- Page 1 82T16 STRING TRIMMER OPERATOR MANUAL COUPE-HERBE MANUEL D’OPÉRATEUR CORTABORDES MANUAL DEL OPERADOR www.greenworkstools.com/82v-Commercial/ STB402 www.shopgreenworksgear.com/...
-
Page 2: Table Of Contents
English Description........2 Stop the machine........6 Operation tips..........6 Purpose............2 Line cut-off blade........7 Overview............ 2 Cutting tips..........7 IMPORTANT SAFETY Adjust the length of the cutting line.... 7 INSTRUCTIONS......2 Maintenance........7 Symbols on the machine....3 General information........8 Risk levels........ -
Page 3: Description
English DESCRIPTION IMPORTANT SAFETY INSTRUCTIONS PURPOSE READ ALL INSTRUCTIONS BEFORE USING (THIS This machine is used to cut grass, light weeds, and POWER TOOL) other similar vegetation at or around ground level. The WARNING cutting plane must be approximately parallel to the ground surface. -
Page 4: Symbols On The Machine
Use of any other battery packs may materials of other types – for example, metal wire, create a risk of injury and fire. Use only Greenworks rope, and the like. GLW300 / GLW600 batteries or other BAB series. -
Page 5: Risk Levels
English The toxic and corrosive materials below are in the Symbol Explanation batteries used in this machine: Lithium-Ion, a toxic material. Do not expose the machine to rain or moist conditions. WARNING Discard all toxic materials in a specified manner to Keep all bystanders at least 15m prevent contamination of the environment. -
Page 6: Attach The Guard
English WARNING • If the parts have damage, do not use the machine. • If you do not have all the parts, do not operate the machine. • If the parts are damaged or missing, speak to the service center. 1. -
Page 7: Operation
English OPERATION 2. Push the on/off button again to turn the machine off. IMPORTANT Before you operate the machine, read and understand the safety regulations and the operation instructions. WARNING Be careful when you operate the machine. CONTROLS 8.1.1 ON/OFF BUTTON Push this button to connect and disconnect the electrical circuit of the machine. -
Page 8: Line Cut-Off Blade
English DIRECTION OF ROTATION DANGER AREA BEST CUTTING AREA ADJUST THE LENGTH OF THE CUTTING LINE While you operate the machine, the cutting line gets worn and shorter. You can adjust the length of the cutting line. 1. Hit the trimmer head against the ground while you LINE CUT-OFF BLADE operate the machine. -
Page 9: General Information
English GENERAL INFORMATION IMPORTANT Only your dealer or approved service center can do the maintenance that is not given in this manual. Before the maintenance operations: • Stop the machine. • Remove the battery pack. • Cool the motor. • Store the machine in cool and dry place. -
Page 10: Replace The Cutting Line
English 2. Bend the line at the midpoint and hook the loop into the slot in the center rim of the spool. Make sure that the line snaps into position in the slot. 3. With your finger between the lines, wind the lines equally and tightly around the spool in the indicated direction. -
Page 11: Assemble The Trimmer Head
English TROUBLESHOOTING Problem Possible Cause Solution The ma- No electrical 1. Remove battery chine does contact between pack. not start the machine and 2. Check contact and when you the battery pack. install the battery pack push the again. trigger. The battery pack Charge the battery is depleted. -
Page 12: Technical Data
English Problem Possible Cause Solution Problem Possible Cause Solution The ma- The guard is not Remove the battery The line The machine is 1. Cut with the tip of chine attached to the pack and attach the keeps used incorrectly. the line, avoid stones, stops machine. -
Page 13: Limited Warranty
GARANTIE DE L'OUTIL GARANTÍA DE LA HERRAMIENTA Greenworks hereby warranties this product, to the original purchaser with proof of purchase, for a period of two (2) years against defects in materials, parts or workmanship. Greenworks, at its own discretion will repair or replace any and all parts found to be defective, through normal use, free of charge to the customer. -
Page 14: Exploded View
English EXPLODED VIEW No. Part No. Qty Description No. Part No. Qty Description 311012461E Rear handle assembly C1100403-00 Trimmer head assembly 311032461A Auxiliary handle assembly 311042461E Guard assembly 311022461E Motor head assembly Greenworks Tools PO Box 1238 Mooresville, NC 28115...
