Dwyer Instruments PHO-1 Specifications-Installation And Operating Instructions

The microprocessor based pH/ORP/Temperature Meter
offers quick response and high accuracy. Simultaneously mea-
sure and display pH from 0 to 14 pH (0 to 1999 mV) and tem-
peratures up to 200°F (100°C). Model PHO-1 meter features
manual or automatic temperature compensation, auto buffer
recognition, and data logging capabilities. The recording inter-
val can be defined by the user. The meter accepts any pH
electrode with a BNC connector. For additional convenience,
select model PHO-1K kit, which contains a meter, RS-232
cable, batteries, software, pH electrode, temperature probe,
gender changer, carrying case and manual.
Measurement Range
pH 0 to 14 pH
0 to 600 mV
mV
601 mV to 1999 mV
Temp (°C) 0 to 100°C
Temp (°F) 32 to 200°F
DWYER INSTRUMENTS, INC.
P.O. BOX 373 • MICHIGAN CITY, INDIANA 46361, U.S.A.
Model PHO-1 pH/ORP/Temperature Meter
Specifications - Installation and Operating Instructions
Resolution
Accuracy
0.001 pH ±0.01 pH
±(0.05% + 1 digit)
0.1 mV
±0.1%
0.1°C ±0.5°C
0.1°F
±0.9°F
3-5/16
(84.14)
2-31/32
(74.9)
7-11/32
(186.20)
2-13/16
(71.4)

SPECIFICATIONS

Input: pH electrode with BNC connector, temperature
probe.
Range: pH: 0.00 to 14.00 pH; mV: 0 to 1999 mV.
Temperature: 32 to 200°F (0 to 100°C).
Operating Temperature: 32 to 122°F (0 to 50°C).
Compensated Temperature Limit: Manual (MTC): 32 to
200°F (0 to 100°C); Automatic (ATC): 32 to 200°F (0 to
100°C).
Operating Humidity: Max. 80% RH.
Sampling Rate: About 1.5 time/sec.
Battery LIfe: Approximately 120 hours.
Power Supply: Six "AA" batteries.
Power Current: Approximately 20 mA DC.
Data Output: RS-232 PC serial interface.
Dimension: 7.4˝ x 2.9˝ x 2˝ (187 mm x 73 mm x 53 mm).
Weight: 1 lb (.45 kg) meter only.
Phone: 219/879-8000
Fax: 219/872-9057
Bulletin E-90-PHO
2
(50.8)
1-5/8
(41.2)
CRITICAL DIMENSION
STANDARD TOLERANCES UNLESS NOTED:
ALL DECIMAL DIMENSIONS ±.005
ALL ANGLES ±1˝
www.dwyer-inst.com
