Making Adjustments - BCS 660HY WS Hydrostatic Commander Operating Instructions Manual

The machine is delivered with the correct
adjustments, however, if it is necessary to make
adjustments, then this should be done via the
adjusting screws below or on the handlebar:
PowerSafe clutch cable adjustment (fig. 6a, 1).
®
Steering brakes/clutches
(figs. 6a & 6b, 2).
Throttle cable adjustment (fig. 6c, 3).
Forward/reverse knob cable adjustment (fig.
6d, 4).
Engine stop cable adjustment (fig. 6c, 5).
Engine RPM adjustment (fig. 6c, 6) (see engine
manual).
Figure 6d
BCS660HY/0819
BCS 660HY Hydrostatic Commander

Making Adjustments

cable adjustment
4
1
Figure 6a
Figure 6b
6
3
5
Figure 6c
2
2
Page 15
