LE4020/LE4020CF V5.0
LTE / 3G CELLULAR ALARM COMMUNICATOR
INSTALLATION GUIDE
For the full installation manual, visit www.dsc.com
Warning: This manual contains information on limitations regarding product use and func-
tion and information on the limitations as to liability of the manufacturer. The entire manual
should be carefully read.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LE4020 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DSC LE4020

Summary of Contents for DSC LE4020

  • Page 1 LTE / 3G CELLULAR ALARM COMMUNICATOR INSTALLATION GUIDE For the full installation manual, visit www.dsc.com Warning: This manual contains information on limitations regarding product use and func- tion and information on the limitations as to liability of the manufacturer. The entire manual...

  • Page 2: Safety Information

    Some of the materials that are found within the battery could become toxic if not disposed of properly and may affect the environment. This equipment, LE4020/LE4020CF, is fixed and shall be installed by Service Persons only (Service Person is defined as a person having the appropriate technical training and experience necessary to be aware of haz- ards to which that person may be exposed in performing a task, and of measures available to minimize the risks to that person or other persons).

  • Page 3: Technical Specifications

    PSTN connected): Average Current (standby without 55 mA* PSTN connected): Transmission Current (no 225 mA* battery): * Plus any current drawn from the LE4020/LE4020CF AUX+ terminal. Each of the four PGM outputs can be loaded up to 50 mA (max)
  • Page 4 Battery charge current limit: 360 mA NOTE: Battery must be replaced every 3 to 5 years. NOTE: When using the battery, use DSC  ADP 1310-NAU(W) or ADP 1320-NAU power adapter Operating frequency - 3G 850 MHz / 1900 MHz (UMTS/HSPA): For LE4020 operating frequencies, see table below.

  • Page 5: C24 Communications Enrollment

    If the signal strength is too low (bottom signal LED off or flashing), the LE4020/LE4020CF will proceed to Step 3: scan for, and attach to, carriers with sufficient signal strength. If the LE4020/LE4020CF is con- nected to a carrier with sufficient signal strength (minimum of bottom signal strength LED on solid), it pro- ceeds to Step 4 .
  • Page 6 3G4010/LE4010 Wiring Diagram...

  • Page 7: Regulatory Information

    N O W A R R A N TY - D S C P RO V ID ES TH E S O F TWA RE “A S IS ” LE4020 P roduct Identifier U S : X X X X WITH O U T WA RRA N TY .

  • Page 8: Warranty

    Incidence of Harm Conditions to Void Warranty If this equipment LE4020/LE4020CF caus es harm to the telephone netw ork, the telephone company w ill notify you in advance that temporary dis - This w arranty applies only to defects in parts and w orkmans hip relating to continuance of s ervice may be required.
