Automatic key cutting machine

Advertisement

PANDA
Automatic Key Cutting Machine
XA-006
User Manual
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Panda XA-006 and is the answer not in the manual?

Questions and answers

Summary of Contents for Xhorse Panda XA-006

  • Page 1 PANDA Automatic Key Cutting Machine XA-006 User Manual V1.0...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1 Safety precautions and warnings 2 General information 2.1 Machine description 2.2 Equipment characteristics 3 Product List 4 Overview 4.1 Equipment structure diagram 4.2 Equipment specifications 4.3 Indicator status 4.4 Software overview 5 Equipment installation instructions 5.1 Cutter or probe installation 5.2 Disassembly of cutter or probe 5.3 Clamp installation 5.4 Real sample drawing of clamp...
  • Page 3: Safety Precautions And Warnings

    Wear protective goggles that are in line with ANSI standard future reference. All the information and illustrations in this document are for guidance only. Xhorse Electronics reserves the right to alter Put down the protective shield when the machines is working products designs, dimensions or info to improve the products quality.
  • Page 4 Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 3 . Product packaging checklist The panda machine factory packaging box contains the following items. If there are any missing items, please contact the dealer. Name Sample picture...
  • Page 5: Overview

    Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 4. Overview 4.1 Structure diagram 4.2 Specification Input voltage 12V DC Input Power Handle Power consumption Switch Principal axis rotation speed 11000rpm USB socket USB2.0 Indicator light Working temperature 0-45℃(-4-113°F)
  • Page 6: Software Overview

    Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 4.4 Software overview 4.4.1 Introduction Support Bluetooth connection and operation with APP Support machine self-check function 234mm Supports the learning and cutting of a variety of common car keys...
  • Page 7: Cutter Or Probe Installation

    Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 5. Installation instruction 5.1 Cutter and probe installation 5.2 Cutter and probe uninstallation Cutter and probe installation steps: Disassembly steps of cutter or probe: 1) Hold the handle of the cutter or probe with your hand, and loosen the cutter or probe 1) Insert the cutter into the cutter hole and push it up to the limit.
  • Page 8: Clamp Installation

    Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 5.3 Clamp installation 5.4 Pictures of clamps Clamp A1 A side support type (as shown below) B side support type (as shown below) Standard single/double sided key Channel track...
  • Page 9: Smart Phone App Connection To The Machine

    QR code as shown below. 2. Connect the machine to the power supply and turn it on, open the Xhorse APP, switch to the homepage of the CNC machine, click “Switch Device”, and select Panda.
  • Page 10 Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 3) Please select the diameter of the 4) Follow the instructions on the page 5) Clean the probes, milling cutters, jigs, milling cutter actually installed. and text, click “Start ”, and the machine and keys that have been cut with a brush will start cutting.
  • Page 11: How To Use The All Key Lost

    Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 6.3 How to use the All Key Lost *This function needs to register and log in to the APP account, and needs to be online for inquiries, please keep the network unblocked. There are three ways to obtain the key code for processing keys using the function of losing all keys: 1.
  • Page 12: How To Use The Vehicle Database

    Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 6.4 How to use the Vehicle Database To use the car database, you must first determine the model and year of the car. 1) Click “Vehicle Database” to enter the ve- 2) Select car brand.
  • Page 13: How To Use Cut By Bitting

    Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 How to se Cuy itting There are two methods for Cuy by bitting processing according to whether there is an original key. Method one: Without the original key,there are two ways to get key bit.
  • Page 14 Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 Method Two: There is the original car key and use key bit to cut key. Shoulder align 1) Click “Cut by bitting”, select or input the 2) Select the key type and click to enter the...
  • Page 15: How To Use Find Bitting

    Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 6.6 How to use Find Bitting Compared with the ignition lock, the door locks and tail box locks of some models are missing lock plate pieces. You can disassemble the car lock to find the key bit missing piece position, replace it with “?”, and enter it into the Find Bitting.
  • Page 16 Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 3) Select or input the key blank type, and 4) Enter the known key bit, if the key bit is not 5) APP will display all possible results, and click to enter.
  • Page 17: How To Use The 3D Function

    Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 6.8 How to use 3D function 6.7 How to use Cut by single-bitting This function requires the APP to select the expert mode; *This function currently only supports some side cut keys, and will continue to upgrade Cut by single-bitting is suitable for individual processing of a certain key bit, it is mostly used more different types of keys.
  • Page 18: How To Use Photos To Read Key Bit

    Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 6.9 How to use photos to get key bit *This function can support direct photo or select key picture from mobile phone album. 1) Click “Decode key”. 2) Select Learn key via photo and click...
  • Page 19: How To Use The Parameter Fine-Tuning Function

    Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 6.10 How to use the parameter fine-tuning function *This function APP needs to select the expert mode, which is suitable for fine-tuning the parameters after the key learning.
  • Page 20: Online Upgrade

    Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 7. Online upgrade 7.1 Online database upgrade 3) Adjust the parameters according to actual 1) Enter the main interface of the APP and 2)Click “Database Update” to enter the needs, and then cut the key.
  • Page 21 Automatic Key Cutting Machine PANDA XA-006 Automatic Key Cutting Machine PANDA XA-006 7.2 Firmware upgrade APP Bluetooth upgrade or use Upgrade kit. 7.2.1APP Bluetooth firmware upgrade (recommended to use ) 3) Click “Update” to download the updated 4) Wait for the device offline data package 1) Enter the main interface of the APP and 2) Click “Firmware Update”...
  • Page 22 1. Contact the dealer to obtain the “upgrade kit” software 2. Send an email titled “Upgrade kit” to support@xhorse.com 3. Consult online customer service in Xhorse App to obtain it. 3) If the computer page will prompt: the selected device is not found, and the device driver is missing, click “Yes”...
  • Page 23: Maintenance

    Xhorse APP All the information and illustrations in this document are for guidance only. Xhorse reserves the right to alter products designs, dimensions or info to improve the products quality. The contents of this document are fully protected by Copyright and may not be copied or reproduced in any form (e.g.
