Grandview Prestige PP R1 Series User Manual

Installation for screen:

Use tape to measure the overall length and height of
screen. Then apply the following formula to calculate
the distance of mounting brackets (please check be-
low). Finally align the mounting brackets horizontally
and vertically.
a：Horizontal distance: 0.6* overall length of screen
b：Vertical distance: overall height of screen minus 96mm.
a
Align horizontally
Align horizontally
Slide the nut plates preinstalled in long black velvet
frame to align with mounting brackets. Then drive
tightly the Phillips screws with nut plates to finish instal-
lation of screen.
Slide the nut plate
Maintainance
In order to maintain good performance of
screen, please cover the screen with cloth if it is
not used for a long term to prevent dust and dirt
b
from screen. If there are apparent varias or dirt
on screen material, please use soft brush or
cloth to clean it.
Clean the screen material
Rub gently according to grain of velvet frame
with warm water mixed with soft detergent.
(Please be noted that it should be gently rubbed
instead of scrubbing hard). Please prevent from
hitting the frame in case of damage of velvet. By
finishing cleaning, let frames dry itself.
Please do not use any dissolvent, chemical
agent or any tool with strong friction for clean,
which would cause permanent damage to the
screen.
GRANDVIEW CRYSTAL SCREEN CO., LTD.
No. 43 South International Trade Avenue, Hualong,
Panyu, Guangzhou, GuangDong, P.R.C
Tel: +86-20-84899499
User Manual for Prestige Series Fixed Frame Screen
Model: PP-xx (R1)
