Arbiter Systems 1040C Training Manual page 14

Table 1. Power Factor/Phase Operating Procedure
STEP OPERATOR ACTION
1. Apply power to PMC
2. Press 60 HZ
3. Press POWER FACTOR
4. Press VOLTAGE
5. Press 1
6. Press 2
Press 0
7. Press V/A
9. Press CURRENT
10. Press 5
RESULTS
After successful completion of Function Tests the PMC
will momentarily display PASSED FUNCTION TEST.
The PMC will return to RESET mode and display DC, 60
Hz, or 400 Hz? The RESET, STBY, and NORMAL
LED's (and the STORE LED if user settings are presently
stored in the user memory) will be illuminated.
RESET LED will extinguish, the 60 HZ and
FREQUENCY LED's will illuminate. The PMC now
displays FREQUENCY 60.00 Hz. (The Frequency may
now be modified or a new value entered).
FREQUENCY LED will extinguish, the POWER
FACTOR LED will illuminate and the PMC now
displays POWER FACTOR 1.000 (Power Factor may
now be modified or a new value entered).
VOLTAGE LED is illuminated and the PMC now
displays VOLTAGE 15.00V (15 Volts rms is the lowest
range available for Power Factor/Phase output mode).
The PMC displays ENTRY = 1
The PMC displays ENTRY = 12
The PMC displays
MINUS/BACKSPACE key may be used to erase
incorrect entries).
Pressing the units key V/A completes the entry of the
voltage setting. The PMC now displays VOLTAGE
120.0 V (The voltage may now be modified using the
rotary Knob or the Up/Down modify keys.).
The VOLTAGE LED will extinguish, the CURRENT
LED will illuminate, the PMC displays CURRENT
.1000A (.1 amps rms is the lowest current available for
Power Factor/Phase output mode).
PMC displays ENTRY = 5
12
ENTRY = 120. (The
