Service Information - BCS 660HY WS Hydrostatic Commander Operating Instructions Manual

Changing filter and gearbox oil
Discharge the oil from the gearbox via the 3 discharging oil caps (fig. 11, B) .
Every Week
• With the machine on a level surface, check the gearbox oil level, top up as necessary
using the correct oil as listed on the following page. The gearbox oil level should reach
between the two notches on the dipstick (fig. 10, D) .
After the First 2 Weeks or 30 Hours of Work
Replace the gearbox oil filter ONLY, (fig. 9, A), part number 58056249.
•
Check the gearbox oil level using the dipstick (figs. 9 & 10, C) , run the machine for 2-3
•
minutes and recheck gearbox oil level, top up as necessary using the correct oil as listed
on the following page.
Every 100 Hours of Work or 12 Months
• Change the gearbox oil by removing the gearbox drain plug (fig. 11, B) .
Replace the gearbox oil filter (fig. 9, A), part number 58056249.
•
• Clean the gearbox drain plug and refit.
• Fill gearbox using the correct oil and quantity as listed on the following page.
• Check the gearbox oil level, run the machine for 2-3 minutes and recheck gearbox oil
level.
C
BCS660HY/0819

Service Information

A
Figure 9
BCS 660HY Hydrostatic Commander
To replace the oil filter (fig. 9, A)
1. Using the correct spanner, remove
the filter.
2. Smear a film of oil on the rubber
gasket of the new filter.
3. Mount the new filter, screwing and
tightening by hand only.
Page 23
