Campbell CS300 Product Manual

Pyranometers
Hide thumbs Also See for CS300:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
CS300 and
CS301
Pyranometers
Revision: 9/18
Copyright © 1994 – 2018
Campbell Scientific

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS300 and is the answer not in the manual?

Questions and answers

Related Manuals for Campbell CS300

Summary of Contents for Campbell CS300

  • Page 1 CS300 and CS301 Pyranometers Revision: 9/18 Copyright © 1994 – 2018 Campbell Scientific...
  • Page 3 Quotations for repairs can be given on request. It is the policy of Campbell Scientific to protect the health of its employees and provide a safe working environment, in support of this policy a “Declaration of Hazardous Material and Decontamination”...
  • Page 5 PLEASE READ FIRST About this manual Please note that this manual was originally produced by Campbell Scientific Inc. primarily for the North American market. Some spellings, weights and measures may reflect this origin. Some useful conversion factors: Area: 1 in...
  • Page 7 • Periodically (at least yearly) check electrical ground connections. WHILE EVERY ATTEMPT IS MADE TO EMBODY THE HIGHEST DEGREE OF SAFETY IN ALL CAMPBELL SCIENTIFIC PRODUCTS, THE CUSTOMER ASSUMES ALL RISK FROM ANY INJURY RESULTING FROM IMPROPER INSTALLATION, USE, OR MAINTENANCE OF TRIPODS, TOWERS, OR ATTACHMENTS TO TRIPODS AND TOWERS...

  • Page 9: Table Of Contents

    Table of Contents PDF viewers: These page numbers refer to the printed version of this document. Use the PDF reader bookmarks tab for links to specific sections. 1. Introduction ..............1 2. Precautions ..............1 3. Initial Inspection ............1 4.
  • Page 10 Multipliers Required for Average Flux and Total Flux Density in SI and English Units ................ 9 B-1. Wiring for Example Programs............B-1 CRBasic Examples B-1. CR1000X Program Measuring the CS300 or CS301 ...... B-1 B-2. CR6 Program Measuring the CS300 or CS301 ....... B-2...

  • Page 11: Introduction

    CS300 and CS301 Pyranometers Introduction The CS300 and CS301 measure total sun and sky solar radiation for solar, agricultural, meteorological, and hydrological applications. Their spectral range of 360 to 1120 nanometers encompasses most of the shortwave radiation that reaches the Earth surface. These pyranometers connect directly to our dataloggers.
  • Page 12 CS300 and CS301 Pyranometers The following procedure also describes programming with Short Cut. Open Short Cut and click Create New Program. Double-click the datalogger model. In the Available Sensors and Devices box, type CS301. Also locate the sensor in the Sensors | Meteorological | Solar Radiation folder. Double- click CS301 Pyranometer.
  • Page 13 CS300 and CS301 Pyranometers In Output Setup, type the scan rate, meaningful table names, and the Data Output Storage Interval. Select the measurement and its associated output options. Click Finish and save the program. Send the program to the datalogger if the datalogger is connected to the computer.

  • Page 14: Overview

    The resistance of the potentiometer is adjusted when the sensors are calibrated so that all sensors have the same output sensitivity. The CS300 and CS301 are calibrated against a Kipp and Zonen CM21 under natural sunlight to accurately measure sun plus sky radiation (360 to 1120 nm).

  • Page 15: Installation

    CS300 and CS301 Pyranometers –2 (full sunlight  1000 W m –2 Measurement range: 0 to 2000 W m Light spectrum waveband: 360 to 1120 nm (wavelengths where response is 10% of maximum) Installation If programming the datalogger with Short Cut, skip Section 7.3, Wiring to the Datalogger , and Section 7.4, Programming...
  • Page 16 CS300 and CS301 Pyranometers Secure the CM225 to the crossarm by placing the U-bolt in the bottom holes and tightening the nuts. Secure the 015ARM to the mast by tightening the U-bolt nuts. CM225 Stand CM200-Series Crossarm U-bolt Nuts 015ARM U-bolt Nuts Place the pyranometer in the centre of the pyranometer levelling base.
  • Page 17 CS300 and CS301 Pyranometers CS300 or CS301 Pyranometer Levelling Base Loosely mount the pyranometer levelling base on the CM225 or 015ARM. Do not fully tighten the three mounting screws. Mounting holes used for the CS300 and CS301 are indicated in yellow.

  • Page 18: Wiring To The Datalogger

    Ground/⏚ FIGURE 7-1. Schematic diagram Connections to Campbell Scientific dataloggers are given in TABLE 7-1. When Short Cut is used to create the datalogger program, connect the sensor to the terminals shown in the wiring diagram created by Short Cut.

  • Page 19: Total Solar Radiation

    Handle the sensor carefully when cleaning. Be careful not CAUTION to scratch the surface of the sensor. Recalibrate the CS300 or CS301 every three years. Refer to the Assistance page at the beginning of this document for the process of returning the...

  • Page 20: Troubleshooting

    CS300 and CS301 Pyranometers Troubleshooting Symptom: –9999, NAN, or radiation values around 0 Check that the sensor is wired to the single-ended terminal specified by the measurement instruction. Verify that the range code is correct for the datalogger type. Disconnect the sensor wires from the datalogger and use a DVM to check the voltage between the red (+) and the black (–) wires.

  • Page 21: Importing Short Cut Code Into Crbasic Editor

    Appendix A. Importing Short Cut Code Into CRBasic Editor This tutorial shows:  Importing a Short Cut program into a program editor for additional refinement  Importing a wiring diagram from Short Cut into the comments of a custom program Short Cut creates files, which can be imported into CRBasic Editor.

  • Page 23: Example Programs

    Black Black Signal Ground ⏚ ⏚ Clear Clear Shield B.1 CR1000X Program CRBasic Example B-1. CR1000X Program Measuring the CS300 or CS301 'CR1000X 'Declare Constants 't=scan rate in seconds Const t = 10 'Declare Variables and Units Public BattV Public...

  • Page 24: Cr6 Program

    SlrW=SlrW*5.0 'Call Data Tables and Store Data CallTable(Hourly) CallTable(Daily) NextScan EndProg B.2 CR6 Program CRBasic Example B-2. CR6 Program Measuring the CS300 or CS301 'CR6 Series 'Declare Constants 't=scan rate in seconds Const t = 10 'Declare Variables and Units...
  • Page 25 Appendix B. Example Programs 'Convert mV to W/m² SlrW=SlrW*5.0 'Call Data Tables and Store Data CallTable Hourly CallTable Daily NextScan EndProg...
