DISPLAY I/O BOARD
Pin
1
24 AC Hot Switched (500 mA average max)
2
24 AC neutral
3
24 AC neutral
4
Coin 1 pulse (short to pin 3 or pin 2 for coin pulse)
5
Coin 2 pulse (short to pin 3 or pin 2 for coin pulse)
6
Coin 3 pulse (short to pin 3 or pin 2 for coin pulse)
Pin
1
24 AC Hot Switched (500 mA average max)
2
24 AC neutral
3
24 AC neutral
4
Coin 4 pulse (short to pin 3 or pin 2 for coin pulse)
Pin
1
5VDC power for backlights
2
GND for 5VDC power backlights
3
24VAC Hot
4
24VAC Neutral
5
12VDC for diverter solenoid
6
GND for 12VDC for diverter solenoid
Document Number:
WS21058
Document Title:
WSII Operations Manual ver 6.10
J3 Main Coin Acceptor
Description
J2 Auxiliary Coin Acceptor
Description
J1 Main Power Input
Description
W A S H
S E L E C T
I I
86
