Summary of Contents for Blanco BCCT302
- Page 1 Instructions for the Use and Care and Installation of BCCT302 Touch Control Cooktop...
- Page 3 Go to www.blanco-australia.com and fill in the subscription details. You will find that the clean lines and modern look of your Blanco cooktop blends in per- fectly with your kitchen décor. It is easy to use and performs to a high standard.
-
Page 4: Safety Warnings
SAFETY WARNINGS · Read the following carefully to avoid an electric shock or fire. · It is most important that this instruction book should be retained with the appliance for future reference. · Should the appliance be sold or transferred, always ensure that the book is left with the ap- pliance in order that the new owner can get to know the functions of the appliance and the relevant warnings. - Page 5 All the operations relating to installation/replacement (electrical connections) must be carried out by specialised personnel in conformity with the regulations in force. Important Avoid spilling liquid, therefore to boil or heat liquids, reduce the heat. Do not leave the heating elements on with empty pots and pans or without receptacles. When you have finished cooking, switch off the relevant heating element.
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS These instructions address specialised installers and serve as a guide for installation, adjustment and maintenance in conformity with the laws and regulations in force. If a built-in oven or any other appliance that generates heat must be fitted directly under the glass- ceramic cooktop, COOKTOP MUST BE SUITABLY INSULATED in such a way that the heat generated by the oven, measured on the bottom right of the cooktop, does not exceed 60°C. - Page 7 The domestic appliance is designed to be built into a worktop as illustrated in the specific figure. Apply sealant around the entire perimeter (cut-out dimensions Fig.1B). Fix the domestic appliance on the worktop by means of the 4 brackets provided, taking the thickness of the worktop into ac- count (Fig.1A).
-
Page 8: Use And Maintenance
USE AND MAINTENANCE • Maintenance Remove any residues of food and drops of grease from the cooking surface using the special scraper supplied (Fig.3). Fig.3 Clean the heated area as thoroughly as possible using SIDOL, STAHLFIX or similar products and a cloth/paper, then rinse with water and dry with a clean cloth. - Page 9 • Functioning (Fig.4) (R1) (R2) Fig.4 A = Sensor ON/OFF B = Sensor (-) C = Sensor (+) D = Cooking zone selection sensor E = Cooking zone selection display (R1-R2) - The appliance can be switched on by selecting the start sensor A (ON/OFF). An appears on all displays for 10 seconds.
- Page 10 key function to modify the hob settings. • Heat up (Rapid heating): The “Heat up” function can be used to set the cooking zone to its maximum temperature for a specified period of time, after which the temperature will return to a lower value selected previously. To activate the Heat up function select the wanted cooking zone using sensor D until position 9 is reached, press sensor C (+) and the display (next to 9) shows a decimal point (•), to indicate that the Heat up function is active.
- Page 11 Consider the following advice and the instructions in the table before contacting the after- sales service in case a problem arises • If the hob does not work, check that a black-out has not occurred. • If the hob has gone off during normal operation, check there are no objects on the Touch Control keys.
- Page 12 Notes - 12 -...
- Page 13 Notes - 13 -...
- Page 14 Notes - 14 -...
- Page 15 We appreciate your feedback. Please review our products on www. blanco-australia.com...
- Page 16 Printed on recycled paper 3LIP0440_ rev_10/03/2014...
