- Page 1 Shower FIttInGS Installation and User Guide These instructions are to be left with the user...
-
Page 2: Important Safety Information
InTroducTIon thank you for purchasing a quality Mira product. to enjoy the full potential of your new product, please take time to read this guide thoroughly, having done so, keep it handy for future reference. nectar Shower Fittings the adjustable Showerhead has four different spray actions and is supplied complete with Shower hose, clamp Bracket, Slide Bar Supports, and a Soap Dish. - Page 3 If you experience any difficulty with the installation or operation of your new Shower Fittings, please refer to ‘Fault diagnosis’, before contacting Kohler Mira Ltd. our telephone and fax numbers can be found on the back cover of this guide.
-
Page 4: Pack Contents
pack conTenTS Tick the appropriate boxes to familiarise yourself with the part names and to confirm that the parts are included. 2 x M4 Screws 1 x Showerhead 2 x Wall 1 x Cap Plugs 2 x Mounting Brackets 2 x Fixing Screws 2 x Slide Bar Supports... - Page 5 dImenSIonS 245 mm 707 mm...
-
Page 6: Specifications
SpecIFIcaTIonS pressures Minimum maintained pressure: 0.1 bar (10 kPa). Maximum maintained pressure: 5.0 bar (500 kPa). Exceeding the stated maximum maintained pressure could result in Warning! excessive spray forces and possible damage to the product. InSTallaTIon requIremenTS Installation must be carried out in accordance with these instructions, and must be conducted by designated, qualified and competent personnel. -
Page 7: Installation
InSTallaTIon note! For dry lined, stud partition, shower cubicle or laminated panel walls the installer may wish to obtain alternative proprietary cavity fixings. Use of these alternative fixings is beyond the scope of this guide. read the section: Installation requirements before proceeding with the installation. - Page 8 remove the slide bar assembly Slide Bar Support preventing any movement between the slide bar and slide bar supports. Slide Bar clamping tighten the two slide bar clamping Screw screws. note! when tightening the screws do not over tighten. half a turn maximum is all that is required.
-
Page 9: Operation
operaTIon Height adjustment. the height of the showerhead is easily adjusted by turning the knob on the clamp bracket and gently moving the clamp bracket either up or down the slide bar until the required height is achieved. Selecting Showerhead Spray. the adjustable showerhead has four different spray actions. -
Page 10: Maintenance
maInTenance cleaning Many household cleaners contain abrasives and chemical substances, and should not be used for cleaning plated or plastic fittings. These finishes should be cleaned with a mild washing up detergent or soap solution, and then wiped dry using a soft cloth. -
Page 11: Spare Parts
1703.276 1703.275 clamp Bracket - white 1703.276 clamp Bracket - chrome 1703.297 nectar Showerhead - chrome 1703.298 nectar Showerhead - white 1703.299 nectar adjustable Showerhead - chrome 1703.275 1703.276 1703.300 nectar adjustable Showerhead - white 1703.078 1703.195 1703.127 632.73 1703.297 1703.297... -
Page 12: Customer Service
You have the assurance of a ● Water or electrical supply, waste and isolation issues. fully trained Mira Technician, genuine Mira spare parts and a 12 month guarantee on any chargeable work done. ● Compensation for loss of use of the product or consequential loss of any kind. - Page 13 Electric Showers Digital Showers Mixer Showers Power Showers Smart Showers Shower Towers From Top Shower Brands Mira Showers Aqualisa Showers Triton Showers Gainsborough Showers Shower Pumps can upgrade your showering experience even more Stuart Turner Shower Pumps Salamander Shower Pumps...
