INSTALLER INSTRUCTIONS
CONTENTS
1
DESCRIPTION OF THE BOILER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag.
2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag.
3
CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag.
4
USE AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag.
When carrying out commissioning of the boiler, you are highly recommended to perform the following checks:
- Make sure that there are no liquids or inflammable materials in the immediate vicinity of the boiler.
- Make sure that the electrical connections have been made correctly and that the earth wire is connected to a
good earthing system.
- Open the gas tap and check the soundness of the connections, including that of the burner.
- Make sure that the boiler is set for operation for the type of gas supplied.
- Check that the flue pipe for the outlet of the products of the combustion is unobstructed and has been properly
installed.
- Make sure that any shutoff valves are open.
- Make sure that the system is charged with water and is thoroughly vented.
- Check that the circulating pump is not locked (CAUTION: Remember to release the pump coupled with the control
panel, if necessary, to protect the electronic control card).
- Purge the system, bleeding off the air present in the gas pipe by operating the pressure relief valve on the gas
valve inlet.
- Check that the syphened drip is fully filled with water. If necessary, fill it via the special opening.
FONDERIE SIME S.p.A. of Via Garbo 27 - Legnago (VR) - Italy declares that its hot water boilers, which bear the CE
mark under Gas Directive 90/396/CEE and are fitted with a safety thermostat calibrated to a maximum of 110°C,
are not subject to application of PED Directive 97/23/CEE as they meet the requirements of article 1 paragraph
3.6 of the Directive.
IMPORTANT
94
98
108
111

Advertisement

loading
Need help?

Need help?

Do you have a question about the DEWY Series and is the answer not in the manual?

Questions and answers

Related Manuals for Sime DEWY Series

Summary of Contents for Sime DEWY Series

  • Page 1 – Check that the syphened drip is fully filled with water. If necessary, fill it via the special opening. FONDERIE SIME S.p.A. of Via Garbo 27 - Legnago (VR) - Italy declares that its hot water boilers, which bear the CE mark under Gas Directive 90/396/CEE and are fitted with a safety thermostat calibrated to a maximum of 110°C,...

  • Page 2: Description Of The Boiler

    DESCRIPTION OF THE BOILER 1. 1 INTRODUCTION management. They comply with the euro- These appliances can be fired by natural pean directives 90/396/CEE, gas (methane) and propane gas (G31). “DEWY” boilers are premix condensation 89/336/CEE, 73/23/CEE, 92/42/CEE The instructions given in this manual are thermal appliances which use microproces- and with the european specifications EN provided to ensure proper installation and...
  • Page 3 TECHNICAL FEATURES DEWY 30/80 DEWY 30/130 Heat output Nominal (80-60°C) kW (kcal/h) 29,3 (25.200) 29,3 (25.200) Minimum (80-60°C) kW (kcal/h) 10,4 (9.000) 10,4 (9.000) Nominal (50-30°C) kW (kcal/h) 32,0 (27.600) 32,0 (27.600) Minimum (50-30°C) kW (kcal/h) 11,4 (9.800) 11,4 (9.800) Nominal D.H.W.
  • Page 4 FUNCTIONAL DIAGRAM 1.4. 1 “30/80” model 1 Fan 16 Automatic by-pass 2 Water-gas exchanger 21 Gas cock 3 Breather valve 24 Limit stat 4 Gas valve 25 Condensation water trap 7 C.H. sensor (SM) 26 Gas rate adjuster 8 100°C safety stat 27 Motor-operated diverter valve 9 Air relief valve 28 Storage tank 80 liter...
  • Page 5 MAIN COMPONENTS 1.5. 1 “30/80” model 15 Ignition transformer 1 Gas cock 16 Negative pressure take-off 2 Manual filling 17 Flowmeter 3 Motor-operated diverter valve 18 C.H. sensor (SM) 4 Gas valve 19 Automatic breather 5 Gas rate adjuster 20 100°C safety stat 6 Condensation water trap 21 Circulating pump 7 Gas pressure take-off...

  • Page 6: Installation

    1.5.2 “30/130” model LOW TEMPERATURE KIT CONFIGURATION PUMP KIT 2/3 ZONE CONFIGURAZIONE CONFIGURAZIONE CONFIGURATION KIT POMPA 2/3 ZONA KIT BASSA TEMPERATURA LEGEND 23 Heating system safety valve 1 130 litre hot water tank 24 Water pressure transducer 2 Hot water tank drain cock 25 Single-acting valve 3 Hot water tank expansion tank 26 Manual recirculation kit bleed (optional)
  • Page 7 connected to a civil drain through a pipe with a slope of at least 5 mm per metre to 1a-b Coaxial duct kit code 8096250 ensure drainage of condensation water. Extension L. 1000 code 8096150 Extension L. 500 code 8096151 The plastic pipes normally used for civil Vertical extension L.
  • Page 8 2.5.3 Coaxial duct outlet on the roof The accessories to be used for this type of installation and some of the connecting systems that may be adopted are illustra- ted in fig. 7. It is possible to insert up to a maximum of three extensions and reach a maximum rectilinear distance of 3.7 meter.
  • Page 9 2.6.2 Connection with existing flues ned off at the foot of the pipe. obtain a concentric discharge by using the The usable height of the water trap must doubler fitting (9 fig. 12). The ø 80 flue gas pipe may be connected to be at least 150 mm.
  • Page 10 CR (6-7). Should this require replacement, it must be recommended for better room temperatu- purchased exclusively from SIME. The elec- re control, must be class II as specified by WARNING: External voltage must not be tric power supply to the boiler must be standard EN 60730.
  • Page 11 Control panel “Logica Remote Control” socket Conector (J2) TA Room stat (not supplied) CR Logica Remote Control (optional) SE External temperature sensor (optional) SB D.H.W. sensor Fig. 13 2.8.4 Wiring diagram “30/80” model Room stat Note: The room stat must (TA) be con- EV1 Gas valve coil SM C.H.
  • Page 12 2.8.5 Wiring diagram “30/130” model SM C.H. sensor (blue) PR Recirculation pump (optional) EV1 Gas valve coil Limit stat EV2 Gas valve coil TRA Ignition transformer Note: The room stat must (TA) be con- Ignition electrode Transformer 230 - 24V nected to the terminals 5-6 Sensing electrode Flowmeter...
  • Page 13 2.8.7 “30/130” wiring diagram with low temperature kit code 8100760 LEGEND P2-P3 Low temperature zone pump Zone control unit Zone 1 room thermostat Relay Low temperature zone room thermostat Zone 1 system pump Low temperature safety thermostat Fig. 14/c LOGICA REMOTE CONTROL vious day.
  • Page 14 HEATING CIRCUIT SETTINGS Antifreeze protection Heating takes place up to this pre-set value if the plant is activated in standby "Pre-set ambient (e.g. holidays). temperature value" In this way, the building antifreeze function is active, preventing an excessive lowering of the ambient. Summer/Winter switch-over This parameter regulates the temperature of the automatic summer/win- temperature...
  • Page 15 DOMESTIC HOT WATER SETTINGS Reduced domestic hot The reduced pre-set value of the temperature of the domestic hot water allow water pre-set value the required water temperature to be obtained outside the programmed usage times (daily programme 8). Domestic hot water load 0 = 24 hours/ day - Hot water is always available at the temperature set with user parameter n°3.

  • Page 16: Characteristics

    2.9.3 Gradient of the characteristic heating curve The gradient of the characteristic heating curve is imposed on the current value “15” of Logica. Increasing the gradient as shown in the drawing of fig. 15, the delivery tempe- rature increases in correspondence to the outside temperature.
  • Page 17 (*) When all 0.5 to 2.5 bar leds are off, check the Flashing red led, fan fault. water pressure transducer connection. 30 minutes after the fan has switched off, the board will attempt a restart Flashing red led, water pressure is too low (*) Flashing red led, Red led on, ignition blocked: communication fault...
  • Page 18 – “Modureg Sel.” connector (14 fig. 17) failures to occur, with consequent activa- “lock-out” lights up. With the bridge disconnected the boiler tion of signal indicating that the control box There could have a break in the wire of is predisposed to function with the SIT has “locked out”.
  • Page 19 3.5. 1 Head with total rate of flow total rate of flow to the other zones (in this Zone 3 = 350 l/h + 400 l/h = 750 l/h. to other zones case zones 2 and 3): 400 l/h + 400 l/h = As shown in the graph at the 800 l/y 800 l/h.

  • Page 20: Use And Maintenance

    SMOKE STAT MAINS ELECTRICITY pumps. CONNECTION The micro or relay contact connection is To protect the polypropylene conduit from made to TA-CR-SE (J2) connector of the cir- smoke the appliance is provided with an Use a separate electricity supply to connect cuit board after having removed the jumper exhaust thermostat (27 fig.
  • Page 21 ADJUSTMENT OF HEAT OUTPUT FOR HEATING To adjust boiler heat output for heating purposes, i.e., modifying the setting made at the factory which is approximately 17 kW, use a screwdriver to adjust the hea- ting heat output trimmer (10 fig. 17). Gas pressure intake Gas valve To increase working pressure, turn the...
  • Page 22 BOILER CALIBRATION The boiler must always be calibrated while set on heating. “∆p air” ADJUSTMENT “∆p air-gas” ADJUSTMENT To measure “∆p air” simply con- To measure “∆p air-gas”, simply nect a differential pressure connect the positive tap of the gauge with a decimal or Pascal differential pressure gauge to scale to the positive and nega- the gas tap and the negative...
  • Page 23 DISASSEMBLY OF EXPANSION VESSEL To disassemble the expansion vessel, pro- ceed as follows: – Make sure that the water has been emp- tied out of the boiler. – Unscrew the connection and the locknut. – Remove the expansion vessel. Before refilling the system, using a pressu- re gauge attached to the valve make sure that the expansion vessel is preloaded at a pressure of 0.8 to 1 bar.
  • Page 24 USER INSTRUCTIONS WARNINGS – In case of fault and/or incorrect equipment operation, deactivate it, without making any repairs or taking any direct action. Contact an authorised technical staff. – The installation of the boiler and any servicing or maintenance job must be carried out by qualified personnel. Under no circumstances, the devices sealed by the manufacturer can be tampered with.
  • Page 25 CLEANING of the efficient operation of the equip- The boiler is supplied with an electric AND MAINTENANCE ment and safety devices must be car- cable. Should this require replacement, ried out exclusively by the authorized contact exclusively with the authorized Preventive maintenance and checking technical staff.
  • Page 26 – Other anomalies (fig. 6) When one of the red “40÷80°C” leds FLASHING RED LED SPIA ROSSA INTERMITTENTE start flashing, switch-off the boiler and then try to ignite again. After 2 or 3 unsuccessful attempts, do not try again but call authorised techni- cal staff.
  • Page 27 ACTIVATING During functioning the lid of the regulator must be closed. – Selection of the operating mode The operating mode desired is selected by (reference keys grey colour) pressing the relative key with the correspon- ding symbol. The choice is displayed with the symbol Automatic functioning: the heating functions automatically according to the hea- ting programme entered.
  • Page 28 – On-line key If the rooms remain unused for a long period of time, the temperatu- re can be reduced with the on-line key, in this way saving energy. When the rooms are occupied again, press the on-line key to re-heat them. The current choice is displayed on the display: Fixed temperature heating Reduced temperature heating...
  • Page 29 – Heating/hot-water With the heating programme it is possible to set the switching times of the temperature for a service programme period of a week. The weekly programme consists of 7 daily programmes. One daily program- me allows 3 phases of heating. Each phase is defined by a starting time and a finishing time. The n.
  • Page 30 – Current values Display and setting of the gradient of the heating characteristics curve. When the room temperature set is not reached choose the gradient indicated in point 2.9.3 Display of the current boiler temperature. Display of the current power of the burner and of the current operating mode = = heating/ = hot-water service) –...
  • Page 31 * Caldaie a basse emissioni inquinanti (“classe 5” rispetto alle norme europee UNI EN 297 e EN 483). Legnago, 20 luglio 2004 Il Direttore Generale ing. Aldo Gava Fonderie Sime S.p.A. - Via Garbo, 27 - 37045 Legnago (Vr) - Tel. 0442 631111 - Fax Servizio Tecnico 0442 631292 - www.sime.it...
  • Page 32 Rendimenti caldaie basamento a gas DPR 412/93 e DPR 551/99 MODELLO Potenza termica Portata termica Rendimento a carico nominale Rendimento al 30% del carico minimo richiesto misurato minimo richiesto misurato RX 19 CE 22,0 25,0 86,7 88,0 84,0 84,5 RX 26 CE 30,5 34,8 87,0...
  • Page 34 Fonderie Sime S.p.A - Via Garbo, 27 - 37045 Legnago (Vr) Tel. + 39 0442 631111 - Fax +39 0442 631292 - www.sime.it...
