APCI-/CPCI-1500

9.2.5 Digital input channel - events

1)

i_APCI1500_SetInputEventMask (...)

Syntax:
<Return value> = i_APCI1500_SetInputEventMask
Parameters:
BYTE b_BoardHandle
BYTE b_Port
BYTE b_Logik
PCHAR pc_EventMask
i
IMPORTANT!
If you use the APCI1500_AND logic, you can only use one edge event
Task:
An event can be generated for each port.
The first event is related to the first 8 input channels (port 1).
The second event is related to the next 6 input channels (port 2).
An interrupt is generated when one or both events have happened.
(BYTE b_BoardHandle,
BYTE b_PortNbr,
BYTE b_Logik,
PCHAR pc_EventMask)
Handle of board xPCI-1500
Number of the input port to be masked (1 or 2)
Event logic
Three possibilities for the first port:
APCI1500_AND: This logic connects the
input channels with an AND logic.
APCI1500_OR: This logic connects the
input channels with an OR logic.
APCI1500_OR: This logic connects the
input channels with a OR logic.
This 8-digit character string (port 1) and
6-digit character string (port 2) defines the
mask of the event. Each digit indicates the
state of the input channel. The state is
identified by one of the following characters:
"X": This input channel is not used for event
"0": The input channel must be on "0"
"1": The input channel must be on "1"
"2": The input channel reacts to a falling edge
"3": The input channel reacts to a rising edge
"4": The input channel reacts to both edges
Port 1: from the left to the right, the first digit
of the character string is input 8 and the last
digit is input 1.
Port 2: from the left to the right, the first digit
of the character string is input 14 and the last
digit is input 9.
Standard software
