Arbiter Systems 1040C Training Manual page 10

AC Voltage Operating Procedure
CAUTION: Prior to making any connections, place the PMC in Standby Mode.
Connect the Model 918B to the PMC as shown below and perform the following steps:
1. Press 60 or 400 HZ.
2. Press VOLTAGE.
3. Enter the desired voltage using the keypad and the units key.
4. Press OPER.
5. MODIFY, MEMORY, or % DEV may be used. The FREQUENCY or VOLTAGE may
be modified.
6. To remove the output signal, press STBY when the measurement is complete.
AUX.
VOLTAGE
1040C PANEL METER
CALIBRATOR
OVERLO
REMOT
E AD
O SRQ ORMT
OLSN O RLK
VOLTAG
E
CURRE
NT
HIG
VOLTAG
H
E
— —
+ +
FUSED
25V
MAX
45 - 500
1000 Vrms CT OUTPUT ONLY
1000 Vdc H 25 mArms MAX
MAX
MAX
POWE
AT POWER ON
R
USE "HOLD" KEY TO CHANGE CT
RATIO USE "PHASE" KEY TO CHANGE PHASE
MODE
VA RANG
Vdc VA
R E
Vrm Arm W/Wh HOL
D
∆ PHAS STAR
PF
E T
SHIF
PHAS FRE MIN/MA
T
E Q X
CURRENT TRANSFORMER TERMINALS ARE AT
SAME POTENTIAL AS (–) VOLTAGE
INPUT USE PROPER
PRECAUTIONS
8
GP-
IB
POWE
R
