ProtoAir FPA-W34
Start-up Guide
For Interfacing Eaton Products:
Greengate, iLumin and Fifth Light
To Building Automation Systems:
BACnet MS/TP, BACnet/IP, Modbus TCP/IP and
Modbus RTU
APPLICABILITY & EFFECTIVITY
Explains ProtoAir hardware and installation.
The instructions are effective for the above as of June 2017.
Document Revision: 1.A
Auto Discovery
Template Revision: 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProtoAir FPA-W34 and is the answer not in the manual?

Questions and answers

Related Manuals for Eaton ProtoAir FPA-W34

Summary of Contents for Eaton ProtoAir FPA-W34

  • Page 1 ProtoAir FPA-W34 Start-up Guide For Interfacing Eaton Products: Greengate, iLumin and Fifth Light To Building Automation Systems: BACnet MS/TP, BACnet/IP, Modbus TCP/IP and Modbus RTU APPLICABILITY & EFFECTIVITY Explains ProtoAir hardware and installation. The instructions are effective for the above as of June 2017.
  • Page 2 Thank you for purchasing the ProtoAir for Eaton. Please call Eaton for Technical support of the ProtoAir product. SMC does not provide direct support. If Eaton needs to escalate the concern, they will contact Sierra Monitor Corporation for assistance. Support Contact Information:...

  • Page 3: Fifth Light: Review System Status And Potential Errors. (Section

    2. Set the Device COM setting that will be connected to ProtoAir. (Section 3.3) 3. Connect the ProtoAir FPA-W34 3 pin RS-485 port to the Field Protocol cabling (Section 4.1) 4. Connect Power to the ProtoAir 3 pin connector. (Section 4.2) 5.

  • Page 4: Table Of Contents

    Eaton ProtoAir Start-Up Guide TABLE OF CONTENTS Table of Contents ............................4 List of Figures ............................. 6 Certification ............................8 ® BTL Mark - BACnet Testing Laboratory ..................8 Introduction ............................9 ProtoAir Gateway ..........................9 Equipment Setup ..........................10 Record Identification Data ......................
  • Page 5 Appendix B.11. Physical Dimensions for FPA-W34 ................47 Appendix B.12. Kaspersky Endpoint Security 10 ..................48 Appendix C Vendor Information – Eaton ....................49 Appendix C.1. 3264640000 Greengate Mappings to BACnet and Modbus ..........49 Appendix C.2. 4864643204 Greengate Mappings to BACnet and Modbus ..........51 Appendix C.3.

  • Page 6: List Of Figures

    Eaton ProtoAir Start-Up Guide LIST OF FIGURES Figure 1: ProtoAir Part Numbers ......................... 10 Figure 2: Supported Point Count Capacity ....................10 Figure 3: Greengate Point Count per Device ....................10 Figure 4: iLumin Point Count per Device ....................10 Figure 5: Connection from ProtoAir to RS-485 Field Network ..............
  • Page 7 Eaton ProtoAir Start-Up Guide Figure 50: DIN Rail ............................46 Figure 51: ProtoAir FPA-W34 Dimensions ....................47 Figure 52: Kaspersky ES10 Settings ......................48 Figure 53: Web Anti-Virus Trusted URLs ....................48 Figure 54: Specifications ..........................65 List of Figures...

  • Page 8: Certification

    Eaton ProtoAir Start-Up Guide CERTIFICATION ® 1 BTL Mark - BACnet Testing Laboratory The BTL Mark on ProtoAir is a symbol that indicates that a product has passed a series of rigorous tests conducted by an independent laboratory which verifies that the product correctly implements the BACnet features claimed in the listing.

  • Page 9: Introduction

    INTRODUCTION ProtoAir Gateway The ProtoAir gateway is a high-performance, multi-protocol IIoT gateway that is preconfigured to auto- discover any of Eaton’s products (hereafter called “device”) connected to the ProtoAir and automatically ® configures them for BACnet MS/TP, BACnet/IP, Modbus TCP/IP or Modbus RTU.

  • Page 10: Equipment Setup

    Eaton ProtoAir Start-Up Guide EQUIPMENT SETUP Record Identification Data Each ProtoAir has a unique part number located on the side or the back of the unit. This number should be recorded, as it may be required for technical support. The numbers are as follows:...

  • Page 11: Interfacing Protoair To Device

    Eaton ProtoAir Start-Up Guide INTERFACING PROTOAIR TO DEVICE Wiring Field Port to RS-485 BMS Network  Connect the RS-485 network wires to the 3-pin RS-485 connector on ProtoAir FPA-W34 as shown in Figure Use standard grounding principles for RS-485 GND ...

  • Page 12: Power Up Protoair

    Eaton ProtoAir Start-Up Guide Power Up ProtoAir Check power requirements in the table below: Power Requirement for ProtoAir External Gateway Current Draw Type ProtoAir Family 12V DC 24V DC FPA – W34 (Typical) 170mA 100mA FPA – W34 (Maximum) 240mA 140mA NOTE: These values are ‘nominal’...

  • Page 13: Connect The Pc To The Protoair Over Ethernet

    Eaton ProtoAir Start-Up Guide CONNECT THE PC TO THE PROTOAIR OVER ETHERNET Connecting to the ProtoAir via the Ethernet Port  Connect a CAT5 Ethernet cable (straight through or cross-over) between the local PC and ProtoAir. Ethernet Port Figure 9: Ethernet Port ...

  • Page 14: Using The Fieldserver Toolbox To Discover And Connect To The Protoair

    Eaton ProtoAir Start-Up Guide Using the FieldServer Toolbox to Discover and Connect to the ProtoAir  Install the FS Toolbox application from the USB drive or get it from the Sierra Monitor website.  Use the FS Toolbox to find the ProtoAir IP Address and connect for configuration.

  • Page 15: Select System

    Eaton ProtoAir Start-Up Guide Select System  After setting the PC on the same subnet as the ProtoAir, open a web browser on the PC and enter the IP Address of the ProtoAir; the Ethernet default address is 192.168.1.24. The Select System Page will appear the first time the FieldServer is accessed.

  • Page 16: Updating Network Settings

    Eaton ProtoAir Start-Up Guide Updating Network Settings From the Web Configurator, Click the Network Settings tab to open the Network Settings page for the ProtoAir. Figure 12: IP Address Settings via Web GUI  Modify the IP Address (N1 IP Address field) of the ProtoAir Ethernet port.

  • Page 17: Configuring The Protoair

    Eaton ProtoAir Start-Up Guide CONFIGURING THE PROTOAIR Select BMS Protocol  Going back to the Discovery and Configuration tab, and press BMS Settings button to view/ change the Building Management System (BMS) Settings.  Select BACnet/IP, BACnet MS/TP, Modbus TCP/IP, or Modbus RTU protocols.

  • Page 18: 6.1.1.1 Set Device Instance For Each Lighting Panel Attached To The Device

    Eaton ProtoAir Start-Up Guide 6.1.1.1 Set Device Instance for each Lighting Panel Attached to the Device The Device Instance can be set independently of the site administrator. As an example:  A Device Instance is a BACnet Node-ID which is obtained by the network administrator.

  • Page 19: 6.1.1.2 Bacnet Ms/Tp: Setting The Mac Address Bacnet Network

    Eaton ProtoAir Start-Up Guide 6.1.1.2 BACnet MS/TP: Setting the MAC Address BACnet Network  Only 1 MAC address is set for ProtoAir regardless of how many light panels are connected to ProtoAir.  Set the BACnet MS/TP MAC address of the ProtoAir to a value between 1 to 127 (MAC Master Addresses);...

  • Page 20: Greengate/Ilumin: Discover And Configure Light Panels Connected To The Protoair

    Eaton ProtoAir Start-Up Guide Greengate/iLumin: Discover and Configure Light Panels Connected to the ProtoAir  For Greengate, click on the “Start Discovery” button to enter the port, network address, panel address and number of panels for the device. Figure 16: Greengate Discovery Window ...

  • Page 21: Figure 18: Discovery Progress Bar

    Eaton ProtoAir Start-Up Guide After entering the device details, click on the “Start Discovery” button and the discovery progress bar will display. Discovering a device may take a few minutes depending on the number of items it contains. Figure 18: Discovery Progress Bar ...

  • Page 22: Figure 21: View Light Panel Parameters

    Eaton ProtoAir Start-Up Guide By clicking on a light panel, parameters for that panel will be shown. Figure 21: View Light Panel Parameters Clicking on a light displays and allows editing of the preconfigured BACnet parameters. Figure 22: View & Edit BACnet Parameters on a Lighting Panel ...

  • Page 23: Figure 24: Saved Configuration

    Eaton ProtoAir Start-Up Guide  When this process is complete, the items on the tree will change from green to black to show that they have been configured. Figure 24: Saved Configuration  In order to clear a configuration, click on the “Clear Configuration” button. An additional option to clear all other device configurations will appear.

  • Page 24: Fifth Light: System Status

    Eaton ProtoAir Start-Up Guide Fifth Light: System Status NOTE: Fifth Light configuration must be done on the Fifth Light panel. For Instructions, refer to the Eaton 5 Light Panel manual. The ProtoAir allows BMS settings to be changed (BBMD settings, Public IP Address, Public IP Port, Router Network Number, Network Number and IP Port) and Fifth Light Panel system information to be reviewed.

  • Page 25: Figure 28: Switch To Another Product

    Eaton ProtoAir Start-Up Guide Click the “Switch to another product” button to clear the current configuration and restart. Figure 28: Switch to Another Product Page 25 of 66...

  • Page 26: Bacnet: Setting Device Instance Offset To Assign Specific Device Instances

    Device Instance (desired) = Offset + Node_ID NOTE: Node_ID is gathered from the Eaton device. For example, if the desired Device Instance for the device 1 is 80,002 and the following is true: Device 1 has a Node-ID of 1...

  • Page 27: Using The Embedded Bacnet Explorer

    Eaton ProtoAir Start-Up Guide USING THE EMBEDDED B ACNET EXPLORER  To access the embedded BACnet Explorer, go to the FS-GUI page and click the BACnet Explorer button. Figure 31: FS-GUI BACnet Explorer Button  Then login to the BACnet Explorer page using the supplied username and password.

  • Page 28: Discover Device List

    Eaton ProtoAir Start-Up Guide Discover Device List  From the BACnet Explorer landing page, click on the BACnet Explorer button on the left side of the screen to go to the BACnet Explorer page. Figure 33: BACnet Explorer Page ...

  • Page 29: View Device Details And Explore Points/Parameters

    Eaton ProtoAir Start-Up Guide NOTE: Allow the devices to populate before interacting with the device list for optimal performance. Any discovery or explore process will cause a green message to appear in the upper right corner of the browser to confirm that the action is complete.

  • Page 30: Figure 37: Full Device Sub-Items

    Eaton ProtoAir Start-Up Guide  To view the full details of a device, go back to highlighting the device directly (in Figure 37 “50001”) and click the Explore button or double-click the device/object. Figure 37: Full Device Sub-items Now additional device details are viewable; however, the device can be explored even further ...

  • Page 31: Figure 39: Additional Device Details

    Eaton ProtoAir Start-Up Guide  Then click on the Explore button or double-click the device object. Figure 39: Additional Device Details A full list of the device details will appear on the right-side window. If changes are expected since the last...

  • Page 32: 8.2.1 Edit The Present Value Field

    Eaton ProtoAir Start-Up Guide 8.2.1 Edit the Present Value Field The only recommended field to edit via BACnet Explorer is the device’s present value field. NOTE: Other BACnet properties are editable (such as object name, object description, etc.); however, this is not recommended because the BACnet Explorer is a discovery tool not a Building Management System (BMS).

  • Page 33: Figure 42: Updated Present Value

    Eaton ProtoAir Start-Up Guide  Enter the appropriate change and click write. A check will appear inside the save button and the window will close. When the BACnet Explorer page appears the present value will be changed as specified. Figure 42: Updated Present Value...

  • Page 34: Appendix A Useful Features

    Eaton ProtoAir Start-Up Guide Appendix A Useful Features Appendix A.1. SSL/TLS for Secure Connection SSL/TLS (Secure Sockets Layer/Transport Layer Security) is a security technology for establishing an encrypted connection between a server and a client. This allows the secure transfer of data across untrusted networks.

  • Page 35: Appendix A.1.1.2. Limiting Client Access

    Eaton ProtoAir Start-Up Guide Appendix A.1.1.2. Limiting Client Access In addition to TLS_Port parameter also add Validate_Client_Cert in the connections section of the configuration file and set it to “Yes”. Connections Adapter , Protocol , TLS_Port , Validate_Client_Cert , Modbus/TCP...

  • Page 36: Appendix A.1.1.4. Certificate Validation Options

    Eaton ProtoAir Start-Up Guide Appendix A.1.1.4. Certificate Validation Options If connections must be limited to only a particular domain (vendor devices), include Check_Remote_Host to specify the domain/host name. Connections Adapter , Protocol , TLS_Port , Validate_Client_Cert , Cert_Authority_File , Check_Remote_Host...

  • Page 37: Appendix A.1.2. Configuring Fieldserver As Ssl/Tls Client

    Eaton ProtoAir Start-Up Guide Appendix A.1.2. Configuring FieldServer as SSL/TLS Client The following Node configurations set the FieldServer to open a secure Modbus/TCP connection to Server at IP Address 10.11.12.13 on port 1502. Appendix A.1.2.1. Simple Secure Client Configuration Add Remote_Node_TLS_Port parameter in the nodes section of the configuration file and set to a port number between 1 –...

  • Page 38: Appendix B Troubleshooting Tips

    Eaton ProtoAir Start-Up Guide Appendix B Troubleshooting Tips Appendix B.1. Communicating with the ProtoAir over the Network  Confirm that the network cabling is correct.  Confirm that the computer network card is operational and correctly configured.  Confirm that there is an Ethernet adapter installed in the PC’s Device Manager List, and that it is configured to run the Modbus TCP/IP protocol.

  • Page 39: Appendix B.2. Lost Or Incorrect Ip Address

    Eaton ProtoAir Start-Up Guide Appendix B.2. Lost or Incorrect IP Address  Ensure that FieldServer Toolbox is loaded onto the local PC. Otherwise, download the FieldServer-Toolbox.zip via the Sierra Monitor Resource Center Software Downloads.  Extract the executable file and complete the installation.

  • Page 40: Appendix B.3. Viewing Diagnostic Information

    Eaton ProtoAir Start-Up Guide Appendix B.3. Viewing Diagnostic information  Type the IP Address of the ProtoAir into the web browser or use the FieldServer Toolbox to connect to the ProtoAir.  Click on Diagnostics and Debugging Button, then click on view, and then on connections.

  • Page 41: Appendix B.5. Led Diagnostics For Communications Between Protoair And Devices

    Eaton ProtoAir Start-Up Guide Appendix B.5. LED Diagnostics for Communications Between ProtoAir and Devices See the diagram below for LED locations to ProtoAir. Diagnostic LEDs Description The SPL LED will light if the unit is not getting a response from one or more of the configured devices.
  • Page 42 Eaton ProtoAir Start-Up Guide  Connect a standard CAT5 Ethernet cable between the PC and ProtoAir.  Double click on the FS Toolbox Utility. Step 1: Take a Log Click on the diagnose icon of the desired device Ensure “Full Diagnostic" is selected (this is the default) NOTE: If desired, the default capture period can be changed.
  • Page 43 Eaton ProtoAir Start-Up Guide Click on “Start Diagnostic” When the capture period is finished, the “Diagnostic Test Complete” window will appear Step 2: Send Log Once the diagnostic test is complete, a .zip file will be saved on the PC Click “Open”...

  • Page 44: Appendix B.7. Updating Firmware

    Eaton ProtoAir Start-Up Guide Appendix B.7. Updating Firmware To load a new version of the firmware, follow these instructions: 1. Extract and save the new file onto the local PC. 2. Open a web browser and type the IP Address of the FieldServer in the address bar.

  • Page 45: Appendix B.9. Securing Protoair With Passwords

    Eaton ProtoAir Start-Up Guide Appendix B.9. Securing ProtoAir with Passwords Access to the ProtoAir can be restricted by enabling a password on the FS-GUI Passwords page – click Setup and then Passwords in the navigation panel. There are 2 access levels defined by 2 account names: Admin and User.

  • Page 46: Appendix B.10. Mounting

    Eaton ProtoAir Start-Up Guide Appendix B.10. Mounting The ProtoAir can be mounted using the DIN rail mounting bracket on the back of the unit. Din Rail Bracket Figure 50: DIN Rail Page 46 of 66...

  • Page 47: Appendix B.11. Physical Dimensions For Fpa-W34

    Eaton ProtoAir Start-Up Guide Appendix B.11. Physical Dimensions for FPA-W34 Power Port P1 Serial Port Figure 51: ProtoAir FPA-W34 Dimensions Page 47 of 66...

  • Page 48: Appendix B.12. Kaspersky Endpoint Security 10

    Eaton ProtoAir Start-Up Guide Appendix B.12. Kaspersky Endpoint Security 10 If Kaspersky Endpoint Security 10 is installed on the user’s PC, the software needs to be modified to allow the PC to register bridges on FieldPoP. NOTE: This problem is specific to KES10, Kaspersky 2017 does not have this problem.

  • Page 49: Appendix C Vendor Information - Eaton

    Eaton ProtoAir Start-Up Guide Appendix C Vendor Information – Eaton Appendix C.1. 3264640000 Greengate Mappings to BACnet and Modbus Point Name BACnet Object Type BACnet Object ID Modbus Register Reset 1001 Relay01 Relay02 Relay03 Relay04 Relay05 Relay06 Relay07 Relay08 Relay09...
  • Page 50 Eaton ProtoAir Start-Up Guide Remote030 Remote031 Remote032 Remote033 Remote034 Remote035 Remote036 Remote037 Remote038 Remote039 Remote040 Remote041 Remote042 Remote043 Remote044 Remote045 Remote046 Remote047 Remote048 Remote049 Remote050 Remote051 Remote052 Remote053 Remote054 Remote055 Remote056 Remote057 Remote058 Remote059 Remote060 Remote061 Remote062 Remote063 Remote064 Switch01...

  • Page 51: Appendix C.2. 4864643204 Greengate Mappings To Bacnet And Modbus

    Eaton ProtoAir Start-Up Guide Switch035 10035 Switch036 10036 Switch037 10037 Switch038 10038 Switch039 10039 Switch040 10040 Switch041 10041 Switch042 10042 Switch043 10043 Switch044 10044 Switch045 10045 Switch046 10046 Switch047 10047 Switch048 10048 Switch049 10049 Switch050 10050 Switch051 10051 Switch052 10052...
  • Page 52 Eaton ProtoAir Start-Up Guide Relay033 Relay034 Relay035 Relay036 Relay037 Relay038 Relay039 Relay040 Relay041 Relay042 Relay043 Relay044 Relay045 Relay046 Relay047 Relay048 Remote01 Remote02 Remote03 Remote04 Remote05 Remote06 Remote07 Remote08 Remote09 Remote010 Remote011 Remote012 Remote013 Remote014 Remote015 Remote016 Remote017 Remote018 Remote019 Remote020...
  • Page 53 Eaton ProtoAir Start-Up Guide Remote054 Remote055 Remote056 Remote057 Remote058 Remote059 Remote060 Remote061 Remote062 Remote063 Remote064 Switch01 10001 Switch02 10002 Switch03 10003 Switch04 10004 Switch05 10005 Switch06 10006 Switch07 10007 Switch08 10008 Switch09 10009 Switch010 10010 Switch011 10011 Switch012 10012 Switch013...

  • Page 54: Appendix C.3. 808640000 Greengate Mappings To Bacnet And Modbus

    Eaton ProtoAir Start-Up Guide Switch059 10059 Switch060 10060 Switch061 10061 Switch062 10062 Switch063 10063 Switch064 10064 AI_State01 10101 AI_State02 10102 AI_State03 10103 AI_State04 10104 AI_State05 10105 AI_State06 10106 AI_State07 10107 AI_State08 10108 AI_State09 10109 AI_State010 10110 AI_State011 10111 AI_State012 10112...
  • Page 55 Eaton ProtoAir Start-Up Guide Remote010 Remote011 Remote012 Remote013 Remote014 Remote015 Remote016 Remote017 Remote018 Remote019 Remote020 Remote021 Remote022 Remote023 Remote024 Remote025 Remote026 Remote027 Remote028 Remote029 Remote030 Remote031 Remote032 Remote033 Remote034 Remote035 Remote036 Remote037 Remote038 Remote039 Remote040 Remote041 Remote042 Remote043 Remote044 Remote045...

  • Page 56: Appendix C.4. 344640003 Greengate Mappings To Bacnet And Modbus

    Eaton ProtoAir Start-Up Guide Appendix C.4. 344640003 Greengate Mappings to BACnet and Modbus Point Name BACnet Object Type BACnet Object ID Modbus Register Reset 1001 Relay01 Relay02 Relay03 Remote01 Remote02 Remote03 Remote04 Remote05 Remote06 Remote07 Remote08 Remote09 Remote010 Remote011 Remote012...

  • Page 57: Appendix C.5. 1664643204 Greengate Mappings To Bacnet And Modbus

    Eaton ProtoAir Start-Up Guide Remote061 Remote062 Remote063 Remote064 Switch01 10001 Switch02 10002 Switch03 10003 Switch04 10004 Switch05 10005 Switch06 10006 Switch07 10007 Switch08 10008 Switch09 10009 Switch010 10010 Switch011 10011 Switch012 10012 Switch013 10013 Switch014 10014 Switch015 10015 Switch016 10016...
  • Page 58 Eaton ProtoAir Start-Up Guide Relay010 Relay011 Relay012 Relay013 Relay014 Relay015 Relay016 Remote01 Remote02 Remote03 Remote04 Remote05 Remote06 Remote07 Remote08 Remote09 Remote010 Remote011 Remote012 Remote013 Remote014 Remote015 Remote016 Remote017 Remote018 Remote019 Remote020 Remote021 Remote022 Remote023 Remote024 Remote025 Remote026 Remote027 Remote028 Remote029...
  • Page 59 Eaton ProtoAir Start-Up Guide Remote063 Remote064 Switch01 10001 Switch02 10002 Switch03 10003 Switch04 10004 Switch05 10005 Switch06 10006 Switch07 10007 Switch08 10008 Switch09 10009 Switch010 10010 Switch011 10011 Switch012 10012 Switch013 10013 Switch014 10014 Switch015 10015 Switch016 10016 Switch017 10017...

  • Page 60: Appendix C.6. 6464643200 Greengate Mappings To Bacnet And Modbus

    Eaton ProtoAir Start-Up Guide AI_State03 10103 AI_State04 10104 AI_State05 10105 AI_State06 10106 AI_State07 10107 AI_State08 10108 AI_State09 10109 AI_State010 10110 AI_State011 10111 AI_State012 10112 AI_State013 10113 AI_State014 10114 AI_State015 10115 AI_State016 10116 AI_State017 10117 AI_State018 10118 AI_State019 10119 AI_State020 10120...
  • Page 61 Eaton ProtoAir Start-Up Guide Relay028 Relay029 Relay030 Relay031 Relay032 Relay033 Relay034 Relay035 Relay036 Relay037 Relay038 Relay039 Relay040 Relay041 Relay042 Relay043 Relay044 Relay045 Relay046 Relay047 Relay048 Relay049 Relay050 Relay051 Relay052 Relay053 Relay054 Relay055 Relay056 Relay057 Relay058 Relay059 Relay060 Relay061 Relay062 Relay063...
  • Page 62 Eaton ProtoAir Start-Up Guide Remote033 Remote034 Remote035 Remote036 Remote037 Remote038 Remote039 Remote040 Remote041 Remote042 Remote043 Remote044 Remote045 Remote046 Remote047 Remote048 Remote049 Remote050 Remote051 Remote052 Remote053 Remote054 Remote055 Remote056 Remote057 Remote058 Remote059 Remote060 Remote061 Remote062 Remote063 Remote064 Switch01 10001 Switch02 10002...
  • Page 63 Eaton ProtoAir Start-Up Guide Switch038 10038 Switch039 10039 Switch040 10040 Switch041 10041 Switch042 10042 Switch043 10043 Switch044 10044 Switch045 10045 Switch046 10046 Switch047 10047 Switch048 10048 Switch049 10049 Switch050 10050 Switch051 10051 Switch052 10052 Switch053 10053 Switch054 10054 Switch055 10055...

  • Page 64: Appendix C.7. Scene Ilumin Mappings To Bacnet And Modbus

    Eaton ProtoAir Start-Up Guide Appendix C.7. Scene iLumin Mappings to BACnet and Modbus Point Name BACnet Object Type BACnet Object ID Modbus Register scene 40001 sceneFT 40002 Appendix C.8. Channel iLumin Mappings to BACnet and Modbus Point Name BACnet Object Type...

  • Page 65: Appendix D Reference

    Eaton ProtoAir Start-Up Guide Appendix D Reference Appendix D.1. Specifications ProtoAir FPA-W34 One 3-pin Phoenix connector with: RS-485 (Tx+ / Rx- / gnd) Electrical Connections One 3-pin Phoenix connector with: Power port (+ / - / Frame-gnd) One Ethernet 10/100 BaseT port...

  • Page 66: Appendix E Limited 2 Year Warranty

    Eaton ProtoAir Start-Up Guide Appendix E Limited 2 Year Warranty Sierra Monitor Corporation warrants its products to be free from defects in workmanship or material under normal use and service for two years after date of shipment. Sierra Monitor Corporation will repair or replace any equipment found to be defective during the warranty period.
