Downloading the SE6166

Download the following items to the SE6166's battery-backed memory:
Item
Control program
DRV_SE driver
Editable properties
Schedules
If you change any of these items or the SE6166's address after the initial download, you
must download again. The first download takes longer than subsequent downloads.
CAUTIONS
•
•
To download in
You download the controller from WebCTRL. If your network is complete, you can
download from any network browser. If not complete, connect a laptop with a local copy of
WebCTRL
the system database to the SE6166's local access port. See To communicate through the
local access port (page 20).
1
2
3
4
5
NOTES
•
•
SE6166 Controller • Rev. 4/13/2011
Notes
Must be in WebCTRLx.x\webroot\<system_name>\programs.
Must be in WebCTRLx.x\webroot\<system_name>\drivers.
NOTE To verify that you have the driver's latest version, go to
http://accounts.automatedlogic.com/download, then select
Drivers > ExecB. Compare the latest version to the SE6166's
driver in SiteBuilder.
The SE6166 will lose stored data when you download.
Equipment controlled by the SE6166 will shut down and restart when you download.
On WebCTRL's NET tree, select the controller.
Click Downloads.
Do one of the following:
If the controller is in the Downloads list, go to step 4.
○
If the controller is not in the list:
○
a. Click Add.
b. In the pop-up, select the controller.
c. Select All Content.
d. Click Add.
e. Click Close.
Select the controller in the Downloads list.
Click Start.
If the download fails, locate and resolve the problem, then retry the download.
You can also download a controller from the Devices page.
