Page 2
Caution Warning: To prevent electrical shock or damage do not expose this unit to any liquids including rain or excessive humidity! 1. Please read these instructions carefully to avoid damage due to inappropriate installation and/or operation. 2. Please keep the screen away from heating/cooling sources, such as radiators, heaters, ducted heating/air-conditioning vents, fireplaces and/or other relatively harmful/dusty electrical devices.
Page 3
Description Aluminium Casing Side View Tab Tension Power Cord Screen Fabric Dropper Bar Smart Combo Tab Tensioned Screen Hook M12 Nut M12 Bar Accessories Bracket M12 Bar (4pcs) M12 Nut (16pcs) Hook (4pcs) Pressing Piece (2pcs) M10X100 Expansion Screw (8pcs) Wrench (1pc) Hanging Board (2pcs) M6 Allen Screw (4pcs)
Installation Instructions The screen needs to be recessed into the ceiling cavity. This manual demonstrates 2 types of installations that could be used for suspension or false plaster ceilings. Please check all necessary parts and quantities for your preferred method before commencing the installation. Concrete Roof Depending on installation you may require 2 or 4...
Mark the location for each of the 4 assembled ceiling Hooks, (usually length of case minus 94mm) at 180mm apart and secure them using the expansion screws provided, (figure 5). The M12 Bars should be ready to secure the case once it has been assembled. H minus 100 L minus 94 Four hanging...
Page 6
Slide an M6 Hex Head bolt into each of the channels that run through the back of the case, (figure 12.1). Align the Hanging Board with the 2 screws and ensure that the Hanging Board is at least 5mm from the edge, (figure 12.2 and 12.3) and secure Hanging Board with the M6 nuts, (figure 12.4).
Page 7
Should you need to connect other cables and/or add other control systems at a later stage, please follow the steps below. 1) Remove the power box retaining screw and gently lower the Power Box assembly. 2) Insert the control system cable to the corresponding output, (figure 10).
Page 8
Trim the M12 threaded rods to the desired length, (H - height minus 100mm). Measure the distance between the mounting holes of the case and mount the threaded bars to the roof, (figure 4 & 5). The M12 Bars should be ready to secure the case once it has been prepared.
Page 9
Fix the screen using M12 nut, then fasten the nut by wrench (accessories) (figure 13-14); until the fascia trim aligns with the ceiling (figure 15) and connect the power. M12 Screw Not provided (screwdriver can replace) Wrench Wrench Figure 13 Figure 14 Align the fascia trim with ceiling...
Should you need to connect other cables and/or add other control systems at a later stage, please follow the steps below. 1) Remove the power box retaining screw and gently lower the Power Box assembly. 2) Insert the control system cable to the corresponding output, (figure 11).
Installation Completed (figure 27). Suspension False Plaster Ceiling Ceiling Figure 27 Note: M12 threaded bar provide is 500mm lengths. If the ceiling gap is larger than 600mm wide you will need to provide your own. Product Instruction Infrared Remote Control Controller Buttons Function Instructions: Your remote control comes with a battery installed.
External Control System There are four control systems available for this motorised screen: A) Manual Control B) Infrared Remote Control (IR) C) Trigger Dry Contact 12 Volt D) Dry Contact External Infrared Receiver Manual Control The manual control button is located under Stop the power box, on the left hand side of the screen, close to the power cord.
Page 13
Protecting Your Screen: • Keep away from direct sunlight or high temperatures. • Examine both the front and back surfaces before retracting into the case to make sure it is free of dust, dirt, insects or other foreign matter. • Use a soft brush or cloth to lightly remove any foreign particles.
