Automatic Key Cutting Machine CONDOR XC-MINI PLUS
4

. Overview

4.1

Structure diagram

Emergency switch
Probe
LED light
Clamp
06

4.2 Characteristics

Operating button
Angle-adjustable 7-inch
capacitive touch screen
Protection shield
Cutter

4.3 Specification

Key tightening knob
Clamp tightening wrench
Automatic Key Cutting Machine CONDOR XC-MINI PLUS
Build-in database
0-90° angle selection 7 inch capacitive touch screen
3-Axis ball screw transmission
Cross rail, high stability
Aluminum structure, larger space for putting flip keys
Strengthened air tightness effectively prevents metal scraps from entering
into the machine
Cutter and probe work in parallel
Support clamps M1
/M2
(standard equipped)
(standard equipped)
Support online update
Support Sided/Track/Dimple/Tibbe key
Input voltage
Input frequency
Power
515 x 480 x 380 mm
Package size
Machine size
250 x 413 x 300 mm
LED screen resolution
Principal axis Rotation speed
USB port
Working temperature
Humidity
Net weight
Gross weight
/M3
/M4
(optional)
(optional)
90-264 VAC
47-63 Hz
200 W
1024 x 600
9000 rpm
USB 2.0
0-50 C
10-90%
19 Kg
24 Kg
07
