SunTech ST940 User Manual

Personal/asset
Hide thumbs Also See for ST940:
Table of Contents

Advertisement

Quick Links

Doc. Title
ST940 User Manual (STGPS)
Concerning:
Features and how to configure ST940
Personal / Asset Tracker

User Manual

Rev.
ST940
Date
Page of Pages
1.0
14-10-27
0
1 of 28

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST940 and is the answer not in the manual?

Questions and answers

Related Manuals for SunTech ST940

Summary of Contents for SunTech ST940

  • Page 1: User Manual

    Doc. Title ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 1 of 28 Features and how to configure ST940 Personal / Asset Tracker ST940 User Manual...

  • Page 2: Table Of Contents

    Concerning: Rev. Date Page of Pages 14-10-27 2 of 28 Features and how to configure ST940 Table of Contents 1. Introduction ..............................3 2. Features ................................5 2-1. GSM/GPRS specification ........................6 2-2. GPS specification ..........................7 2-3. Available operation / Features ......................8 3.
  • Page 3 Suntech International Ltd., which is hereinafter referred to as “Suntech”. The information in this manual is believed to be accurate and reliable at the time of releasing. We, at Suntech, also assume no responsibility for any damage or loss resulting from the use of this manual, and expressly disclaim any...

  • Page 4: Introduction

    Without any efforts for connecting wires, the ST940 works autonomously with its built-in battery. If users want to track an object with the ST940, all they have to do is just simply put it into the box or the carry bag where the object is contained.

  • Page 5: Features

    5 of 28 Features and how to configure ST940 algorithms and motion checking. *In case the ST940 is placed inside a metal container, it may not work. Position of the IMEI label the center of the back cover. 2. Key Features ...

  • Page 6: Gsm/Gprs Specification

    Doc. Title ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 6 of 28 Features and how to configure ST940  2-1. GSM/GPRS Specifications Item Description Battery Rechargeable 3.7V, Li-ion Battery- 1500mAh Motion Detection Built-in 3-axis Acceleration sensor...

  • Page 7: Gps Specification

    ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 7 of 28 Features and how to configure ST940 2-2. GPS Specifications Item Description 56-channel U-blox7 engine Receiver Type GPS & QZSS L1 C/A, GLONASS L1OF, Galileo* E1B/L1, Compass* ready...

  • Page 8: Available Operation / Features

    Doc. Title ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 8 of 28 Features and how to configure ST940 2-3. Operational Features Item Description Configuration either by SMS or PC either by SMS or GPRS Parameter Change...

  • Page 9: Accessories

    USB Cable (for charging and setting) 4. How to insert SIM card by step There are 5 steps in inserting a SIM card onto the ST940 as shown below in the pictures. Step 1.: Please, unscrew SIM cover. Step 2.: Please, insert SIM #1.

  • Page 10: Charging Battery

    5. Remove the travel adapter from the device. It is highly recommended that the rechargeable battery should be charged completely before using the device. Connect the ST940 to its charger cable supplied by Suntech and charge it for 5 hours.

  • Page 11: Appearance

    6. Appearance 7. How to operate The ST940, a multifunctional battery-powered mini GPS tracker, is ideal for tracking personnel, valuable assets like merchandises that are delivered by putting it onto an object. While tracking, it reports location information about the object at a predefined interval and alerts if it detects motion of the object.
  • Page 12 Date Page of Pages 14-10-27 12 of 28 Features and how to configure ST940 Power Turn On If you press POWER button for more than 3 seconds, the device will be turned on. When the power is on, LEDs blink as below.

  • Page 13: Commands

    Date Page of Pages 14-10-27 13 of 28 Features and how to configure ST940 Red LED GPS status indicator Right after the device is turned on, the red LED starts to blink as below. Five (5) minutes after the red LED starts to blink, it is turned off automatically to save electricity. If you turn on the power button again, the red LED will be on just for short time, for some seconds, to show you the current status of the GPS connectivity.
  • Page 14 Doc. Title ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 14 of 28 Features and how to configure ST940 “ST940” Model Name “NETWORK COMMAND Command Type DEV_ID 9 char. 9 digits ID of device. It is a part of IMEI.
  • Page 15 Doc. Title ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 15 of 28 Features and how to configure ST940 B_SERVER_IP String Backup Server IP Address B_SERVER_PORT String Backup Server Port <Example> [command] ST940;NETWORK;123456789;1;internet;suntech;1234;111.111.111.111;8800;111.111.111.111;8801;1234;0 [response] ST940;RES;NETWORK;123456789;1;internet;suntech;1234;111.111.111.111;8800;111.111.111.111;8801;1234;0 <Notes> If the SIM does not require User ID and Password, these fields should be empty.
  • Page 16 Rev. Date Page of Pages 14-10-27 16 of 28 Features and how to configure ST940 ‘alive report’. 3 : ACK when the server receives ‘emergency report’. Command response does not need ACK. Device’s port for receiving command from UDP server.
  • Page 17 Rev. Date Page of Pages 14-10-27 17 of 28 Features and how to configure ST940 ST940;CGF;123456789;1;36.923548;127.309570;29;1;1 [response] ST940;RES;CGF;123456789;1;1;36.923548;127.309570;29;1;1 How to set ‘Report Parameters’ ● The following table shows how to set intervals of location report, alert and how to set sensor value to sense if any motion is made.
  • Page 18 Rev. Date Page of Pages 14-10-27 18 of 28 Features and how to configure ST940 [command] ST940;REPORT; 123456789;180;60;60;3;0.5;0;0 [response] ST940;RES;REPORT; 123456789;180;60;60;3;0.5;0;0 <Notes> 1. Driving or Parking is decided by Motion Sensor. If CARRY_THRES is equal to zero, it cannot recognize Driving.
  • Page 19 Date Page of Pages 14-10-27 19 of 28 Features and how to configure ST940 Off (Power off) ● The following table shows how to make a command for power off remotely for a time period of the “the minutes” predefined.
  • Page 20 Doc. Title ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 20 of 28 Features and how to configure ST940 by using the ‘power key’. <Example> [command] ST940;FUNCTION;123456789;0 [response] ST940;RES;FUNCTION;123456789;0;1...
  • Page 21 Concerning: Rev. Date Page of Pages 14-10-27 21 of 28 Features and how to configure ST940 Erase Reports ● The following table shows how to make a command to erase all the reports which have been stored. Field Marks Value Meaning “ST940”...
  • Page 22 Concerning: Rev. Date Page of Pages 14-10-27 22 of 28 Features and how to configure ST940 ACK (Server Acknowledgement about Alert) ● The following table shows how to make a command in order to stop sending alert. Field Marks Value Meaning “ST940”...
  • Page 23 ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 23 of 28 Features and how to configure ST940 <Example> [command] ST940;InitDist;123456789 [response] ST940;RES; InitDist;123456789 ResetMsgNo ● The following table shows how to initialize the message numbers of the reports: Field...
  • Page 24 Doc. Title ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 24 of 28 Features and how to configure ST940 <Example> [command] ST940;InitCircleGeo;123456789 [response] ST940;RES;InitCircleGeo;123456789 TurnOff ● Definition: Command for target power off . Field Marks Value Meaning “ST940”...

  • Page 25: Reports

    ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 25 of 28 Features and how to configure ST940 9. Reports This Chapter explains how device makes a report and sends it to its server. Location Report Field Marks Meaning “ST940”...
  • Page 26 Doc. Title ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 26 of 28 Features and how to configure ST940 Emergency Report Field Marks Meaning “ST940” Model Name “Emergency” Report Type or “0002” RPT_TYPE DEV_ID 9 char. 9 digits ID of device. It is a part of IMEI.
  • Page 27 Doc. Title ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 27 of 28 Features and how to configure ST940 Alert when battery level is low Field Marks Meaning “ST940” Model Name “Low Battery” Report Type or “0003”...

  • Page 28: Revision History

    Doc. Title ST940 User Manual (STGPS) Concerning: Rev. Date Page of Pages 14-10-27 28 of 28 Features and how to configure ST940 Alert Report Field Marks Meaning “ST940” Model Name “Alert” Report Type or “0005” RPT_TYPE DEV_ID 9 char. 9 digits ID of device. It is a part of IMEI.
