QUICK START GUIDE
FUNMAT HT

Remove The Packaging

Unpack the printer and accessories trays from the cardboard box, and then take out the printer
and accessories trays.
STEP 1:
Connect the power cable and
power on your printer.
STEP 2:
Lower down the build plate by
clicking "Settings" → "Other
Settings"→ "Buildplate to the bottom."
Reminder:
Please keep all packaging materials for warranty purpose.
PN：320-0205
QUICK START GUIDE
Gently place the printer on a flat, solid and sturdy platform.
1 / 8
REV: P02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FUNMAT HT and is the answer not in the manual?

Questions and answers

Related Manuals for Intamsys FUNMAT HT

Summary of Contents for Intamsys FUNMAT HT

  • Page 1 QUICK START GUIDE PN：320-0205 REV: P02 FUNMAT HT QUICK START GUIDE Remove The Packaging Unpack the printer and accessories trays from the cardboard box, and then take out the printer and accessories trays. Gently place the printer on a flat, solid and sturdy platform.
  • Page 2 QUICK START GUIDE PN：320-0205 REV: P02 Install The Printer STEP 1: Power off the printer. Use the Allen key and socket wrench to remove the four screws to free the X & Y axis. STEP 2: Install the motor on top of the extruder, and ensure the upper PEEK tube is securely inserted into its position.
  • Page 3 QUICK START GUIDE PN：320-0205 REV: P02 STEP 6: Power on the printer. power off NOTE: All maintenance work must be performed in mode. Set Up The Printer Install The Filament Go back to the main menu, click “Material → “Load Material”, then refer to the instruction and the right images to ensure that the filament is installed correctly.
  • Page 4 QUICK START GUIDE PN：320-0205 REV: P02 STEP 2: Select “Manual Level”. Have the leveling card with thickness of 0.2mm ready and then start the bed leveling process. STEP 3: There are three screws below the build plate for manual bed leveling. STEP 4: Tighten the center screw of the build plate and use leveling card to...
  • Page 5 QUICK START GUIDE PN：320-0205 REV: P02 Auto Bed Leveling STEP 1: Verify the auto leveling sensor is healthy. Go back to the main menu, click “Settings” → “Other Settings” → “Test” → ”Leveling sensor”. The nozzle will be heated up. Wait for approx. 2 minutes, follow the instruction on the screen, use a removal tooling to touch the hot nozzle, and then lift the nozzle...
  • Page 6 QUICK START GUIDE PN：320-0205 REV: P02 NOTE Do not touch the hot nozzle to avoid burns. STEP 3: Click “Auto Level”, printer will automatically finish the auto leveling process without any human interference. Firstly, the machine will preheat the buildplate and chamber, then preheat the nozzle.
  • Page 7 QUICK START GUIDE PN：320-0205 REV: P02 Install Software After successfully setting up the printer, locate the SD card and install the INTAM-SUITE software on your computer. It is available for Windows, Mac OSX and Linux. Camera Guide To connect the camera please follow the Camera User manual in your box. You can install the App of the camera on your smartphone or computer.
  • Page 8 Warranty 1 year Warranty, please provide the Series No. to your local reseller for warranty. Support For more information or technical support please visit: www.intamsys.com/support/ (or contact nearby reseller) 8 / 8...
