  • Page 1 ) EYE-LCD7000 / 8200 EYE-LCD7000 EYE-LCD8200 User’s Manual Version 2.3b (Dec/2010)
  • Page 2 EYE-LCD7000 / 8200...

  • Page 3: Table Of Contents

    EYE-LCD7000 / 8200 TABLE OF CONTENT SAFETY INSTRUCTIONS General Instructions Power Installation Unused for long periods of time Precautions for the remote control batteries Cleaning Storing Notes & Cautions fur Use FEATURES Packaging 2.1.1 Way of Packaging Dimensions 2.2.1 Mounting holes CONNECTORS &...
  • Page 4 EYE-LCD7000 / 8200 SUPPORTED INPUT MODES Sync Type: SOG (Component – VGA – HDMI) Sync Type : Video (S-Video – Composite) Sync Type : Graphics (VGA - HDMI ) HDMI only modes A GUIDE TO SIMPLE PROBLEM SOLVING Malfunction or Trouble...

  • Page 5: Safety Instructions

    Therefore the mains plug shall be easily accessible. If, not, this may cause electric shock or fire.  Do only use the power cord provided by eyevis. Do not use the power cord of another product. Improper power cords may lead to fire or electric shock. ...

  • Page 6: Installation

    EYE-LCD7000 / 8200 Installation Do not install the device in areas where humidity is high. If the unit is installed in direct sunlight, closed car or near a stove the cabinet or other parts may  distort or be damaged, and electric shock may result.

  • Page 7: Use

    EYE-LCD7000 / 8200 Never repair, modify or disassemble the unit by yourself. It may cause a fire or an electric shock because dangerous voltages exist in the unit. Consult your  dealer for internal inspection and repairs. Follow these precautions for the power cord.

  • Page 8: Unused For Long Periods Of Time

    EYE-LCD7000 / 8200 wipe it off with cotton swab or soft cloth immediately, otherwise display surface will be deteriorated. If water gets inside the LCD module, circuit may be damaged. This product contains chemicals, including lead, known to cause birth defects or other reproductive harm.

  • Page 9: Storing

    EYE-LCD7000 / 8200 3 To keep the cabinet looking brand-new, periodically clean it with a soft cloth. Stubborn stains may be removed with a cloth lightly dampened with mild detergent solution. Never use strong solvents, such as thinner or benzene, or abrasive cleaners, since these will damage the cabinet.

  • Page 10: Features

    3 1 remote control (optional) 2.1.1 Way of Packaging The EYE-LCD7000 / 8200 is packed in a carton box. To provide protection during transportation, the EYE- LCD7000 / 8200 is surrounded with foam. The packaging is secure with banding and fastening clips.

  • Page 11: Dimensions

    EYE-LCD7000 / 8200 Dimensions Dimensions EYE-LCD7000 (front / bottom view) 1677.7mm 1560mm Dimensions EYE-LCD8200 (front / bottom view)

  • Page 12: Mounting Holes

    EYE-LCD7000 / 8200 2.2.1 Mounting holes EYE-LCD7000 30mm 1677.7mm 100mm M8 Thread 800mm 200mm 400mm 200mm M12 Thread 1636.5mm 1886mm 800mm M12 Thread EYE-LCD8200 1926mm 30mm M8 Thread 100mm 800mm 200mm 200mm 400mm 200mm 200mm M12 Thread 1886mm 1886mm 800mm...

  • Page 13: Connectors & Control

    EYE-LCD7000 / 8200 CONNECTORS & CONTROL Power Cord Connection 3 AC power cord connection 3 Use the supplied power cord to connect your LCD panel to the wall outlet. 3 Plug the female power connector into the male connector at the back of the LCD panel 1.

  • Page 14: The Remote Control

    EYE-LCD7000 / 8200 The Remote Control 3.3.1 Remote Control Buttons / Push-Buttons on Device Function Power Power on/off board Menu Opens OSD Exit Closes OSD ▲ “Up” • Moves up through possible selections • Switch main input port while OSD is closed ▼...

  • Page 15: Osd Menu Functions

    EYE-LCD7000 / 8200 OSD MENU FUNCTIONS All the functions of the Display are controlled and adjusted using the OSD. Access the OSD Menu with the included software or with the Menu button on the remote control unit. Note: Illustrated values may differ from your displayed OSD menu settings, depending on the firmware...

  • Page 16: Sub-Menu "Image Settings Advanced

    EYE-LCD7000 / 8200 4.1.2 Sub-Menu “Image Settings Advanced“ “Advanced” Menu for video mode of SDI, svideo, composite and component inputs. “Advanced” Menu for graphics mode of HDMI & VGA Color: 3 Color Temp: Allow selection of different color temperature schemes.
  • Page 17 EYE-LCD7000 / 8200 Noise Reduction: 3 CCS Mode: Changes Cross-Color Suppression between off/adaptive/normal. Adjust for best image. 3 Dynamic NR Mode: Changes Dynamic Noise Reduction between low/medium/high/off/adaptive. High setting may cause loss of detail, adjust f for best image. Video Processing: 3 DCDi: Directional Correlation De-interlacing (DCDi) is a digital enhancement method developed by Faroudja.

  • Page 18: Sub-Menu "Display Settings

    EYE-LCD7000 / 8200 4.1.3 Sub-Menu “Display Settings“ Aspect Ratio: Used to adjust display between full screen, Letter Box Expand, and Pillar Box PIP: Picture-In-Picture can be used to display HDMI/DVI and another input at the same time. 3 PIP mode can be toggled between Off, PAP-Tall, PAP, Small PIP and Large PIP.

  • Page 19: Sub-Menu "Audio Settings

    EYE-LCD7000 / 8200 4.1.4 Sub-Menu “Audio Settings“ Audio Settings: 3 Volume: Set to in- or decrease the output audio level 3 Balance: Allocates the amount of output for left or right speaker 3 Bass: Level of deep frequencies 3 Treble: Level of higher frequencies 3 Stereo: Stereo can be toggled between: Stereo and Mono.

  • Page 20: Sub-Menu "Position Settings

    EYE-LCD7000 / 8200 4.1.5 Sub-Menu “Position Settings“ “Position Settings” menu for video mode of SDI , svideo, composite and component inputs. WARNING: Please note that it is not possible to access “Position Settings” menu when input is graphic mode of HDMI.

  • Page 21: Sub-Menu "Osd Settings

    EYE-LCD7000 / 8200 4.1.6 Sub-Menu “OSD Settings“ 3 Horizontal: This function can be used to move the OSD window on a horizontal line. 3 Vertical: This function can be used to move the OSD window on a horizontal line. 3 Blend: This function can be used to change the transparancy of the OSD window.

  • Page 22: Technical Specification

    EYE-LCD7000 / 8200 TECHNICAL SPECIFICATION LCD Panel EYE-LCD7000 EYE-LCD8200 Technology S-PVA LCD Max. Image Resolution 1,920 x 1,080 (full HD) Display Features Colours 16.7 Millionen (8bits-true) Aspect Ratio 16:9 Viewing Angle 178° / 178° Response Time 8 ms (Grey-to-Grey) Contrast Ratio...

  • Page 23: Supported Input Modes

    EYE-LCD7000 / 8200 SUPPORTED INPUT MODES The PrismaMEDIA can support the following input modes (support for RGB is mandatory; DVI & video support depend on the PrismaMEDIA type). The modes are detected when presented to the input and previous lignments for setup are automatically recalled.

  • Page 24: Sync Type : Graphics (Vga - Hdmi )

    EYE-LCD7000 / 8200 Sync Type : Graphics (VGA - HDMI ) The factory preset supported input modes include: Resolution) Resolution 640 x 350 x 70 Hz (IBM) 1024 x 768 x 72 Hz (IBM) 640 x 350 x 85 Hz (VESA)

  • Page 25: A Guide To Simple Problem Solving

    EYE-LCD7000 / 8200 A GUIDE TO SIMPLE PROBLEM SOLVING Before calling service personnel, please check the following chart for a possible cause to the trouble you are experiencing. Symptom Check these things No picture 3 Make sure the power cord is plugged in...

  • Page 26: Guidelines For The Use Of The Displays

    EYE-LCD7000 / 8200 GUIDELINES FOR THE USE OF THE DISPLAYS TO AVOID UNDESIRED EFFECTS Introduction Thanks to their flexible possibilities of usage, their minor space requirement and their reliable display performance the displays of the EYE-LCD Series have become more and more popular for a wide range of applications.

  • Page 27: Advantages Of The Eye-Lcd Series Over Other Display Technologies

    The LCD/TFT Technology of the EYE-LCD Series: The light for the LCD/TFT technology used for the displays from eyevis comes from several small fluorescent tubes. These tubes are placed behind several different filter layers and a polarisation filter. In colour LCDs each individual pixel is divided into three cells, or sub-pixels, which are coloured red, green, and blue, respectively, by additional filters (pigment filters, dye filters and metal oxide filters).

  • Page 28: How To Minimize The Danger Of Image Retention

    EYE-LCD7000 / 8200 How to minimize the Danger of Image Retention Reduce Ambient Temperature The ambient temperature and therefore the temperature inside the LCD display plays a decisive role for the appearance of image retention. The risk of image retention increases the higher the surrounding temperature is.

  • Page 29: Warranty Information

    Repair and Return The defective product is sent to eyevis by the customer and is repaired within 14 days. In this case eyevis bears the costs for eventually required components or the arising working time, as well as for the costs for the reshipment to the customer.
  • Page 30 The reaction time to claim a right given by this warranty starts with the customer’s announcement of the claim to the eyevis GmbH. It is calculated in accordance to the standard service hours of the eyevis GmbH (daily 9.00 AM to 5.00 PM, except Saturdays, Sundays and Bank Holidays).
  • Page 31 4.) The eyevis GmbH can provide a suitable transport box on request if the customer can not ensure to be able to pack the defect device correctly and to label t as a breakable good. The customer is liable for damages caused by the use of an improper or unsuitable packing by the customer.

  • Page 32: Correct Disposal

    EYE-LCD7000 / 8200 CORRECT DISPOSAL Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.

  • Page 33: Additional Support

    The content of this manual is furnished for information use only, is subject to change without notice, and should not be construed as a commitment by eyevis GmbH. eyevis GmbH resumes no responsibility or liability for any errors or inaccuracies that may appear in this documentation.
  • Page 34 EYE-LCD7000 / 8200 ANNEX 1: TECHNICAL SPECIFICATIONS EXPANDED SCALER BOARD VERSION Technical Specifications Expanded Scaler Board Version EYE-LCD7000 / 8200 with HDMI / Display Port / SDI...
  • Page 35 EYE-LCD7000 / 8200             DATA DISPLAY GROUP Table of Contents 1 Revision History..........................3 2 Introduction............................3 3 Minimum requirements........................3 4 How to Communicate with PrismaMEDIA-II.................3 Serial port configuration..............................3 Request and response structure ..........................4 Calculating the Checksum..............................

  • Page 36: Revision History

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 1 Revision History Date Rev. No. Description 08.03.2010 1.0.0 Initial release New control added: Pip Transparency 15.04.2010 1.0.1 Bug fix: Sharpness adjustment related New audio controls added: Volume, Balance, Bass, Treble, 16.06.2010...

  • Page 37: Request And Response Structure

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.2 Request and response structure To read and adjust the OSD menu controls, and to execute the OSD menu functions, requests must be sent to the PrismaMEDIA-II board from the COM port of the PC.

  • Page 38: Calculating The Checksum

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.3 Calculating the Checksum The calculation of checksum is as follows: Add the previous (first 7) bytes of the request, take the least significant 8 bits of this result, and find the 2’s complement of this result.

  • Page 39: Remote Osd Sub-Function Ids

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.4 Remote OSD Sub-Function IDs Sub-function ID is taken into account in all commands except “Connection Check” and “Protocol Version”. In “Control Function” this byte is used, but the format changes. This special command will be explained in Section 4.8.1.15.

  • Page 40: Remote Osd Command Table

        EYE-LCD7000 / 8200         DATA DISPLAY GROUP 4.5 Remote OSD Command Table √ √ None 1: Valid Sync Connection Check 0x00 2: Powered Off 3: No Sync √ 1-Set...
  • Page 41     EYE-LCD7000 / 8200         DATA DISPLAY GROUP √ 1-Set MPEG NR 0x46 √ 1-Set 0: Off Main DCDi 0x11 1: On √ 1-Set 0: Off Main MADI Mode 0x12...
  • Page 42         EYE-LCD7000 / 8200     DATA DISPLAY GROUP √ HDMI Video Width 0x21 1-Set √ HDMI Video Height 0x22 1-Set √ HDMI Horizontal Start 0x23 1-Set √ HDMI Vertical Start...
  • Page 43         EYE-LCD7000 / 8200     DATA DISPLAY GROUP √ TBD, None Factory Reset 0x39 √ √ 1-Set 0: Off Speed Mode 0x48 1: On √ 1-Set 0: Off Auto Brightness...
  • Page 44 EYE-LCD7000 / 8200 DATA DISPLAY GROUP 1-Set 0: O √ 1: Audio In-1 Audio L/R input port 0x86 2: Audio In-2 (VGA) 3: Audio In-3 4: Audio In-4 1-Set 0: O √ 1: Audio In-1 Audio L/R input port 0x87...

  • Page 45: Availability Of Controls

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.6 Availability of Controls √ Available if firmware saves settings according to active scheme. Scheme 0x01   Control Function Firmware Properties BIT0 will be “1”...
  • Page 46 EYE-LCD7000 / 8200             DATA DISPLAY GROUP √ Not available if firmware does not support pip option.   Pip Mode 0x16 Control Function Firmware Properties BIT1 will be “1” if this control is available.
  • Page 47 EYE-LCD7000 / 8200             DATA DISPLAY GROUP √ NTSC Video Width 0x29 Available if the resolution is NTSC and adjusted input type is S-Video, or Composite. Also, “Aspect Ratio” setting √...
  • Page 48 EYE-LCD7000 / 8200             DATA DISPLAY GROUP √ Audio L/R input Not available if firmware does not suport S-Video1 input. 0x8A port (S-Video1) √ Audio L/R input Not available if firmware does not suport S-Video2 input.

  • Page 49: File Operations

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.7 File Operations All settings are saved in the NVRAM of the PrismaMEDIA-II firmware. Some of these functions have a different variable for each input type or scheme (multiple set). See Table 5, Column “Number of Saved Value Sets in File Operations”.

  • Page 50: Sample Request And Response Packets With Explanations

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.8 Sample Request and Response Packets with Explanations This section includes examples referring to both regular commands and commands with special conditions and behaviour.

  • Page 51: Connection Check

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP Power On : Request Explanations Request Response Response (Hex) (Hex) Explanations Length 0x08 0x08 Length Remote OSD 0x34 0x34 Remote OSD Power...

  • Page 52: Brightness

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.8.1.3 Brightness Request Explanations Request Response Response (Hex) (Hex) Explanations Length 0x08 0x08 Length Remote OSD 0x34 0x34 Remote OSD Brightness control...

  • Page 53: Aspect Ratio

        EYE-LCD7000 / 8200         DATA DISPLAY GROUP 4.8.1.6 Aspect Ratio Normally this control is enabled if “Tiling Status” setting is not “On”. But, “Letter Box (Expand)”, “Pillar Box (Expand)” and “Panoramic” options are not available according to input resolution, panel resolution and “Pip Mode”...

  • Page 54: Auto Brightness

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.8.1.9 Auto Brightness “Auto Brightness” is a setting which available with custom firmwares. See Section 4.8.1.15.2. Request Explanations Request Response Response (Hex)

  • Page 55: Film Mode Detection

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.8.1.11 Film Mode Detection In this example, there is an adjust request for “Film Mode Detection". The adjustment operation has been performed.

  • Page 56: Protocol Version 1.0.0

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.8.1.12 Protocol Version Request Explanations Request Response Response (Hex) (Hex) Explanations Length 0x08 0x08 Length Remote OSD 0x34 0x34 Remote OSD Protocol version...

  • Page 57: Board Type

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.8.1.14 Board Type Request Explanations Request Response Response (Hex) (Hex) Explanations Length 0x08 0x08 Length Remote OSD 0x34 0x34 Remote OSD Board Type...

  • Page 58: Control Function

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.8.1.15 Control Function Control function is for making checks that are related to more than one item of the OSD or making checks related with firmware’s available functions and properties.

  • Page 59: Supported Inputs By Firmware

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.8.1.15.1 Supported Inputs by firmware Request Explanations Request Response Response (Hex) (Hex) Explanations Length 0x08 0x08 Length Remote OSD 0x34 0x34 Remote OSD...

  • Page 60: Are Osd Functions Available For Pip Input

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.8.1.15.3 Are OSD functions available for PIP Input When there is no signal at the PIP input, pip input related controls can not be used. In Remote OSD Control...

  • Page 61: Position Menu Type Of Main/Pip Input

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.8.1.15.5 Position menu type of main/pip input Position menu controls change according to selected input and detected resolution (Table 9). This control can be used to check which menu type is available for the current state of main/pip input.

  • Page 62: File Operation Examples

        EYE-LCD7000 / 8200         DATA DISPLAY GROUP Request Explanations Request Response Response (Hex) (Hex) Explanations Length 0x08 0x08 Length Remote OSD 0x34 0x34 Remote OSD Control Function 0x40 0x40...

  • Page 63: Input Change Examples

    EYE-LCD7000 / 8200             DATA DISPLAY GROUP 4.8.3 Input Change Examples See Section 4.4 for explanation about input changes. 4.8.3.1 Main Input Change Request Explanations Request Response Response (Hex)
