geo-FENNEL CrossPointer5 SP User Manual page 15

EN
KEYPAD
1. LED horizontal line
2. LED vertical line
3. Button pulse function
4. LED laser dot function
5. ON/OFF-LED
6. Button on/off laser dots
7 . LED MANUAL function
8. Button on/off laser lines
1
3
2 5
4
7
8
6
POWER SUPPLY
Unscrew the instrument from the base part and open the battery compartment. Insert 3 x AA Alkaline
batteries (ensure correct polarity). Close the battery compartment and fix the instrument on the base
part again.
15
