Eyevis EYE-LCD-6000-QHD-LD User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
) EYE-LCD-6000-QHD-LD
EYE-LCD-6000-QHD-LD
User's Manual
Version 1.1 (September 2012)
Technical changes reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EYE-LCD-6000-QHD-LD and is the answer not in the manual?

Questions and answers

Related Manuals for Eyevis EYE-LCD-6000-QHD-LD

Summary of Contents for Eyevis EYE-LCD-6000-QHD-LD

  • Page 1 ) EYE-LCD-6000-QHD-LD EYE-LCD-6000-QHD-LD User’s Manual Version 1.1 (September 2012) Technical changes reserved.
  • Page 2 EYE-LCD-6000-QHD-LD...

  • Page 3: Table Of Contents

    Compatible Input Signal ......................24 4.1.1 Recommended (native) Input Signal ........................24 APPENDIX Dimensional Drawing ........................ 25 5.1.1 EYE-LCD-6000-QHD-LD (dimensions in mm) ....................... 25 CONNECTORS & CONTROL Power Cord Connection ......................26 Input Source Connections & Controls ..................26 6.2.1 Signal-Input .................................. 26 6.2.2 Controling (RS232) ..............................
  • Page 4 10.6 Advised Procedure for raising a Claim ..................47 10.6.1 Consider the Manual before raising a Claim ..................47 10.6.2 Prepare necessary Information ........................47 10.6.3 Approval by eyevis ............................47 10.6.4 Packing ................................47 10.6.5 Transport ................................. 47 10.6.6 Service Code ..............................

  • Page 5: Revision History

    EYE-LCD-6000-QHD-LD REVISION HISTORY PAGE/ VERSION DATE DESCRIPTION SECTION 2012-06-07 Specification first issued. Section 2012-09-18 Safety updated, warranty updated 1, 10-12...
  • Page 6 EYE-LCD-6000-QHD-LD ABOUT THIS MANUAL Read and pay attention to this manual. It contains important information on the product. In particularly, note all of the safety instructions and warnings. Keep this manual in a safe place! Warnings used NOTICE! Indicates a hazard that could lead to damage or destruction of the product.
  • Page 7 EYE-LCD-6000-QHD-LD ZU DIESEM HANDBUCH Lesen und beachten Sie dieses Handbuch. In ihm stehen wichtige Informationen zum Produkt. Beachten Sie insbesondere alle Sicherheits- und Warnhinweise. Bewahren Sie dieses Handbuch sorgfältig auf! Verwendete Warnhinweise ACHTUNG! Kennzeichnet eine Gefahr, die zur Beschädigung oder Zerstörung des Produkts führen kann.
  • Page 8 EYE-LCD-6000-QHD-LD À PROPOS DE CE MANUEL Lisez et suivez ces instructions. Ils contient des informations importantes sur le produit. Faites particulièrement attention à toutes les consignes de sécurité et aux avertissements. Conservez ce manuel soigneusement! Des symboles d`avertissement utilisés ATTENTION! Indique un danger qui peut endommager ou détruire le produit.

  • Page 9: Safety/Sicherheit/Sécurité

    EYE-LCD-6000-QHD-LD SAFETY/SICHERHEIT/SÉCURITÉ SAFETY PRECAUTION Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product.

  • Page 10: Safety Instructions

    Never rub or tap the monitor with hard objects. Please understand that eyevis bears no responsibility for errors made during use by the customer or a third party, nor for any other malfunctions or damage to this product arising during use, except where indemnity liability is recognized under law.
  • Page 11 If dust collects inside the monitor, it may lead to excessive heat, outbreak of fire, or malfunction. Please request a cleaning of the inside of the monitor from an authorized Eyevis servicing dealer or service center.
  • Page 12 EYE-LCD-6000-QHD-LD NOTICE! This is a class A product according EN 55022: 2010. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate counter measures. NOTICE! To maintain compliance with EMC regulations, use shielded cables to connect to the following...

  • Page 13: Sicherheitsvorkehrungen

    EYE-LCD-6000-QHD-LD SICHERHEITSVORKEHRUNGEN Elektrizität erfüllt viele nützliche Aufgaben, kann aber auch Personen- und Sachschäden verursachen, wenn sie unsachgemäß gehandhabt wird. Dieses Produkt wurde mit Sicherheit als oberster Priorität konstruiert und hergestellt. Dennoch besteht bei unsachgemäßer Handhabung u.U. Stromschlag- und Brandgefahr. Um mögliche Gefahren zu vermeiden, befolgen Sie beim Aufstellen, Betreiben und Reinigen des Produkts bitte die nachstehenden Anleitungen.

  • Page 14: Sicherheitshinweise

    EYE-LCD-6000-QHD-LD  Wenn das Gerät nicht wie in der Bedienungsanleitung beschrieben funktioniert.  Nehmen Sie nur die in den Bedienungsanleitungen beschriebenen Einstellungen vor. Unsachgemäße Einstellungen an anderen Reglern können zu einer Beschädigung führen und machen häufig umfangreiche Einstellarbeiten durch einen qualifizierten Service-Techniker erforderlich.
  • Page 15 Vermeiden Sie es, den Monitor mit harten Gegenständen abzureiben oder zu berühren. Wir bitten um Ihr Verständnis, dass eyevis über die gesetzlich anerkannte Leistungshaftung hinaus keine Haftung für Fehler übernimmt, die sich aus der Verwendung durch den Kunden oder einen Dritten ergeben, und auch nicht für sonstige Funktionsstörungen oder Schäden, die während der Verwendung am Gerät entstehen.
  • Page 16 EYE-LCD-6000-QHD-LD ACHTUNG! Dieses Gerät ist ein Produkt der Klasse A gemäß EN 55022: 2010. In Wohnräumen kann dieses Gerät Störsignale erzeugen, die durch entsprechende Abhilfemaßnahmen durch den Benutzer beseitigt werden müssen. ACHTUNG! Verwenden Sie EMV-gerechte, abgeschirmte Kabel, um die folgenden Anschlüsse zu...

  • Page 17: Précautions De Sécurité

    EYE-LCD-6000-QHD-LD PRÉCAUTIONS DE SÉCURITÉ L’électricité remplit de nombreuses fonctions utiles, mais elle peut provoquer des blessures et des dégâts matériels si elle n’est pas utilisée correctement. Cet appareil a été conçu et fabriqué en attachant la plus grande importance à la sécurité.

  • Page 18: Mesures De Sécurité

    Ne frottez pas, ne grattez pas le moniteur avec un objet dur. Il faut savoir que la Eyevis décline toute responsabilité en cas d’erreurs commises durant l’utilisation par le client ou par une tierce personne, ainsi qu’en cas de dysfonctionnement ou de dommage survenu à ce produit pendant son...
  • Page 19 à l’intérieur du moniteur risque d’entraîner une surchauffe, un incendie ou un dysfonctionnement. Faites nettoyer l’intérieur du moniteur par un revendeur Eyevis ou un centre de services autorisé. Il n’est pas possible de faire tourner les images sur ce moniteur. Quand vous travaillez suivant la direction verticale, prévoyez d’orienter au préalable le contenu.
  • Page 20 EYE-LCD-6000-QHD-LD ATTENTION! Ce produit appartient à la Classe A d‘après la norme EN 55022: 2010. Dans un environnement résidentiel, il peut provoquer des interférences radio et, dans ce cas, l’utilisateur peut être obligé de prendre les mesures nécessaires. ATTENTION! Afin de satisfaire aux normes EMC, utiliser des câbles blindés pour connecter les bornes suivantes : Borne de sortie PC/AV DVI-D, borne d’entrée PC/AV DVI-D, borne d’entrée PC/AV HDMI, borne...

  • Page 21: Features

    EYE-LCD-6000-QHD-LD FEATURES Ultra-High-Resolution Wide-Screen Display The EYE-LCD-6000-QHD-LD is an Ultra-High-Resolution TFT Monitor. With a resolution of 3840 x 2160 pixels and 16.7 Mio colours you can display extremely fine pictures on this LCD display. Split-Stripes The native resolution (real existing number of Pixel) of the display needs a high-bandwidth-transmission of the video signal.

  • Page 22: Installation Possibilities For Eye-Lcd-6000-Qhd-Ld

     1 eyevis display adjustment software on CD  1 IR remote control 2.1.1 Way of Packaging The EYE-LCD-6000-QHD-LD is packed in a carton box. To provide protection during transportation, the EYE-LCD- 6000-QHD-LD is surrounded with foam. To unpack  Open cardboard box ...

  • Page 23: Operating The Monitor

    8 hours the display should be switched off (not only black screen). That enlarges the life-time of the product decisively and reduces the risk of image retention effects. The lifetime of the EYE-LCD-6000-QHD-LD is not limited, but the components have limited values: The average life time of the backlight is 50.000 hours.

  • Page 24: Technical Specification

    EYE-LCD-6000-QHD-LD TECHNICAL SPECIFICATION EYE-LCD-6000-QHD-LD LCD Display Type: EYE-LCD-6000-QHD-LD Installation: Landscape Screen Size (Active Screen Area): 60“ (1330,6mm x 748,4mm) Display Resolution: 3.840 x 2.160 Pixel Pixel Pitch: 0.3465 mm (H) x 0.3465 mm (V) Brightness: 500 cd/m Response time: 6 ms Viewing Angle:: 176°...

  • Page 25: Appendix

    EYE-LCD-6000-QHD-LD APPENDIX Dimensional Drawing 5.1.1 EYE-LCD-6000-QHD-LD (dimensions in mm)

  • Page 26: Connectors & Control

    DVI-D input DVI-Input stripe 2 DVI-D input DVI-Input stripe 3 DVI-D input DVI-Input stripe 4 DVI-D input 6.2.2 Controling (RS232) Name Remarks Sub-D 9pin RS232 Input (for connection additional eyevis displays) Sub-D 9pin RS232 Output (for connection additional eyevis displays)

  • Page 27: Backside Controls

    EYE-LCD-6000-QHD-LD Backside controls 6.2.3 Backside Controls Name Remarks 1. Force Address 1 2. Not used 3. Not used 4. Not used DIP switches 5. Enable debug and error messages 6. Enable verbose debug and error messages [only use this on a single device at a time] 7.

  • Page 28: The Remote Control

    EYE-LCD-6000-QHD-LD The Remote Control The menu functions of the OSD menu can be accessed with the eyevis Remote-Control (RC), see picture below. To use the RC aim at the displays-IR-Receiver) Opening the On-Screen-Display Press the MENU/EXIT-Button to open the OSD Menu on the screen.
  • Page 29 EYE-LCD-6000-QHD-LD Changing the Remote Control Batteries Remove the battery cover Slide back and remove the battery cover in the direction of the arrow. Insert the batteries Align and insert two AAA batteries according to their plus and minus poles (as indicated in the remote control).

  • Page 30: Main Menu

    EYE-LCD-6000-QHD-LD 6.3.2 Main Menu This menu is used for making common adjustments (see the basics of navigating the menu in chapter „The Remote Control“). Main Menu Select Area Status Input Boards Tools Fan Status Temperature Status Info Save Select Area (rw) Select in which of the 4 stripes the OSD is displayed: •...

  • Page 31: Status Input Boards

    EYE-LCD-6000-QHD-LD 6.3.3 Status Input Boards Status Input Boards Source pres Acol Aline 2160 Totalcol 1120 Totalline 2222 FrameFreq 59972 Source pres Recognised sources at input board (indentified source = 1, no identified source =0) • Press MENU/EXIT or ◄ to return to the previous menu.

  • Page 32: Tools

    EYE-LCD-6000-QHD-LD 6.3.4 Tools Tools Front LED Backlight level Front LED (rw) Switch Front LED ON/OFF • Press ENTER or  to enter. • Press  to set ON/OFF. • Press MENU/EXIT or ◄ to return to the previous menu. (Default: ON)

  • Page 33: Fan Status

    EYE-LCD-6000-QHD-LD 6.3.5 Fan Status Fan Status Fan 1 Speed Fan 1 Status Fan 2 Speed Fan 2 Status Fan 3 Speed Fan 3 Status Fan 1 Speed Current speed of Fan 1 (depends on CPU Temperature) • Press MENU/EXIT or ◄ to return to the previous menu.

  • Page 34: Temperature Status

    EYE-LCD-6000-QHD-LD 6.3.6 Temperature Status Temperature Status Temp Input Board 1 Temp Input Board 2 Temp Input Board 3 Temp Input Board 4 CPU Temperature DBPVM Temperature Fan Sensor 1 Temperature Temp Input Board 1 Current temperature of Input Board 1 in °C •...

  • Page 35: Info

    EYE-LCD-6000-QHD-LD 6.3.7 Info Info LCD Panel CPU HW Version LCC301 DB Version CPU FW Version 2.56 FB Board Database Version 2101 HW Version 2104 SW Version 2104 LCD Panel String Description of the LCD Panel • Press MENU/EXIT or ◄ to return to the previous menu.

  • Page 36: Eyedevicesetup" Control Software

    The EYE-LCD-6000-QHD-LD can be controlled and parameterised with the included “eyeDeviceSetup“ software. To control the EYE-LCD-6000-QHD-LD you need a Windows XP (or higher) compatible PC with a serial Interface (RS232). If a serial interface (RS232) does not exist, you can use the USB-RS232 adapter (not included in delivery).

  • Page 37: Mode Of Operation

    The EYE-LCD-6000-QHD-LD is equipped with a internal processing which can access to every individual stripe of the monitor.  With the „Eyevis Device Setup“ software you can read out and edit the parameters. To read out the actually values, press the button „Read current...“.

  • Page 38: Information "Status"-Index

    EYE-LCD-6000-QHD-LD Information “STATUS”-Index The index “Status” indicates the current operating values of the monitor. To update the operating values press the button „Refresh“ on the left side. PARAMETER RANGE OF VALUES / DEFAULT VALUE FUNCTION Fan 1 Speed 0-255 The current speed of Fan 1...

  • Page 39: A Guide To Simple Problem Solving

    EYE-LCD-6000-QHD-LD A GUIDE TO SIMPLE PROBLEM SOLVING Before calling service personnel, please check the following chart for a possible cause to the trouble you are experiencing. Symptom Check these things No picture  Make sure the power cord is plugged in ...

  • Page 40: Evaluation Of Visual Range

    EYE-LCD-6000-QHD-LD EVALUATION OF VISUAL RANGE Failure of Pixel A image point (Pixel) consist 3 sub pixel with basic colour red, green and blue. The physical dimension of pixel (also called pixel pitch) differs depending on the model (look at the data sheet for more information). If a pixel failure is larger than 1/2 pixel, it counts as pixel failure according to definition.

  • Page 41: Overview Acceptable Total Number Of Dot Defects

    2 bright subpixel + 6 black subpixel → 4 bright subpixel + 2 black subpixel 1 bright subpixel + 8 black subpixel 0 bright subpixel +10 black subpixel For more information, see the information sheet „Standards for Display Quality Inspection“ of eyevis GmbH.

  • Page 42: Chronological Effects

    EYE-LCD-6000-QHD-LD Chronological Effects False installation or use of the display during operating time may bring forth undesirable partly visible effects. The intern structure of imaging part (panel) may be changed by outside influences with partly visible effects. Following effects were recognised and are explainable: 9.4.1 “Image Sticking”...
  • Page 43 EYE-LCD-6000-QHD-LD How to minimize the Danger of Image Retention NOTICE! Reduce Ambient Temperature The ambient temperature and therefore the temperature inside the LCD display plays a decisive role for the appearance of image retention. The risk of image retention increases the higher the surrounding temperature is.
  • Page 44 EYE-LCD-6000-QHD-LD Summary Unlike permanent burn-in in phosphor-based displays, which is the result of a premature aging of the phosphors of individual pixels, and thus, is irreversible, image sticking in LCD panels can often be reversed to a point of total invisibility.

  • Page 45: Warranty Terms And Conditions

    Repair and Return The defective product is sent to eyevis by the customer and is repaired within 21 days. In this case eyevis bears the costs for eventually required components or the arising working time, as well as for the costs for the reshipment to the customer.

  • Page 46: Warranty Exclusions

    The reaction time to claim a right given by this warranty starts with the customer’s announcement of the claim to the eyevis GmbH. It is calculated in accordance to the standard service hours of the eyevis GmbH (monday- friday 9.00 AM to 5.00 PM, except bank holidays).

  • Page 47: Advised Procedure For Raising A Claim

    The customer will receive a service code and the eyevis GmbH will prepare the service work chosen by the customer. It is the customer’s duty to keep the product ready for collection (in cases of DOA the product has to be equipped with all cablings and mains adaptors before it is put in its box or packed).

  • Page 48: Correct Disposal

    EYE-LCD-6000-QHD-LD 10.8 Limitations of Liability In cases of slight negligent breaches of duty the liability of the eyevis GmbH is limited to the direct, foreseeable and contract-typical average damage. The slightly negligent breach of minor contractual obligations excludes the liability.

  • Page 49: Additional Support

    The content of this manual is furnished for information use only, is subject to change without notice, and should not be construed as a commitment by eyevis GmbH. eyevis GmbH resumes no responsibility or liability for any errors or inaccuracies that may appear in this documentation.
  • Page 50 EYE-LCD-6000-QHD-LD Notes:...
