Pin
1
Rear Sensor
2
Data Track 2
3
Card Present
4
Strobe Track 2
5
N/C
6
5VDC power to card reader
7
GND power to card reader
8
Strobe Track 1
9
Data Track 1
Pin
1
12VDC button feed (current limited)
2
Button return (short this to Pin 1 for button press)
Pin
1
12VDC button feed (current limited)
2
Button return (short this to Pin 1 for button press)
Pin
1
12VDC button feed (current limited)
2
Button return (short this to Pin 1 for button press)
Pin
1
12VDC button feed (current limited)
2
Button return (short this to Pin 1 for button press)
Document Number:
WS21058
Document Title:
WSII Operations Manual ver 6.10
J9 Credit Card Reader
Description
J20 Wash 1 Button
Description
J21 Wash 2 Button
Description
J22 Wash 3 Button
Description
J23 Wash 4 Button
Description
W A S H
S E L E C T
I I
88
