To use the Auto-
You can control a digital output using the Auto-Off-On switch.
Off-On switches
If switch position is...
Auto
Off
On
The control program can monitor the status of an Auto-Off-On switch and display the
status on the control program's Point Checkout page in WebCTRL. The Value of the point
monitoring the Auto-Off-On switch shows Off if the switch is set to Auto, and On if the
switch is set to Off or On.
To monitor an Auto-Off-On switch
1
2
3

To set up the driver

After you download the driver and control program(s) to the SE6166, you may want to
change the driver's properties to suit your application.
1
2
3

Driver

On the Driver page, you can change the following properties:
•
•
•
BACview Control
Overwrite Daylight Saving
parameters set in
BACview?
SE6166 Controller • Rev. 4/13/2011
Insert a BACnet Binary Input microblock in the control program.
On the microblock's Properties page in WebCTRL, set the I/O Type field to H-O-A
Status Feedback.
In the Input Number field, type the number of the output you want to monitor.
On WebCTRL's NET tree, click
Click to the left of Driver to see its children.
Make changes as needed on the Properties page for Driver and any of its children.
BACview inactivity timeout and user password. See table below.
Module clock synchronization and failure. See table below.
Network Input microblock communication properties.
Normally open output contacts are...
Determined by control program
Locked open
Locked closed
to the left of your SE6166.
Yes—Every download includes Daylight Saving Time
properties from System Settings page and overwrites
changes to these properties made from BACview.
No—Download System Settings page Daylight Saving Time
properties during first download. You must make
subsequent changes from BACview. (Primarily for OEM use.)
