1. Wheel speed lever
2. PTO engagement lever
3. Handlebar height adjustment lever
4. Parking brake lock lever
5. Throttle lever
6. Engine stop lever
7. Red OPC stop lever
8. PowerSafe® clutch lever
9. Right steering lever (also on the right)
BCS660HY/0819
BCS 660HY Hydrostatic Commander

Controls Description

10. Left steering lever
11. Right steering lever
12. Handlebar lateral adjusting lever
13. Hydrostatic transmission control lever
14. Dipstick transmission oil level and filling
15. Support and filter oil transmission
16. PTO quick hitch
17. Oil radiator
18. Fuel tank cap
Figure 1a
Page 11
