Introduction
ALARM OUTPUT
MODEL CAT3-(
( E )
OPTION
(4)
HIGH OPEN COLLECTOR
(5)
HIGH TTL / CMOS
(6)
HIGH RELAY ONE SPDT, CONTACT RATED @ 2A 30V
(7)
LOW OPEN COLLECTOR
(8)
LOW TTL / CMOS
(9)
LOW RELAY ONE SPDT, CONTACT RATED @ 2A 30V
NOTE: WHEN ALARM OPTION IS SELECTED, (AC) POWER IS NOT AVAILABLE.
USE REMOTE ACC39B POWER SUPPLY.
ENCLOSURE STYLE
MODEL CAT3-(
( F )
OPTIONS
(1)
GENERAL PURPOSE.
2.6"L X 2.6"H X 2.6"W MINIMUM MOUNTING SPACE.
(D)
2" LONG DIN RAIL MOUNT SINGLE UNIT.
UP TO 20 CAT3 UNITS CAN BE MOUNTED ON A SINGLE
RAIL. ADD 2" PER UNIT.
(E3)
EXPLOSION-PROOF (ALL CONDUIT PORTS ARE ¾" FNPT)
(E3M)
EXPLOSION-PROOF (CONDUIT PORTS D2 & D3 = M20 THR'D;
(E4)*
EXPLOSION-PROOF - FOR USE WITH AC POWERED CAT ONLY
(NOT Ex d SYSTEM CERTIFIED)
*FOR Ex d CERTIFIED SYSTEM USE E6 OR E6M ENCLOSURE
(E6)
EXPLOSION-PROOF STAINLESS STEEL
(ALL CONDUIT PORTS ARE ¾"FNPT)
(E6M)
EXPLOSION-PROOF STAINLESS STEEL
NOTE: FOR UL LISTED EXPLOSION-PROOF APPLICATIONS CONTACT FACTORY
HP-312
)-(
)-(
)-(
)-(
E
)-(
)-(
)-(
)-(
)-( )-(
)
)-(
F
)-(
)
(M20 NOT AVAILABLE FOR CANADA)
.
CAT3
