SunTech ST3500 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
ST3500
User Manual
Suntech International Ltd.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ST3500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SunTech ST3500

Summary of Contents for SunTech ST3500

  • Page 1 ST3500 User Manual Suntech International Ltd.
  • Page 2 ST3500 User Manual 1. Introduction This document describes features, protocols and detail operation of ST3500. If there is another operation description document for special buyer to customize or model and the contents of the document is different with this, customizing document should be applied for special buyer.
  • Page 3 ST3500 User Manual Emergency is the first to be sent after recovering WCDMA condition. 2-3. Setting Parameter Parameters of device can be changed by WCDMA or SMS, and some control can be realized also in the same way. Detail protocols are described in Chapter 4.
  • Page 4 DEV_ID Field 1 Field 2 … Field n Field Definitions Remark String “ST3500” + Command type DEV_ID 6 char. Device ID of AVL “02” Protocol Version. This is fixed with “02”. Field 1 ~ n String Contents Device ID is unique number of each device that consists of 6digits.
  • Page 5 ST3500 User Manual DEV_ID 6 char. Device ID of AVL “001” Software version that the device has. Field 1 ~ n String Contents 4. Commands When the device is received a command, it responds with response string and changes some parameters or acts related operation.
  • Page 6 ST3500 User Manual For no use, it should be empty. PIN_NO String PIN Number to release PIN lock if it is enabled <example> [command] ST3500NTW;850000;02;0;internet;;;111.111.111.111;8600;;;; [response] ST3500NTW;Res;850000;010;0;internet;;; 111.111.111.111;8600;;;; ST3500NTW;Res;850000;010;A1;tim.br;tim;tim; 111.111.111.111;8600;;;; <notes> ** If network does not require User ID and Password, these fields should be empty.
  • Page 7 ST3500 User Manual If 0, report in driving will be sent only one time when vehicle starts driving. String Interval for sending status report in emergency mode Range : 0 ~ 9999 If 0, emergency report will be sent only one time when emergency state occurs.
  • Page 8 ST3500 User Manual DEV_ID IGNITION IN1_TYPE IN2_TYPE IN3_TYPE IN1_CHAT IN2_CHAT IN3_CHAT OUT1_TYPE OUT2_TYPE OUT1_ACTIVE OUT2_ACTIVE PULSE1_NO PULSE1_ON PULSE1_OFF PULSE2_NO PULSE2_ON PULSE2_OFF IN4_TYPE IN5_TYPE IN4_CHAT IN5_CHAT BAUD ● Definition : Set parameter related event. Field Definitions Unit Remark “ST3500EVT” Command type DEV_ID 6 char.
  • Page 9 ST3500 User Manual OUT1_TYPE ‘0’ ~ ‘5’ 0 = GPIO 1 = immobilizer 2 = Immobilizer & Auto active Auto active means immobilizer activated automatically when the vehicle starts parking. 3 = Pulse 4 = LED Out for indicating call status. Refer 7-2-3.
  • Page 10 ST3500 User Manual <example> [command] ST3500EVT;850000;02;1;60;0;3;2;2;30;20;20;1;0;1;0;0;0;0;0;0;0;0;0;0;0;0 [response] ST3500EVT;Res;850000;010;1;60;0;3;2;2;30;20;20;1;0;1;0;0;0;0;0;0;0;0;0;0;0;0 <notes> ** If IGNITION is set to ‘0’, device doesn’t check driving or parking state of the vehicle. It reports status string with idle mode always, and cannot support parking lock and the service that enters sleep or deep sleep automatically when the vehicle is parked.
  • Page 11 ST3500 User Manual IN1_TYPE ‘0’ ~ ‘5’ 0 = Falling Edge 1 = Rising Edge 2 = Both Edge (Falling & Rising) 3 = Panic Button 4 = Call1 Button 5 = Call 2 Button 6 = Reserved 7 = Anti-Theft Button 13 = Disable Immobilizer if it’s activated by jammer...
  • Page 12 ST3500 User Manual SMS_MT4 IN_CALL_LOCK CALL_MT1 CALL_MT2 CALL_MT3 CALL_MT4 CALL_MT5 CALL_MO1 CALL_MO2 ● Definition : Set parameters related SMS or Call. Field Definitions Unit Remark “ST3500WCD Command type MA” DEV_ID 6 char. Device ID “02” Protocol Version SMS_LOCK ‘0’ or ‘1’...
  • Page 13 ST3500 User Manual 4-5. Service Parameter Setting DEV_ID PARKING_LOCK SPEED_LIMIT PWR_DN CON_TYPE GROUP_SEND MP_CHK ANT_CHK BAT_CHK M_SENSOR CALL GEO_FENCE DATA_LOG ANTITHFT_CNT1 ANTITHFT_CNT2 JAM_DET JAM_CHK_DIST JAM_CHK_TM ● Definition : Set parameters related report. Field Definitions Unit Remark “ST3500SVC” Command type DEV_ID 6 char.
  • Page 14 ST3500 User Manual GROUP_SEND ‘0’ or ‘1’ Group Send for stored data 0 : Disable 1 : Enable. One packet can include up to 5 reports. Group send is explained below. MP_CHK ‘0’ or ‘1’ Main Power Disconnection Check Disable (0) / Enable (1) ANT_CHK ‘0’...
  • Page 15 ST3500 User Manual CON_TYPE 1. KEEP_CON : The device keeps TCP connection always and can receives a command by WCDMA. 2. KEEP_DISCON : The device connects TCP connection when the data is sent. After sending, the device disconnects WCDMA and TCP connection if it estimates there is no data for sending within 3minutes.
  • Page 16 ST3500 User Manual DEV_ID SVR_TYPE B_SVR_TYPE UDP_ACK DEV_PORT ● Definition : Setting additional parameter requested. Field Definitions Unit Remark “ST3500ADP” Command type DEV_ID 6 char. Device ID “02” Protocol Version SVR_TYPE ‘T’ / ‘U’ Server Protocol Type T : TCP...
  • Page 17 ST3500 User Manual This command can be applied from software version 22. ACK in case of UDP UDP is protocol that doesn’t check whether the data is transmitted successfully. So, the device checks completion of sending with ACK depending on UDP_ACK type.
  • Page 18 ST3500 User Manual “02” Protocol Version CHR_STOP_THRES_12 String Voltage value to stop backup battery charging in 12V vehicle. DECIDE_BAT_12 String Voltage value to check whether the vehicle’s battery is 12V. OPERATION_STOP_THRES_12 String Voltage value to protect vehicle battery. The device operation stops if car battery voltage is lower than this value in vehicle that has 12V power.
  • Page 19 ST3500 User Manual Recommend : 600 ( 10 min.) MOTION_THRES String Step Detection level of shock violation. Range : 0.04 ~ 2.0 Recommend : 0.04 SHOCK_THRES String Step Detection level of shock violation. Range : 0.04 ~ 2.0 Recommend : 0.04...
  • Page 20 ST3500 User Manual 4-11. Control Command DEV_ID CMD_ID ● Definition : Controls some functions. Field Definitions Unit Remark “ST3500CMD” Command type DEV_ID 6 char. Device ID ‘01’ Protocol Version CMD_ID String Control command content Caution : If it’s not correct the Unit ID, ignored.
  • Page 21 ST3500 User Manual device. <example> [command] ST3500CMD;850000;02;Reset [response] ST3500CMD;Res;850000;010;Reset 4-11-3. Preset ● Definition : Reset all of parameters. Field Definitions Unit Remark CMD_ID “Preset” Report parameter setting values and current device status. Response includes network, report, event, WCDMA and service parameters. It includes status of device, also.
  • Page 22 ST3500 User Manual 2 = Deep sleep 1 = Backup battery is connected. Field Definitions Unit Remark CMD_ID “PresetA” Report all parameters including additional parameter. <example> [command] ST3500CMD;850000;02;PresetA [response] ST3500CMD;Res;850000;010;PresetA; NTW;0;internet;;;111.111.111.111;8600;;;;1234; RPT;60;180;120;60;3;0;0;;;; EVT;1;60;0;3;2;2;30;20;20;1;1;1;0;0;0;0;0;0;0;0;0;0;0;0; WCDMA;0;;;;;0;;;;;;;; SVC;1;120;0;0;0;0;1;1;1;0;0;0;0; ADP;U;T;2;9000;0;0;0;0;0;0; DEV;0;0;0;0;0;0;0;0 <notes> ** This command can be applied from software version 22.
  • Page 23 ST3500 User Manual Field Definitions Unit Remark CMD_ID “AckEmerg” Acknowledgement of emergency report. The device will stop emergency reports if it is in emergency state. <example> [command] ST3500CMD;850000;02;AckEmerg [response] ST3500CMD;Res;850000;010;AckEmerg 4-11-5. Enable1 ● Definition : Active Output1. Field Definitions Unit...
  • Page 24 ST3500 User Manual [response] ST3500CMD;Res;850000;010;Disable1NoUse (in case that IN type is set to ‘No Use’). <notes> ** Output1 line goes to inactive status. 4-11-9. Request IMSI ● Definition : Request the unique SIM ID. Field Definitions Unit Remark CMD_ID “ReqIMSI”...
  • Page 25 ST3500 User Manual [response] ST3500CMD;Res;850000;010;ReqVer;ST3500E_SAMPLE_STBASE_001 4-11-12. Erase All ● Definition : Erase all of data in buffer. Field Definitions Unit Remark CMD_ID “EraseAll” Erase saved all reports and disable outputs. This is needed to initialize just before device is delivered to a customer.
  • Page 26 ST3500 User Manual <example> [command] ST3500CMD;850000;02;InitMsgNo [response] ST3500CMD;Res;850000;010;InitMsgNo 4-11-23. Reboot ● Definition : reboot unit. Field Definitions Unit Remark CMD_ID “Reboot” Reboot device. <example> [command] ST3500CMD;850000;02;Reboot [response] ST3500CMD;Res;850000;010;Reboot 4-11-24. Request SIM IP Address ● Definition : Request of the local IP address in SIM card.
  • Page 27 ST3500 User Manual 4. Trouble Shooting (LED Indicator) 4.1 Blue LED: Indicates WCDMA status. WCDMA Blink Count Remarks Normal Server Com. Error <Possible Cause> 1. Server or network parameter is wrong. 2. Server is closed. 3. Temporary network barrier WCDMA Com.
