Page 1: User Manual
LCD-4600/5500-M-USN-LD-BC EYEVIS LCD LINE User Manual Version 1.0 (Oktober 2014) Technical changes reserved. -
Page 2: Additional Support
The content of this document is solely informative, can be changed at any time without notice, and represents no obligation on the part of eyevis. eyevis assumes no responsibility or liability for any errors or inaccuracies that may appear in this document. -
Page 3: Table Of Contents
EYE-LCD-4600/5500-M-USN-LD-BC Table of Content Selecting a display � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 32 Safety/Sicherheit/ Sécurité... - Page 4 Prepare necessary information � � � � � � � � � � � � � � � � � � � � � � � 64 Approval by eyevis � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 64 Service code: RMA number �...
- Page 5 EYE-LCD-4600/5500-M-USN-LD-BC Revision History Page / Version Date Description Section 2014-10 Specification first issued. Version 1.0 | Oktober 2014...
-
Page 6: About This Manual
EYE-LCD-4600/5500-M-USN-LD-BC About this Manual Read and pay attention to this manual. It contains important information on the product. In particular, note all of the safety instructions and warnings. Keep this manual in a safe place! Warnings used NOTICE Indicates a hazard that could lead to damage or destruction of the product. The general warning symbol indicates a hazard that could lead to injuries or death. -
Page 7: Safety/Sicherheit/ Sécurité
EYE-LCD-4600/5500-M-USN-LD-BC Safety/Sicherheit/ Sécurité Safety Safety Precaution Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and/or fire. - Page 8 EYE-LCD-4600/5500-M-USN-LD-BC Repair — If any of the following conditions occurs, unplug the power cord from the AC outlet, and request a qualified service person to perform repairs. • When the power cord or plug is damaged. • When a liquid was spilled on the product or when objects have fallen into the product.
- Page 9 If dust collects inside the monitor, it may lead to excessive heat, outbreak of fire, or malfunction. Please request a cleaning of the inside of the monitor from an authorized Eyevis servicing dealer or service centre.
- Page 10 EYE-LCD-4600/5500-M-USN-LD-BC The Power Cord Do not damage the power cord nor place heavy objects on it, stretch it or over bend it. Do not use damaged extension cords. Damage to the cord may result in fire or electric shock. Use only the power cord supplied with the monitor. Do not use the power cord with a power tap.
- Page 11 EYE-LCD-4600/5500-M-USN-LD-BC NOTICE This is a class A product according EN 55022: 2010. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate counter measures. NOTICE To maintain compliance with EMC regulations, use shielded cables to connect to the following terminals: PC/AV DVI-D output terminal, PC/AV DVI-D input terminal, PC/AV HDMI input terminal, PC D-SUB input terminal, PC RGB input terminals, and...
-
Page 12: Zu Diesem Handbuch
EYE-LCD-4600/5500-M-USN-LD-BC Zu diesem Handbuch Lesen und beachten Sie dieses Handbuch. Darin stehen wichtige Informationen zum Produkt. Beachten Sie insbesondere alle Sicherheits- und Warnhinweise. Bewahren Sie diese Anleitung sorgfältig auf! Verwendete Warnhinweise ACHTUNG Kennzeichnet eine Gefahr, die zur Beschädigung oder Zerstörung des Produkts führen kann. -
Page 13: Sicherheitsvorkehrungen
EYE-LCD-4600/5500-M-USN-LD-BC Sicherheit Sicherheitsvorkehrungen Elektrizität erfüllt viele nützliche Aufgaben, kann aber auch Personen- und Sachschäden verursachen, wenn sie unsachgemäß gehandhabt wird. Dieses Produkt wurde mit Sicherheit als oberster Priorität konstruiert und hergestellt. Dennoch besteht bei unsachgemäßer Handhabung u.U. Stromschlag- und Brandgefahr. Um mögliche Gefahren zu vermeiden, befolgen Sie beim Aufstellen, Betreiben und Reinigen des Produkts bitte die nachstehenden Anleitungen. - Page 14 EYE-LCD-4600/5500-M-USN-LD-BC Gegenständen besteht Stromschlaggefahr bzw. die Gefahr von Kurzschlüssen zwischen den Bauteilen. Aus demselben Grunde dürfen auch keine Flüssigkeiten auf das Gerät verschüttet werden. Wartung — Versuchen Sie auf keinen Fall, selbst Wartungsarbeiten am Gerät durchzuführen. Durch das Entfernen von Abdeckungen setzen Sie sich hohen Spannungen und anderen Gefahren aus.
- Page 15 Vermeiden Sie es, den Monitor mit harten Gegenständen abzureiben oder zu berühren. Wir bitten um Ihr Verständnis, dass eyevis über die gesetzlich anerkannte Leistungshaftung hinaus keine Haftung für Fehler übernimmt, die sich aus der Verwendung durch den Kunden oder einen Dritten ergeben, und auch nicht für sonstige Funktionsstörungen oder Schäden, die während der...
- Page 16 Staub im Inneren des Monitors ansammelt, kann es zu einer Überhitzung des Geräts und in der Folge zu einem Brand oder Fehlfunktionen kommen. Bitte lassen Sie das Innere des Monitors von einem autorisierten eyevis-Händler oder einem eyevis Servicecenter reinigen. Bilder können auf diesem Monitor nicht gedreht werden. Wenn Sie den Monitor in vertikaler Ausrichtung verwenden, müssen Sie die Bilder zuvor...
- Page 17 EYE-LCD-4600/5500-M-USN-LD-BC ACHTUNG Dieses Gerät ist ein Produkt der Klasse A gemäß EN 55022: 2010. In Wohnräumen kann dieses Gerät Störsignale erzeugen, die durch entsprechende Abhilfemaßnahmen durch den Benutzer beseitigt werden müssen. ACHTUNG Verwenden Sie EMV-gerechte, abgeschirmte Kabel, um die folgenden Anschlüsse zu verbinden: PC/AV DVI-D-Ausgangsanschluss, PC/AV DVI-D-Eingangsanschluss, PC/AV HDMI-Eingangsanschluss, PC D-sub-Eingangsanschluss, PCRGB-...
- Page 18 EYE-LCD-4600/5500-M-USN-LD-BC À propos de ce Manuel Lisez et suivez ces instructions. Ils contient des informations importantes sur le produit. Faites particulièrement attention à toutes les consignes de sécurité et aux avertissements. Conservez ce manuel soigneusement! Des symboles d`avertissement utilisés ATTENTION Indique un danger qui peut endommager ou détruire le produit.
-
Page 19: Précautions De Sécurité
EYE-LCD-4600/5500-M-USN-LD-BC Sécurité Précautions de sécurité L’électricité remplit de nombreuses fonctions utiles, mais elle peut provoquer des blessures et des dégâts matériels si elle n’est pas utilisée correctement. Cet appareil a été conçu et fabriqué en attachant la plus grande importance à la sécurité. - Page 20 EYE-LCD-4600/5500-M-USN-LD-BC Entretien — N’essayez pas de réparer vous-même l’appareil. La dépose des couvercles peut vous exposer à une haute tension ou à d’autres dangers. Confiez toute réparation à un personnel qualifié. Réparation — Dans les cas suivants, débranchez le cordon d’alimentation au niveau de la prise secteur et demandez à...
- Page 21 Ne frottez pas, ne grattez pas le moniteur avec un objet dur. Il faut savoir que la Eyevis décline toute responsabilité en cas d’erreurs commises durant l’utilisation par le client ou par une tierce personne, ainsi qu’en cas de dysfonctionnement ou de dommage survenu à...
- Page 22 EYE-LCD-4600/5500-M-USN-LD-BC Veuillez vous assurer que la prise est installée près du système et est facilement accessible. Le cordon d‘alimentation est un dispositif de déconnexion. Le cordon d’alimentation N’endommagez pas le cordon d’alimentation, ne déposez pas d’objets lourds sur le cordon d’alimentation, ne tirez pas dessus et ne le pliez pas de manière excessive.
- Page 23 EYE-LCD-4600/5500-M-USN-LD-BC ATTENTION Ce produit appartient à la Classe A d‘après la norme EN 55022: 2010. Dans un environnement résidentiel, il peut provoquer des interférences radio et, dans ce cas, l’utilisateur peut être obligé de prendre les mesures nécessaires. ATTENTION Afin de satisfaire aux normes EMC, utiliser des câbles blindés pour connecter les bornes suivantes : Borne de sortie PC/AV DVI-D, borne d’entrée PC/AV DVI-D, borne d’entrée PC/ AV HDMI, borne d’entrée PC D-sub, bornes d’entrée PC RVB, et bornes...
-
Page 24: About Our Product
About our Product Product description With this LC display type, eyevis presents a special version of its seamless LCD optimised for the use in broadcast applications. Therefore the EYE-LCD-M-USN- LD-BC monitor provides several functions and features which make it the ideal solution for the installation of LCDbased video walls in broadcast environments. -
Page 25: Packaging
• 1 IR remote control sensor Way of packaging The eyevis display is packed in a carton box. To provide protection during transportation, the EYE-LCD display is surrounded with foam. The packaging is secure with banding and fastening clips. To unpack: Open cardboard box. -
Page 26: Installation Possibilities For Eye-Lcd-M Series
Optional wall mounting kit Optionally eyevis provides wall-mounting kits for the displays from the EYE- LCD-M series. These wall-mounting kits consist of wall-mounting brackets that have to be fixed to the backside of the display and an according wall-fixture. -
Page 27: Optional Stacking Frame
Special ventilation duct Optional display rack eyevis also provides display racks for the displays of the EYE-LCD-M series. These racks are designed to build up freestanding video walls with the stacking frame versions. -
Page 28: Installation/Assembly
When raising a video wall, please use the special cross spacers provided by eyevis. These are highly precise shaped metal pieces which guarantee exact distances between the individual modules of a video wall, these spacers are placed in the T-slot and screwed to every frame. -
Page 29: Landscape/Portrait Installation
EYE-LCD-4600/5500-M-USN-LD-BC Example: Video wall assembly 3x3 NOTE: Please insert the spacers in every junction of the displays in the tiled video wall. To assembly a video wall 3x3: Mount the stacking frames row by row Fix the stacking frames together Hang in the displays row by row. -
Page 30: Linking The Displays
EYE-LCD-4600/5500-M-USN-LD-BC Linking the displays The EYE-LCD-M series displays are especially designed for video wall applications. The size of the video wall matrix may range from 1x1 up to 10x10 displays. Displays within a video wall matrix have to be addressed consecutively from 0 - 99. -
Page 31: Dimensions Of Different Video Wall Configurations
EYE-LCD-4600/5500-M-USN-LD-BC Dimensions of different video wall configurations Video wall with 46” displays Individual unit 46“: Configuration 2x2: ca. 1025 mm (Housing) / 1,920 Pixel ca. 2050 mm / 3,840 Pixel Configuration 5x5: ca. 5125 mm / 9,600 Pixel Version 1.0 | Oktober 2014... -
Page 32: Video Wall With 55" Displays
EYE-LCD-4600/5500-M-USN-LD-BC Video wall with 55” displays Individual unit 55”: Configuration 2x2: ca. 1216 mm (Housing) / 1,920 Pixel ca. 2432 mm / 3,840 Pixel Configuration 5x5: ca. 6080 mm / 9,600 Pixel User Manual... -
Page 33: Connectors & Control
EYE-LCD-4600/5500-M-USN-LD-BC Connectors & Control Power cord connection ► Use the supplied power cord to connect your LCD panel to the wall outlet. ► Plug the female power connector into the male connector at the back of the LCD panel Input source connections Name Remarks Network... -
Page 34: Controlling The Display
EYE-LCD-4600/5500-M-USN-LD-BC Controlling the Display The Remote Control The menu functions of the OSD menu can be accessed with the eyevis Remote-Control (RC), see picture below. (To use the RC aim at the display’s IR-Receiver) ► To use the RC connect the IR sensor (see picture on the left) with the IR Input socket of the first LC display of the RS232 daisy-chain in the video wall. -
Page 35: Changing The Remote Control Batteries
EYE-LCD-4600/5500-M-USN-LD-BC Changing the Remote Control batteries Remove the battery cover Slide back and remove the battery cover in the direction of the arrow. Insert the batteries Align and insert two AAA batteries according to their plus and minus ports (as indicated on the button of the battery case of the remote control). -
Page 36: The Osd Menu
EYE-LCD-4600/5500-M-USN-LD-BC The OSD Menu NOTE Some settings depend on the input signal whether are available or not. Main Menu Main menu contains all submenus of the OSD. ► Main Menu Select Device Input Picture Setup Scaling Matrix Analogue RGB Settings Network Configuration Tools Status... -
Page 37: Input
EYE-LCD-4600/5500-M-USN-LD-BC Input Input menu is used for making common adjustments of the input. ► > Input > Input Input Source DVI-1 Autoscan Selects the input of the display. Input Source Press ◄ or ► to select the desired input source and then press ENTER. Options: DVI-1, DVI-2, RGB-1, RGB-2, CompV1, CompV2, S-Video Activates or deactivates automatic scanning for input signals. -
Page 38: Picture Setup
EYE-LCD-4600/5500-M-USN-LD-BC Picture Setup Picture Setup menu is used for making common adjustments of the picture. ► > > Input Picture Setup Color Temperature 9500 User Color Red User Color Green User Color Blue Manual BL Control Backlight Set Backlight Bright Set Backlight Dark Video Color Video Tint... -
Page 39: Scaling
EYE-LCD-4600/5500-M-USN-LD-BC Scaling Scaling menu is used for making common adjustments of the picture size. ► > Scaling > Scaling Picture Scaling FillAll H-Resolution V-Resolution H-Size V-Size H-Offset V-Offset H-Linearity 4095 V-Linearity 4095 Adjusts the picture scaling of the input signal. Picture Scaling Press ◄... -
Page 40: Matrix
EYE-LCD-4600/5500-M-USN-LD-BC Matrix Matrix menu is used for making common adjustments of the picture spitting over displays. ► > Scaling > Matrix Enable Matrix Size X Size Y Element X Element Y Matrix Scaling FillAll Frame X Frame Y Set Matrix Activates or deactivates the Matrix function of the display. -
Page 41: Analogue Rgb Settings
EYE-LCD-4600/5500-M-USN-LD-BC Analogue RGB Settings Analogue RGB Settings menu is used for making common adjustments of the analogue picture. ► > Analogue RGB Settings > Analogue RGB Settings Autoadjust Phase 2500 Frequency 2500 H-Position V-Position Options Disabled H-Visible 1000 V-Visible H-Total 1000 H-Start V-Start... -
Page 42: Network Configuration
EYE-LCD-4600/5500-M-USN-LD-BC Network Configuration Network Configuration menu is used for making common adjustments of the network settings. ► > Network Configuration > Network Configuration Netboard IP Address 192 168 000 062 Netboard Netmask 255 255 255 000 Netboard Gateway 192 168 000 001 Netboard TCP Port 7292 Set Netboard Value... -
Page 43: Tools
EYE-LCD-4600/5500-M-USN-LD-BC Tools Tools menu is used for making common adjustments of the utilities. ► > Tools > Tools Line Move Input Board Reset Framelock Video Framelock RGB Testpattern User Broadcast Mode V-Start Install RGB Activates or deactivates the screensaver of the display. Line Move Press ◄... -
Page 44: Status
EYE-LCD-4600/5500-M-USN-LD-BC Status Status menu shows common information about the status of the display. ► > Status > Status Fan 1 Speed Fan 1 Status Fan 2 Speed Fan 2 Status Fan 3 Speed Fan 3 Status CPU Temperature DVBPM Temperature Fan Sensor 1 Temperature Fan Sensor 2 Temperature Ambient Sensor... -
Page 45: Info
EYE-LCD-4600/5500-M-USN-LD-BC Info Info menu shows common information about the hardware and software of the display. ► > > Info Info LCD Panel CPU HW Version LCC201 CPU FW Version 2.58 DB Version 2.58 SB FW Version C70I02VI String description of the LCD panel (only read) LCD Panel Press ◄... -
Page 46: Power Scheduler
EYE-LCD-4600/5500-M-USN-LD-BC Power Scheduler Power Scheduler menu is used for making common adjustments for switching on / off the display in specific time. ► > Power Scheduler > Power Scheduler Scheduler Menu Mon-Fri 08:00:00-18:00:00 From Active Mon-Fri 08:00:00-18:00:00 Not Active Mon-Fri 08:00:00-18:00:00 Start Time Not Active... -
Page 47: Configuration
EYE-LCD-4600/5500-M-USN-LD-BC Configuration The eyeDeviceSetup software is available to help you configure the devices. The software is stored on the CD provided. NOTE: The devices have to be configured at the DIP switch before they can be commissioned for the first time. General information The eyeDeviceSetup software is used to perform different tasks: •... -
Page 48: The Eyedevice Setup Software
EYE-LCD-4600/5500-M-USN-LD-BC The eyeDevice Setup Software eyevis has developed the eyeDeviceSetup software for setting the devices and devices. The EC-Lcontrol program is used in conjunction with the devices or eyeDeviceSetup.exe ESP devices for colour adjustment. However, all other settings are programmed with the eyeDeviceSetup software. -
Page 49: The Load/Save Area
EYE-LCD-4600/5500-M-USN-LD-BC The Load/Save area In this area of the window, you can load and save configurations as well as determine the size of the video wall. File Configuration Load Loads a configuration file saved on the PC (for example the saved file of the first system configuration). -
Page 50: The Parameter Area
EYE-LCD-4600/5500-M-USN-LD-BC The settings are displayed and can be changed in this area of the screen. All settings are segmented in following tabs: • User Parameters for adjusting the signal functions. • Setup Basic password, device and scaler settings of the device. •... -
Page 51: Establishing Communication Via Eyedevice Setup
EYE-LCD-4600/5500-M-USN-LD-BC Establishing Communication via eyeDevice Setup This section describes how to establish the communication with the devices with the help of the eyeDevice Setup software. eyeDeviceSetup.exe NOTE The illustrations and certain descriptions in this manual may vary due to development process. Establishing communication ►... -
Page 52: Entering The Wall Size
EYE-LCD-4600/5500-M-USN-LD-BC Entering the wall size In the Wall size field, you can enter the number and layout of the devices: 1. In the first window, select the number of columns, which is 2 in the example above. In the second window, select the number of rows, which is 2 in the example above. -
Page 53: Settings Of The Parameter Area
EYE-LCD-4600/5500-M-USN-LD-BC Settings of the parameter area User In the User menu, you can find parameters for adjusting the signal functions and the device matrix. Power Control Power Activates/deactivates the check box to switch the display on/off. Source Input Source Select input signal of the input board (DVI-1, DVI-2, RGB-1, RGB-2, CompV1, CompV2, SVideo) Autoscan... -
Page 54: Setup
EYE-LCD-4600/5500-M-USN-LD-BC Setup The basic password, display and scaler settings can be performed on this page. Security Setting User password Administrators can enter a password for users here when logged in as Admin. Admin password Administrators can change the admin password here when logged in as Admin. -
Page 55: Service
EYE-LCD-4600/5500-M-USN-LD-BC Analogue RGB Settings Phase Phase of the analog signal Frequency Frequency of the analog signal H-Position Horizontal Picture Shift V-Position Vertical Picture Shift Options [Disabled, Mode1, Mode2, Mode3] H-Visible H-Resolution in Pixels V-Visible V-Resolution in Pixels H-Total H-Total in Pixels H-Start H-Start in Pixels V-Start... -
Page 56: Status
EYE-LCD-4600/5500-M-USN-LD-BC Status In this window, you can call up current status information such as errors, temperature, firmware etc. Status Fan 1 Speed Speed of Fan 1 Fan 1 Status Fan 1 status (OK indicates active / !! indicates inactive) Fan 2 Speed Speed of Fan 2 [Depends on Fan Temperature] Fan 2 Status Status of Fan 3 (OK indicates active / !! indicates... -
Page 57: Preference
EYE-LCD-4600/5500-M-USN-LD-BC Preference The communication to the first device is defined on this page. Communication Settings Use local area network With an Ethernet connection between the PC and the first device • Socket Standard 7992 • First device IP Address IP address of the connected device (the first device) •... -
Page 58: Reports
Only administrators have the authorisation to send commands (logon with password). Command sequences are used to control the devices. A separate manual for serial commands is available to show you how to generate command sequences. This can be requested from the eyevis service. User Manual... -
Page 59: Troubleshooting Guide
EYE-LCD-4600/5500-M-USN-LD-BC Troubleshooting Guide Before calling service personnel, please check the following chart for a possible cause of the trouble you are experiencing. Symptom Check these things • No picture Make sure the power cord is plugged in • Maybe the power is OFF or Standby •... -
Page 60: Effects In Continuous Operation Of Lcds
EYE-LCD-4600/5500-M-USN-LD-BC Effects in continuous operation of LCDs False installation or use of the display during operating time may bring undesirable partly visible effects. The internal structure of LCD panel may be changed by outside influences with partly visible effects. "Image Sticking" This phenomenon which named alternatively "image retention", "ghost image", "memory effect"... -
Page 61: Prevention Of Image Retention
EYE-LCD-4600/5500-M-USN-LD-BC Prevention of Image Retention NOTICE! Reduce ambient temperature The ambient temperature and therefore the temperature inside the LCD display plays a decisive role for the appearance of image retention. The risk of image retention increases the higher the surrounding temperature is. -
Page 62: Evaluation Of Visual Range
EYE-LCD-4600/5500-M-USN-LD-BC Evaluation of Visual Range Failure of pixel A image point (Pixel) consist of 3 sub pixel with basic colour red, green and blue. The physical dimension of a pixel (also called pixel pitch) differs depending on the model (look at the data sheet for more information). If a pixel failure is larger than 1/2 pixel, it counts as pixel failure according to definition. -
Page 63: Overview Acceptable Total Number Of Dot Defects
EYE-LCD-4600/5500-M-USN-LD-BC Overview acceptable total number of dot defects Isolated pixel errors can not be eliminated for production reasons. The standard ISO 9241-307 specify the acceptable total number of dot defects for class II panels. You can see the tolerance limits in the following table: Acceptable total number of dot defects according to ISO 9241-307 for class II panels (in relation to the resolution) Defect type 1... -
Page 64: Warranty Terms And Conditions
Duration and validity of warranty The specified product is under warranty for 24 months beginning from the date of delivery by eyevis , valid for the European Union. 12 months applies to products that were purchased outside the European Union. Warranty services during the warranty period do not extend the validity period of the warranty. -
Page 65: Warranty On Repairs
The reaction time to claim a right given by this warranty starts with the customer’s announcement of the claim to eyevis. It is calculated in accordance with the standard service hours of the eyevis (Monday - Friday 6:00 AM to 6:00 PM local German time, except German bank holidays). -
Page 66: Advised Procedure For Raising A Claim
The customer has to pack the defective device properly in the original box, to label it as fragile, and to attach the RMA number visibly on the box. eyevis can provide a new original box on request. The customer is liable for damages caused by the use of improper or unsuitable packaging. -
Page 67: Limitations Of Liability
The warranty shall not apply to repairs or service necessitated by normal wear and tear or for lack of reasonable and proper maintenance. As far as the liability of eyevis is excluded or limited, this also applies to the personal compensation liability of its staff, employees, associated employees, agents, and auxiliary persons. -
Page 68: Appendix
EYE-LCD-4600/5500-M-USN-LD-BC Appendix Appendix: Technical specifications EYE-LCD-4600/5500-M-USN-LD-BC LCD MODEL: EYE-LCD-4600-M-USN-LD-BC EYE-LCD-5500-M-USN-LD-BC Installation: Landscape/Portrait Screen Size: 46“ (ca.116 cm) 55“ (ca.139 cm) Display Resolution: 1920 × 1080 Pixel (full HD) Colours: 16,7 Mio. Brightness: 700 cd/m / (ca. 400 cd/m for 3200K version) -
Page 69: Appendix: Dimensions
EYE-LCD-4600/5500-M-USN-LD-BC Appendix: Dimensions EYE-LCD-4600-M-USN-LD (Dimentions in mm) Version 1.0 | Oktober 2014... -
Page 70: Eye-Lcd-5500-M-Usn-Ld
EYE-LCD-4600/5500-M-USN-LD-BC EYE-LCD-5500-M-USN-LD (Dimentions in mm) 687,4 User Manual... -
Page 71: Frame Eye-Lcd-4600-M-Usn-Ld
EYE-LCD-4600/5500-M-USN-LD-BC Frame EYE-LCD-4600-M-USN-LD (Dimentions in mm) Frame EYE-LCD-5500-M-USN-LD (Dimentions in mm) Version 1.0 | Oktober 2014... -
Page 72: Appendix: Updating Firmware And Database
EYE-LCD-4600/5500-M-USN-LD-BC Appendix: Updating firmware and database Updating firmware of the CPU To update the firmware of the CPU: Switch off the LCD device. Create a direct serial connection with a cable between the display and a COM port of your PC. Open the eyeBootLoader software. - Page 73 EYE-LCD-4600/5500-M-USN-LD-BC Select the COM port you use in the "SETUP MENU" and press "OK". Open the drop-down menu and select the according hardware. Choose the firmware version you want to install. Switch the LCD on and the firmware update starts. You can see the progress in the status bar.
-
Page 74: Upgrading The Database Of The Display
EYE-LCD-4600/5500-M-USN-LD-BC Upgrading the database of the display To upgrade the database of the display: Be sure, that there is a connection between display and PC. Open the eyeDeviceSetup software. Choose the display you want to update. Open the Service tab, press the button and restart ERASE THE DATABASE the display. -
Page 75: Updating The Firmware Of The Scaler
EYE-LCD-4600/5500-M-USN-LD-BC Updating the firmware of the scaler To updating the firmware of the scaler: Power Off the display. Connect the flasher cable (shown in picture) to the PC. Connect the flasher cable to port "COM2 Out" on the display. Set dip switch No. 8 to On. Start the "Flash Upgrader Software". -
Page 76: Appendix: Product-Design Related Characteristics Of Eyevis Super Narrow Bezel Displays
EYE-LCD-4600/5500-M-USN-LD-BC Appendix: Product-design related characteristics of eyevis super narrow bezel displays This chapter describes the care which must be exercised in handling LCD panel. The LCD panels are so sensitive that its material and structure may be easily damaged or lost due to carelessness on the part of users or operators. -
Page 77: Holding And Moving
EYE-LCD-4600/5500-M-USN-LD-BC Visible sheet guide boss & clip Sheet guide boss & clips may be visible at side view. (4 kinds of shape). Super narrow does not have enough mechanical design margin. Left side Right side Bottom side Holding and moving ►... -
Page 78: Shock Test
EYE-LCD-4600/5500-M-USN-LD-BC Shock Test NOTICE Dropping the display. ► Do not drop from over 5 cm height. Height Model Panel 5 cm 10 cm 15 cm 20 cm passed failed passed failed EYE-LCD-4600/5500-M-USN-LD passed passed failed passed failed Panel #1 Panel #2 Panel #3 Panel #4 Twist Angle... -
Page 79: Appendix: Rs232 Protocol
Appendix: RS232 Protocol General description The eyevis LC Displays can be controlled using an ASCII-serial protocol. Each display is assigned an ID and can be addressed in the protocol using this ID. Commands can either be sent to a single ID or to all devices simultaneously (broadcast mode). - Page 80 EYE-LCD-4600/5500-M-USN-LD-BC Command SET(1;Input;0) Response ACK(1) Set the current input source to Display Port. GET(ID;Command) ID = Display address Command = Command from the display database The actual values of the display will be returned. e.g.: Command GET(1;Power) Response DATA(1;Power;1) The display no. 1 is switched on. e.g.: Command GET(1;Input)
-
Page 81: Command List
EYE-LCD-4600/5500-M-USN-LD-BC Command list Possible Default Function Command Comment Values Values Sending to an individual ID will enable Switch the LCD On or Off Power 0=Off, 1=On Sleep mode. SET(0;Power;0) will set the entire wall to deep sleep mode. 0=DVI-1, 1=DVI-2, 2=RGB-1, 3=RGB-2, Input Source... - Page 82 EYE-LCD-4600/5500-M-USN-LD-BC 0=1:1, 1 = FillAll, Only applicable with DVI and RGB Picture Scaling Picture Scaling 2=FillAspect, Sources 3 = User 0=Fill4:3, 1=Fill16:9, 2=Clip4:3, 3=Clip16:9, Only applicable with CompV1, Video Scaling Video Scaling 4 =FillAll, CompV2, SVideo 5=Clip4:3LB to 16:9, 6 = User V-Resolution V-Resolution Read Only Value...
- Page 83 EYE-LCD-4600/5500-M-USN-LD-BC Fan 1 Speed Fan 1 Speed 24-63 Read Only Fan 2 Speed Fan 2 Speed 24-63 Read Only 0=Not Working Fan 1 Status Fan 1 Status Read Only 1=Working 0=Not Working Fan 2 Status Fan 2 Status Read Only 1=Working CPU Temperature CPU Temperature...
-
Page 84: Index
EYE-LCD-4600/5500-M-USN-LD-BC Index TOLERANCE LIMITS TROUBLESHOOTING ASSEMBLY MALFUNCTION EQUIPMENT MURA VIDEO WALL VIDEO WALL CONFIGURATIONS ON-SCREEN-DISPLAY BATTERIES NAVIGATING CHANGING OPENING WARRANTY OSD MENU ACCESSORIES POWER SCHEDULER CLAIM DURATION COSTS EXCHANGE LEGAL PACKAGING EXCLUSIONS LIMITATIONS SERIAL NUMBER BOX CONTENT PACKING SERVICE RAISING A CLAIM PIXEL VALIDITY REACTION TIME... - Page 85 Notes:...
- Page 86 Fax: +49 (0)7121-4 33 03-22 Hotline: +49 (0)7121-4 33 03-290 (netPIX & eyeCON) Hotline: +49 (0)7121-4 33 03-291 (Cubes & Displays) web: www.eyevis.de e-mail: info@eyevis.de service@eyevis.de service: Version: 1.0 | Oktober 2014 Copyright © 2014 eyevis GmbH. All rights reserved.
