Installation and connections
in.touch 2-EN (home) installation
The in�touch 2-EN unit must be installed inside the house near the router as it needs to be connected to it� The in�touch
2-EN is provided with an Ethernet cable and a power supply� If required, a longer cable of good quality can be used by
the installer (longer cable not provided) to install the in�touch 2-EN module closer to the spa within the home� The only
requirement for installation location is that household current be available to power the in�touch 2-EN module using the
provided wall transformer�
The in�touch 2-EN can be fixed in the house to optimize the signal strength� We recommend that you install the unit with
a #8 pan head screw�
Here are some suggestions for a successful installation:
• If possible, install device on the first floor of your house�
• If installing in a basement, place at highest level possible and closest to a window�
• Try to install as far as possible from materials that may interfer with signal (ie� metal structures, thick cement walls)�
Connection of the in.touch 2-EN (home)
Simply connect Ethernet cable into the RJ45 port of the in�touch 2-EN module and in one of the available LAN ports on
the router�
Finally, to power up the in�touch 2-EN, connect the provided transformer to a 120V (North American model) or 220V
(European model) household supply and connect the USB cable between the transformer and the in�touch 2-EN�
RJ45 Ethernet connection
Micro usb power
Ethernet cable
LAN port, router
7
