- Page 1 Automatic Key Cutting Machine - CONDOR XC-007 CONDOR Automatic Key Cutting Machine XC-007 User Manual V1.2...
-
Page 2: Table Of Contents
Automatic Key Cutting Machine - CONDOR XC-007 Table of Contents 1） Safety Precautions and Warnings --------------------------------------------3 2） General Information -------------------------------------------------------4 3） Packing List --------------------------------------------------------------5 4） Overview 4.1 Machine overview ------------------------------------------------------8 4.2 Specification --------------------------------------------------------9 5） Installation 5.1 Cutter installation --------------------------------------------------10 5.2 Cutter release -------------------------------------------------------11 5.3 Clamp installation ---------------------------------------------------12... -
Page 3: Safety Precautions And Warnings
Automatic Key Cutting Machine - CONDOR XC-007 1．Safety Precautions and Warnings To prevent personal injury or damage to machine, read this instruction manual first and observe the following safety precautions: Always work on machine in a safe environment. ... -
Page 4: General Information
Automatic Key Cutting Machine - CONDOR XC-007 2．General Information Thank you for choosing CONDOR XC-007 Automatic Key Cutting Machine. This manual includes the use of equipment notes, please read this manual carefully before use so that you can correctly use it. -
Page 5: Packing List
Automatic Key Cutting Machine - CONDOR XC-007 3. Packing List The whole package covers the following items, if missing, please contact your dealer. Name Image Quantity Description Cutting tool 2.5mm Cutter (Ø2.5×Ø6×40L ) Cutting tool 1.5mm Cutter (Ø1.5×Ø6×40L ) Detection tool 1.0mm Probe... - Page 6 Automatic Key Cutting Machine - CONDOR XC-007 X1 Fixture Fixture X2 Fixture Fixture Keymachine body Protective cover Pads Install with 4mm allen wrench Driver CD Quality certificate Packing List...
- Page 7 Automatic Key Cutting Machine - CONDOR XC-007 User manual Note: -- Replace the cutter regularly to ensure good cutting results. -- Spindle drive belt and timing belt stepper motor requires regular inspections degree of wear, excessive wear and tear please change to ensure the accuracy of the cutting force and the machine is running.
-
Page 8: Overview
Automatic Key Cutting Machine - CONDOR XC-007 4. Overview 4.1 Machine Overview Protective cover Cutter installation knob 7’Touch screen Operation buttons Emergency stop button LED lights Spindle lock button Probe Cutter Clamp Key locking knob Clamp lock... -
Page 9: Specification
Automatic Key Cutting Machine - CONDOR XC-007 4.2 Specifications AC110V/220V Input Voltage 47~63Hz Input Frequency 220W Consume L 460×W 520×H 620 (mm) Packing Dimensions L 336×W 407×H 490 (mm) Machine Dimensions 800×480 Display 12,000 rpm Spindle Speeds USB2.0 0~50℃ Working Temperature... -
Page 10: Installation
Automatic Key Cutting Machine - CONDOR XC-007 5. Installation 5.1 Cutter installation Cutter installation knob Spindle lock button Cutter installation steps: 1） Put the cutter into the jacket. 2） Press and hold "Spindle lock button". 3） Turn clockwise "Cutter installation knob", "Spindle lock button" will take advantage into the positioning hole on spindle;... -
Page 11: Cutter Release
Automatic Key Cutting Machine - CONDOR XC-007 5.2 Cutter release Cutter release steps: 1） Press and hold "Spindle lock button", turn counterclockwise "Cutter installation knob" to loosen cutter. 2） Hold the cutter when loosen it to prevent fallen damage to cutter. -
Page 12: Clamp Installation
Automatic Key Cutting Machine - CONDOR XC-007 5.3 Clamp installation Locating pin pull handle Locking wrench Clamp installation steps: 1） Turn counterclockwise "Locking wrench" to loosen. 2） Pull out "Locating pin pull handle". 3） Push the clamp from the right side of the clamp base, choose corresponding anchor point according to the key type. -
Page 13: Clamp Base Wiring
Automatic Key Cutting Machine - CONDOR XC-007 5.4 Clamp base wiring 1）Connect wire to the connector and tighten. -
Page 14: Operating Instructions
Automatic Key Cutting Machine - CONDOR XC-007 6. Operating instructions Please initial device before use: 6.1 Leveling cutter and probe 1） Click "Machine Initial" button 2） Click "Height detect" button... - Page 15 Automatic Key Cutting Machine - CONDOR XC-007 3） Follow the steps on the screen, then click "Continue" button 4） Follow the steps on the screen, then click "Continue" button...
-
Page 16: X1 Initialization
Automatic Key Cutting Machine - CONDOR XC-007 5） Select cutter diameter, click "Enter" button to finish 6.2 X1 Initialization 1） Click "Machine Initial" button... - Page 17 Automatic Key Cutting Machine - CONDOR XC-007 2） Click "X1 Initial" button 3） Follow the steps on the screen, then click "Continue" button...
-
Page 18: X2 Initialization
Automatic Key Cutting Machine - CONDOR XC-007 6.3 X2 Initialization 1）Click "X2 Initial" button 2）Follow the steps on the screen, then click "Continue" button... -
Page 19: Factory Mode
Automatic Key Cutting Machine - CONDOR XC-007 3）Follow the steps on the screen, then click "Continue" button 6.4 Factory mode 1） Enter factory mode Press and hold BOTH A and B button, then power on the machine. -
Page 20: Calibration Method 1 (Using Dual Probe)
Automatic Key Cutting Machine - CONDOR XC-007 Click "Factory Mode" button 2） Calibration method 1 (using dual probe) -
Page 21: Calibration Method 2 (Cutting A Blank Key)
Automatic Key Cutting Machine - CONDOR XC-007 3） Calibration method 2 (cutting a blank key) 4）Follow the steps on the screen, then click "Continue" button Note: You can choose either Method 1 or Method 2 to calibrate machine. -
Page 22: Key Cutting Method 1 (Known Key Blank Name And Bit Code)
Automatic Key Cutting Machine - CONDOR XC-007 6.5 Key cutting method 1 (Known key blank name and bit code) 1） Click "Cut by Code" 2） 1. Select or input key blank name 2. Click "Enter" button... -
Page 23: Key Cutting Method 2 (From Key Database)
Automatic Key Cutting Machine - CONDOR XC-007 3） 1. Change clamp 2. Input bit code and verify, then click "Start Cut" button to start 6.6 Key cutting method 2 (From key database) 1） Click "Key Database" button... - Page 24 Automatic Key Cutting Machine - CONDOR XC-007 2） 1. Select car make 2. Click "Enter" button 3） 1. Input key code 2. Click "Enter" button...
- Page 25 Automatic Key Cutting Machine - CONDOR XC-007 4） 1. Select key series 2. Click "Enter" button 5） 1. Bitting code will be searched from database, and displayed on screen. 2. Click "Start Cut" button to start...
-
Page 26: Key Cutting Method 3 (Copy Key From Existing Key)
Automatic Key Cutting Machine - CONDOR XC-007 6.7 Key cutting method 3 (Copy key from existing key) 1） Click "Key Copy" button 2） 1. Select car make 2. Click "Enter" button... - Page 27 Automatic Key Cutting Machine - CONDOR XC-007 3） 1. Select or input key blank name 2. Click "Enter" button 4） 1. Click "Key Learn" button, learned bit code will display on screen 2. Verify bit code, and modify bit code if needed.
-
Page 28: Find Bitting
Automatic Key Cutting Machine - CONDOR XC-007 6.8 Find bitting 1） Click "Find bitting" button 2） 1. Select car make 2. Click "Enter" button... - Page 29 Automatic Key Cutting Machine - CONDOR XC-007 1. Select or input key blank name 2. Click "Enter" button 1. Select key type 2. Click "OK" button...
- Page 30 Automatic Key Cutting Machine - CONDOR XC-007 5） 1. Input known bit code 2. Input unknown bit code as "?" 3. Click "Find bitting" button 6）Possible bit code was listed. Note that system has sorted the codes by most economical way to save blank keys. For example, the bit codes under "Key 1" only...
-
Page 31: Online Update
Automatic Key Cutting Machine - CONDOR XC-007 7．Online Update Please contact your dealer for latest Update Tool. CONDOR Automatic Key Cutting Machine Online Update Tool.exe Follow the update steps prompts on the software. Note: Download data and upgrade may take a long time, please be patient.
