INSTALLER INSTRUCTIONS

CONTENTS
1
DESCRIPTION OF THE BOILER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag. 102
2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag. 104
3
CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag. 111
4
USE AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag. 114
When carrying out commissioning of the boiler, you are highly recommended to perform the following checks:
– Make sure that there are no liquids or inflammable materials in the immediate vicinity of the boiler.
– Make sure that the electrical connections have been made correctly and that the earth wire is connected to a
good earthing system.
– Open the gas tap and check the soundness of the connections, including that of the burner.
– Make sure that the boiler is set for operation for the type of gas supplied.
– Check that the flue pipe for the outlet of the products of the combustion is unobstructed and has been pro-
perly installed.
– Make sure that any shutoff valves are open.
– Make sure that the system is charged with water and is thoroughly vented.
– Check that the circulating pump is not locked.
– Purge the system, bleeding off the air present in the gas pipe by operating the pressure relief valve on the gas
valve inlet.
FONDERIE SIME S.p.A. of Via Garbo 27 - Legnago (VR) - Italy declares that its hot water boilers, which bear the
CE mark under Gas Directive 90/396/CEE and are fitted with a safety thermostat calibrated to a maximum of
110°C, are not subject to application of PED Directive 97/23/CEE as they meet the requirements of article 1
paragraph 3.6 of the Directive.
Supplied By www.heating spares.co Tel. 0161 620 6677
IMPORTANT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Planet Dewy 60 BFR and is the answer not in the manual?

Questions and answers

Related Manuals for Sime Planet Dewy 60 BFR

Summary of Contents for Sime Planet Dewy 60 BFR

  • Page 1: Installer Instructions

    FONDERIE SIME S.p.A. of Via Garbo 27 - Legnago (VR) - Italy declares that its hot water boilers, which bear the CE mark under Gas Directive 90/396/CEE and are fitted with a safety thermostat calibrated to a maximum of 110°C, are not subject to application of PED Directive 97/23/CEE as they meet the requirements of article 1...

  • Page 2: Description Of The Boiler

    European regulation EN 483. sequence/cascade autonomously. “PLANET DEWY 60 BFR” boilers (supplied They are designed and constructed to Upon request, a control unit for a maxi- as Class B devices) are pre-mixed conden-...
  • Page 3 TECHNICAL FEATURES PLANET DEWY 60 BFR Heat output nominal (80-60°C) kW (kcal/h) 56,6 (48.600) Heat output nominal (50-30°C) kW (kcal/h) 62, 1 (53.400) Heat output minimum G20 (80-60°C) kW (kcal/h) 17,0 (14.600) Heat output minimum G20 (50-30°C) kW (kcal/h) 19,0 (16.300) Heat output minimum G31 (80-60°C)

  • Page 4: Installation

    3. such as, for example, Sentinel X300 or “PLANET DEWY 60 BFR” boilers can be With control unit code 8096301, supplied X400. Complete instructions are provided installed in boiler rooms whose size and...
  • Page 5 Condensation drain installation. Should this require replacement, it must be If the inlet is not connected, the boiler purchased exclusively from SIME. A siphoned drain must be connected to the should be regarded a Class B device. The electric power supply to the boiler must...
  • Page 6 3-4. NOTE: SIME declines all responsibility for Equipment for the checking of civil plants injury or damage to persons, animals or 2.7.2 “Logica Remote Control”...
  • Page 7 ROOM STAT CRONOTERMOSTATO Control panel “Logica Remote Control” socket Conector (J2) TA Room stat (not supplied) CR Logica Remote Control (optional) SE External temperature sensor (optional) LOGICA REMOTE CONTROL LOGICA REMOTE CONTROL SONDA EXTERNAL SENSOR ESTERNA Fig. 8 2.7.4 Wiring diagram EV1 Gas valve coil Exhaust thermostat EV2 Gas valve coil...

  • Page 8: Heating Circuit Settings

    LOGICA REMOTE CONTROL vious day. ne system with external contact or – Holiday programme: the programme is through a window contact. All the boiler's functions can be managed interrupted for the holiday period and – Anti-bacterial. by a optional digital multifunctional device automatically restarted on returning code 8092204 for the remote of the boi- home.

  • Page 9: Domestic Hot Water Settings

    Maximum limit of delivery The delivery temperature is limited to the maximum set value. temperature Variation of the maximum speed of the The increase per minute of the prescribed delivery temperature value sent delivery temperature in °C is limited to the imposed value. Activation of adaptation With the activation of the adaptation, the pre-set value transmitted to the boiler regulator is adapted to the effective heat need.
  • Page 10 Input function terminal 3-4 The freely programmable input (terminals 3-4) allows three different functions to be activated. The parameter has the following significance: 1 = If an external sensor is connected, the display will show the temperature of the external sensor ( _ _ = no sensor connected, function disabled). 2 = With an external contact, it is possible to switch-over to "reduced pre- set value of the ambient temperature".
  • Page 11 CHARACTERISTICS 3. 1 ELECTRONIC BOARD the trimmer counter-clockwise. minute it will run at minimum modu- lation pressure before moving to Built according to Low Voltage direc- – “IGNITION POWER” TRIMMER the set heating pressure. tive CEE 73/23 and powered at 230 (6 fig.

  • Page 12: Electronic Ignition

    1 Ignition electrode earth faston 3 Fuse (1,6 AT) 5 “ANN. RIT.” connector 6 “POT. ACC.” trimmer NOTE: To gain access to trimmers (6) and (10), 8 D.H.W. potentiometer unscrew the central heating potentiometer knob. 9 Detector electrode faston 10 “POT. RISC.” trimmer 11 C.H.

  • Page 13: Air Pressure Switch

    off the burner, when power is restored, the boiler will automatically start. AIR PRESSURE SWITCH The pressure switch signal value is measured by a specific tool connected to the positive and negative pressure fixtures. The pressure switch is fac- tory set to 35-45 Pa. SYSTEM AVAILABLE HEAD The head available for the heating plant is shown as a function of the flow in...

  • Page 14: Use And Maintenance

    USE AND MAINTENANCE 4. 1 GAS VALVE The boiler, is equipped standard with Gas valve Air pressure switch the SIT 848 SIGMA gas valve (fig. 16). Fan socket (+) Mixer intake ( - ) Nozzle Digital pressure gauge Air signal intake Air/gas mixer Upstream pressure fixture Intermediate pressure fixture...

  • Page 15: Gas Conversion

    BOILER CALIBRATION GAS CONVERSION connections using soapy water or appropriate products. DO NOT USE NAKED FLAMES. – Close the gas cock. – Stick onto the casing panel the – Replace the injector (pos. 30) plate showing the relevant fee- and the relevant gasket (pos. ding gas.

  • Page 16: Cleaning And Maintenance

    SHELL REMOVAL For easy boiler maintenance the shell can be completely removed by fol- lowing these instructions (fig. 19): - Pull the front panel for ward t o unhook it from the pegs on the sides. - Unscrew the two screws that secu- re the instrument panel to the sides - Unscrew the four screws that secu- re the side to the instrument panel...

  • Page 17: Lighting And Operation

    USER INSTRUCTIONS WARNINGS – In case of fault and/or incorrect equipment operation, deactivate it, without making any repairs or taking any direct action. Contact an authorised technical staff. – The installation of the boiler and any servicing or maintenance job must be carried out by qualified personnel. Under no circumstances, the devices sealed by the manufacturer can be tampered with.
  • Page 18 one for which the boiler has been checking of the efficient operation of equipped, approach the technical the equipment and safety devices staff. must be carried out exclusively by the authorized technical staff. The boiler is supplied with an electric CLEANING AND MAINTENANCE cable.

  • Page 19: Logica Remote Control

    “PLANET DEWY 60 BFR” BOILER INSTALLATION IN SEQUENCE/CASCADE WHEN THE “PL ANET DEWY 60 BFR” IS CONNECTED TO REGUL ATOR RVA 47.320 IN SEQUENCE/CASCADE INSTALLATIONS, ALL BOILERS IN THE HEATING UNIT MUST HAVE THEIR “CR/OFF/INV/RELEASE” SELECTORS POSITIONED AS INDICATED IN FIG. 7.
  • Page 20 ACTIVATING During functioning the lid of the regulator must be closed. – Selection of the operating mode The operating mode desired is selected by (reference keys grey colour) pressing the relative key with the correspon- ding symbol. The choice is displayed with the symbol Automatic functioning: the heating functions automatically according to the hea- ting programme entered.
  • Page 21 – On-line key If the rooms remain unused for a long period of time, the temperatu- re can be reduced with the on-line key, in this way saving energy. When the rooms are occupied again, press the on-line key to re-heat them. The current choice is displayed on the display: Fixed temperature heating Reduced temperature heating...
  • Page 22 – Heating/hot-water With the heating programme it is possible to set the switching times of the temperature for a service programme period of a week. The weekly programme consists of 7 daily programmes. One daily program- me allows 3 phases of heating. Each phase is defined by a starting time and a finishing time. The n.
  • Page 23 – Setting the time To set the current day of the week (1 = Monday/7 = Sunday) To set the current hour To set the current minute Once the hour is completed, the setting of the hour changes. With keys the current hour is regulated. Pressing these keys together, the regulation is speeded up in an increasing sense.
  • Page 24 – Error display Ignition lock-out Rotate selector CR/OFF/EST/INV/RESET on the boiler control panel to the release position ) to reset operation. If the lock-out re-occurs, call an authorised Service Centre. Safety thermostat trip Rotate selector CR/OFF/EST/INV/RESET on the boiler control panel to the release position ) to reset operation.
  • Page 25 Legnago, 29 luglio 2005 Il Direttore Generale ing. Aldo Gava Fonderie Sime S.p.A. - Via Garbo, 27 - 37045 Legnago (Vr) - Tel. 0442 631111 - Fax Servizio Tecnico 0442 631292 - www.sime.it Supplied By www.heating spares.co Tel. 0161 620 6677...
  • Page 26 PLANET DEWY 30 BF - 30 BFT 29,3 30,0 92,5 97,7 98,5 106,6 PLANET DEWY 30 BFR 28,3 29,0 92,5 97,7 98,5 106,6 PLANET DEWY 60 BFR 56,6 58,0 92,8 97,5 98,8 109,8 PLANET DEWY 30/50 BF 29,2 30,0 92,5 97,2 97,9 106,7 FORMAT 25 OF - METRÒ...
  • Page 27 Si dichiara che la caldaia SIME tipo .......avente...
  • Page 28 Supplied By www.heating spares.co Tel. 0161 620 6677...
  • Page 29 Supplied By www.heating spares.co Tel. 0161 620 6677...
  • Page 30 Fonderie Sime S.p.A - Via Garbo, 27 - 37045 Legnago (Vr) Tel. + 39 0442 631111 - Fax +39 0442 631292 - www.sime.it Supplied By www.heating spares.co Tel. 0161 620 6677...
