V_Apci1500_Set16Digitaloutputon - Addi-Data APCI-1500 Technical Description

Standard software
7)

v_APCI1500_Set16DigitalOutputOn (...)

Syntax:
<Return value> = v_APCI1500_Set16DigitalOutputOn
Parameters:
BYTE b_BoardHandle
LONG l_Value
Task:
Sets one or several output channels of board xPCI-1500
Example:
Switching on the digital output memory (ON)
see function "i_APCI1500_SetOutputMemoryOn (...)
l_Value = 5555 Hex
The output channels 1, 3, 5, 7, 9, 11, 13, 15 are set. The other output channels
hold their state.
Switching off the digital output memory (OFF)
see function "i_APCI1500_SetOutputMemoryOff (...)
l_Value = 5555 Hex
Outputs 1, 3, 5, 7, 9, 11, 13, 15 are set. Outputs 2, 4, 6, 8, 10, 12, 14, 16 are reset.
Return value:
0: No error
-1: The handle parameter of the board is wrong
74
(BYTE b_BoardHandle,
LONG l_Value)
Handle of the xPCI-1500
Output value (0 to 65535)
APCI-/CPCI-1500
