer. 2.2.5 Target cable adapter card The target adapter card inserts into the designated target slot (Upstream slot) on the OSS expansion backplane. Do not plug in the target card in the “Downstream slot”... -
Page 8: Installation Instructions
One Stop Systems 3 Installation Instructions 3.1 Install Host Card Insert the host cable adapter into an appropriate PCIe slot of the host computer. For example, a PCIe x4 host board can be inserted into a PCIe x16, x8, or x4 slot. It will still operate at x4 speeds. If you are using a x16 Gen3 cable adapter, use a x16 PCIe slot on the computer’s motherboard. -
Page 9: Plug In Add-In Card / 3 Rd Party Pcie Card
One Stop Systems NOTE: Do not use the Endpoint slot (Expansion slot / Downstream slot) for the “Target Cable Adapter card”. 3.3 Plug in Add-in Card / 3 Party PCIe card Plug in the add-in card or PCIe card in the available IO slot (Endpoint slot: also known as expansion slot and / or downstream slot), see photos below. -
Page 10: Connect Power
One Stop Systems 3.4 Connect Power Connect +12v 4-PIN Aux power cable from your ATX power supply to either J3, J5 or both J3 and J5, see photos below. If your ATX power supply does not have a separate +12V 4-pin connector, you can buy a P4-to-ATX Power Supply adapter, see photo below. -
Page 11: Connect Link Cable
One Stop Systems 3.5 Connect Link Cable Connect the link cable between Target and Host cards. You can also use a x8 or x16 iPass or PCIe 3.0 cable, depending on the cable adapter cards you are using. 3.5.1 Connecting x4 Ipass Cable 3.5.2... -
Page 12: Connecting Pcie 3.0 Cables
One Stop Systems 3.5.3 Connecting PCIe 3.0 Cables For more detail on how to properly connect the PCIe 3.0 cables, please read the manual for the HIB68x16 card. 3.6 Power Up the System Connect external power brick to the 2-slot backplane. The board LED will turn ON (as solid red). The board is at standby-mode. -
Page 13: Backplane - Pwr / Fault Led
One Stop Systems 3.9 Backplane - PWR / FAULT LED MODE LED Indicator / Description Standby Controller is in the OFF condition, but it is not clear what the LED signal state is in the OFF condition. Since the LED is powered by 12V input power (not controlled by PS_ON), the LED may shine in this state. -
Page 14: Contacting Technical Support
However, if you return a product to One Stop Systems for warranty repair/ replacement or take advantage of the 30-day money back guarantee, you will need to package the product in a manner similar to the manner in which it was received from our plant. One Stop Systems cannot be responsible for any physical damage to the product or component pieces of the product (such as the host or expansion interfaces for the PCIe expansion chassis) that are damaged due to inadequate packing. - Page 15 One Stop Systems OSS-BP-412 | 15...
