Doc. Title
ST3940 User Manual
Concerning:
Features and how to configure ST3940
Personal / Asset Tracker
ST3940
User Manual
Rev.
Date (dd-mm-yy)
1.00
07-05-18
15
0
Page of Pages
1 of 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST3940 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SunTech ST3940

  • Page 1 Doc. Title ST3940 User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.00 07-05-18 1 of 16 Features and how to configure ST3940 Personal / Asset Tracker ST3940 User Manual...
  • Page 2: Table Of Contents

    Rev. Date (dd-mm-yy) Page of Pages 1.00 07-05-18 2 of 16 Features and how to configure ST3940 Table of Contents Revision History ..............................4 1. Introduction ..............................4 2. Key Features ..............................5 2-1. GSM/GPRS Specifications ........................6 2-2. GPS Specifications ..........................8 2-3.
  • Page 3 Suntech International Ltd., which is hereinafter referred to as “Suntech”. The information in this manual is believed to be accurate and reliable at the time of releasing. We, at Suntech, also assume no responsibility for any damage or loss resulting from the use of this manual, and expressly...
  • Page 4: Revision History

    Without any efforts for connecting wires, the ST3940 (hereinafter referred to as ‘device’) works autonomously with its built-in battery. If users want to track an object with the ST3940, all they have to do is just simply put it into the box or the carry bag where the object is contained. And then, users can track the locations of such an object and receive an alert if the object enters or leaves a pre-defined zone.
  • Page 5: Key Features

    Built-in motion detector for alarming  ST3940 with its CradleWaterproof in compliance with IP66  ST3940 without its Cradle  Waterproof in compliance with IP65  Baby’s palm-sized versatile mini tracker  Fixed asset tracking in real time with Standby Current less than 8uA.
  • Page 6: Gsm/Gprs Specifications

    ST3940 User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.00 07-05-18 6 of 16 Features and how to configure ST3940 2-1. GSM/GPRS Specifications Item Description Battery Rechargeable 3.7V, Li-ion Battery- 1500mAh Motion Detection Built-in 3-axis Acceleration sensor Standby time *with 1,500mA/h Li-ion battery Standby Time with GSM “On/Off”...
  • Page 7 Doc. Title ST3940 User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.00 07-05-18 7 of 16 Features and how to configure ST3940 Approval CE, FCC...
  • Page 8: Gps Specifications

    ST3940 User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.00 07-05-18 8 of 16 Features and how to configure ST3940 2-2. GPS Specifications Item Description 56-channel U-blox7 engine Receiver Type GPS & QZSS L1 C/A, GLONASS L1OF, Galileo* E1B/L1, Compass* ready...
  • Page 9: Operational Features

    ST3940 User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.00 07-05-18 9 of 16 Features and how to configure ST3940 2-3. Operational Features Item Description Configuration either by SMS or PC Parameter Change either by SMS or GPRS Command /Control...
  • Page 10: Accessories

    Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.00 07-05-18 10 of 16 Features and how to configure ST3940 3. Accessories The ST690 has two accessories:  Wall Charger  USB Cable (for charging and setting) 4. How to insert SIM card by step There are 5 steps in inserting a SIM card into the ST690 as shown below in the pictures.
  • Page 11: Charging Battery

    If this error occurs continuously, please replace the battery or contact Suntech. <Caution!!> The ST3940 (device) should be charged by using the USB cable that Suntech provides the user with. In such a case, however, Suntech does not guarantee that charging the device can be done completely. It is highly recommended that the users, in charging the device, should use the battery charger provided by Suntech.
  • Page 12: Appearance

    Doc. Title ST3940 User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.00 07-05-18 12 of 16 Features and how to configure ST3940 6. Appearance...
  • Page 13: How To Operate

    Features and how to configure ST3940 7. How to operate The ST3940,a multifunctional battery-powered mini GPS tracker, is ideal for tracking personnel, valuable assets like merchandises that are delivered by putting it onto an object. While tracking, it reports location information about the object at a predefined interval and alerts if it detects motion of the object.
  • Page 14 Date (dd-mm-yy) Page of Pages 1.00 07-05-18 14 of 16 Features and how to configure ST3940 Charging Turn On Mode As soon as a device in a status of power off is connected with a charger, only charging the device starts being processed. But, GSM session does not work. GPS LED is on.
  • Page 15 Date (dd-mm-yy) Page of Pages 1.00 07-05-18 15 of 16 Features and how to configure ST3940 Blue& Red GSM network & Operating Status indicator LEDs (2 colors) Right after the device is turned on, the blue LED starts to blink as below. Five (5) minutes after the blue LED starts to blink, it is turned off automatically to save battery.
  • Page 16: Contacts

    Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.00 07-05-18 16 of 16 Features and how to configure ST3940 Battery Battery indicator LEDs (3 colors) Normally, it blinks shortly to indicate the battery level for user as described below.  Red LED blinks twice shortly. under 10% of the full capacity ...
