Model CN-MIxx
Before use, please read instructions carefully. After installation, store instructions for future reference.
ISO9001:2000
International Certification
Instruction Manual for
CNV Intellectualized-controlled Screen
Thank you for purchasing a Grandview projection screen.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Grandview CN-MI series
Summary of Contents for Grandview CN-MI series
- Page 1 Tel: 1-604-412-9777 Fax: 1-604-412-9796 Website: www.grandviewscreen.ca Thank you for purchasing a Grandview projection screen. Guangzhou Grandview Crystal Screen Co., Ltd. Before use, please read instructions carefully. After installation, store instructions for future reference. P.O. 51 1400 Federal Ind. Zone No. 363, Y ushan West Road,...
- Page 2 Description Illustration Front view Side view Top view Screen parts Metal Casing Black border Installation bracket Screen fabric Accessaries Remote control emitter ( 1pc ) 7# batteries ( 1 pair ) Trigger line ( 1pc ) External IR Receiver ( 1pc ) Allen Key ( 1pc ) Instruction Manual ( 1pc ) Optional Accessory...
-
Page 3: Installation
Installation Warnings Attention: Take out all the parts from the packaging and follow the accessories guideline to ensure you have all the parts.Installing > Please make sure there is no dust or dirt on the fabric surface before rolling it back to the casing is as below. -
Page 4: Specifications
Specifications 4. Use the horizontal indicator to make sure the screen are at horizontal level ( Figure 5 ). Viewing area Net weight L (mm) A (mm) P (mm) B3 (mm) horizontal indicator Format Model Size in W (mm) H (mm) CN-MI84 84"... - Page 5 Instructions How to use IR Remote Control 1. Turn the manual/IR remote control switch to position "0" ( remote control stalls ) ( Figure 20 ). 2. Take out the External IR Receiver, and connect the end to the relevant access in the end cap ( Figure 21 ). Controller button instruction 1.To raise screen press "UP .
- Page 6 Operation Instruction How to use Trigger Control: 1. Insert one end of the signal cable into the Trigger jack of the handle controller, and the other end into the + 5V-12V DC Power supply connection output hole of the projector ( Figure 15 ) .
