What is the SE6166 controller?

The SE6166 controller controls rooftop Air Handling Units (AHUs) or other large single
pieces of equipment. You can mount the SE6166 on or inside the rooftop equipment.
Driver and control
Driver
program
Maximum number of control programs
Maximum number of BACnet objects*
* Depends on available memory.
** Any points that exceed this number will not be network visible.

Specifications

Power
BACnet port
(This port may be labeled
CMnet.)
Local Access port
LogiStat port
Rnet port
Inputs
Input resolution
Input pulse frequency
Digital outputs
SE6166 Controller • Rev. 4/13/2011
DRV_SE
1
300**
24 Vac ±10%, 50–60 Hz, 20 VA power consumption (38.4
VA with BACview6 attached) single Class 2 source only, 100
VA or less
For communication with the controller network using
ARC156 or MS/TP (9600 bps–76.8 kbps)
For system start-up and troubleshooting
For LogiStat and LogiStat Plus room sensors. The LogiStat
port uses two universal inputs.
NOTE The SE6166 does not support the LogiStat Pro. Use
an RS Pro on the Rnet port instead.
Supports up to four RS Standard sensors and one RS Plus,
RS Pro, or RS Pro-F sensor for averaging or high/low select
control. The sensors can share the Rnet port with a BACview
or BACview .
6
NOTE If you use the Rnet port, you cannot connect a
LogiStat sensor to the LogiStat port.
16 inputs, configurable for 0–10 Vdc, 0–20 mA, RTD,
thermistor, or dry contact, and one LogiStat port. Inputs 1
and 2 are also configurable for pulse counter or timed local
override (TLO).
NOTE If using a LogiStat or LogiStat Plus, temperature and
setpoint adjust inputs replace inputs 9 and 10, making 9
and 10 unavailable.
12 bit A/D
40 pulses per second. Minimum pulse width (on or off time)
required for each pulse is 12.5 msec.
6 digital outputs, relay contacts rated at 3 A max @ 24 Vac.
Configured normally open.
