Repair Parts List - Aventics C-2 Service Information

Old Part Number New Part
Number
-538975-00000 R431000091
-850012-00000 R431000110
P –050756-00001 R431002759
-850050-00000 R431000127
-850015-00000 R431000113
SEE KIT SEE KIT
SEE KIT SEE KIT
-850046-00000 R431000126
SEE KIT SEE KIT
-850019-00000 R431000114
SEE KIT SEE KIT
P –049882-00010 R431002387
P –049882-00044 R431002397
-850022-00000 R431000116
-521391-00000 R431000021
-850023-00000 R431000117
-850024-00000 R431000118
-850025-00000 R431000119
-850026-00000 R431000120
SEE KIT SEE KIT
850028 R431000121
*NOTE: Parts marked with an asterisk are recommended spares to be carried in stock at all times, Suggested quantities are 100% for rubber parts and 25%
for all other parts recommended. Spare parts may be ordered in Kit Form Pg. No R431004938 (Old No. P –059191-00000)

REPAIR PARTS LIST

A
Fig. 3. Assembly View
Ref.
No.
C-2 RELAY VALVE, complete
RELAY VALVE PORTION complete
(Includes Ref. Nos. 2 to 42, inclusive)
2 BODY, Relay Valve
VALVE, Supply complete (Includes
3,5,9,10 and R431000128)
3 CAGE, Supply Valve
4* RING, 1-7/16" O.D. Supply Valve
Cage Packing
5* SPRING, Supply Valve
SEAL, Supply Valve, complete
(Includes 6,7, and 8)
6 HOUSING, Supply Valve Seal
7* SEAL, Supply Valve
8 RETAINER, Supply Valve Seal
9* RING, 5/8" O.D. Supply V. Seal
10 RING, Supply Valve Retaining
11 RING, Supply Valve Cage Retaining
20 STEM, Diaphragm
21* SPRING, Diaphragm Stem
VALVE, Exhaust, complete (Includes
22,26,27,29, and R431000119)
22 CAGE, Exhaust Valve
SEAL, Exhaust Valve, complete
(Includes 23, 24, and 25)
23 HOUSING, Exhaust Valve Seal
24* SEAL, Exhaust Valve
25 RETAINER, Exhaust Valve Seal
Prices will be quoted upon application
Orders should give PART NUMBER and NAME of part wanted
SEE KIT
SEE KIT
SEE KIT
P –049921-00003 R431002551
P –049882-00010
-850030-00000
-850031-00000 R431000123
SEE KIT
P –067541-00000 R431007214
P –051181-00000 R431002887
P –049976-00004 R431002567
SEE KIT
P –050394-00001 R431002633
P –049871-00004 R431002350
P –049901-00020 R431002419
-527583-00000 R431000048
-529161-00000 R431000051
SEE KIT
P –050395-00000 R431002634
P –049832-00149 R431002242
P –049832-00149 R431002242
P –049876-00001 R431002357
Page 3
SEE KIT 26* RING, 15/16" O.D. Ex.V. Seal
Housing Packing
SEE KIT 27* SPRING, Exhaust Valve
SEE KIT 28* RING, 1-5/8" O.D. Cage Packing
29 RING, Exhaust Valve Retaining
R431002387 30 RING, Exhaust Valve Cage
R431000122 DIAPHRAGM complete (Includes
35, 36, 37, three of 38 and 39)
35 FOLLOWER, Diaphragm
SEE KIT 36* DIAPHRAGM
37 PLATE, Diaphragm Clamping
38 SCREW, Diaphragm Clamping
(3 req'd)
39 NUT, Diaphragm Clamping
(3 req'd)
SEE KIT 40* GASKET, 9/16" Port
41 COVER, Diaphragm
42 BOLT, 5/16" x 1-1/4"
Diaphragm Cover (6 req'd)
43 NUT, 5/16" x 1-1/4"
47 STRAINER (2 req'd)
48 RING, Strainer Retaining (2 req'd)
SEE KIT 49* GASKET, Pipe Bracket
50 BRACKET, Pipe
51 BOLT, 3/8" x 1-7/8"
Pipe Bracket (3 req'd)
52 BOLT, 3/8" x 2-1/4" Pipe Bracket
53 NUT, 3/8" (2 req'd)
Pipe Bracket (3 req'd)
