TEFAL RK705 Manual

TEFAL RK705 Manual

10-in-1 rice & multi-cooker
Hide thumbs Also See for RK705:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
EN
10-in-1 Rice & Multi-Cooker
www.tefal.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RK705 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TEFAL RK705

Summary of Contents for TEFAL RK705

  • Page 1 10-in-1 Rice & Multi-Cooker www.tefal.com...
  • Page 3 10 cups 10 cups MAX. MAX.
  • Page 4 CONTROL PANEL...
  • Page 5 IMPORTANT SAFEGUARDS SAFETY INSTRUCTIONS Read and follow the instructions for use. Keep them safe. • This appliance is not intended to be operated by means of an external timer or a separate remote- control system.* • This appliance shall not be used by children from 0 year to 8 years.* •...
  • Page 6 and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. • Children should be supervised to ensure that they do not play with the appliance. • As this appliance is for household use only, it is not intended for use in the following applications and the guarantee will not apply for: –...
  • Page 7 cloth or sponge. Drying accessories and parts in contact with food with a dry cloth. • If the symbol is marked on the appliance, this symbol means “Caution: surfaces may become hot during use”. • Caution: the surface of heating element is subject to residual heat after use.

  • Page 8: Connecting To The Power Supply

    • For your safety, this appliance complies with the safety regulations and directives in effect at the time of manufacture (Low-voltage Directive, Electromagnetic Compatibility, Food Contact Materials Regulations, Environment…). • Check that the power supply voltage corresponds to that shown on the appliance (alternating current).

  • Page 9: Protect The Environment

    • Do not put any food or water into the appliance until the bowl is in place. • Respect the levels indicated in the recipes. • Should any part of your appliance catch fire, do not attempt to put it out with water.

  • Page 10: Before The First Use

    DESCRIPTION 1 Steam basket e “MENU” key 2 Measurements for water and rice f “+” key - time increase 3 Removable ceramic bowl g “DELAYED START” key 4 Measuring cup 14 Function indicators 5 Rice spoon a “RICE” function 6 Soup spoon b “RISOTTO”...

  • Page 11: Preparation Before Cooking

    THE APPLIANCE • This multicooker is equipped with 10 cooking programs: Rice, Risotto, Reheat, Oatmeal, Slow Cook, Steam/Soup, Yogurt, Baking/Dessert, Browning, Keep Warm. The multicooker also features an adjustable timer and delayed start. • When the power cord is installed into the power outlet and into the socket on the cooker base, the appliance will ring a long sound “Beep”, all the indicators on the control panel will light up for an instant.
  • Page 12 When steam cooking • The quantity of water must be appropriate and always be lower than the steam basket bottom. • Exceeding this level may cause overflows during use. • Place the steam basket onto the bowl – fig.5. • Add the ingredients in the basket. FOR ALL FUNCTIONS •...
  • Page 13 • The maximum quantity of water + rice should not exceed the highest mark inside the bowl – fig.8. Depending on the type of rice, quantities of water may need adjustment. See the table below. COOKING GUIDE FOR WHITE RICE - 10 cups Rice Weight of Water measurement...
  • Page 14 COOKING GUIDE FOR DIFFERENT KINDS OF RICE OR OTHER RICES Water Rice Weight measurement Type of rice measurement Serves of rice in the bowl in cups (+ rice) 900 g 6 cup mark 7pers.-8pers. Japanese rice 1500 g 10 cup mark 10pers.-12pers.
  • Page 15 SOME RECOMMENDATIONS FOR BEST RESULTS WHEN COOKING RICE • Measure the rice and rinse it thoroughly under running water in a sieve for 2 minutes (except for risotto rice which should not be rinsed). Then place the rice in the bowl together with the corresponding quantity of water. •...

  • Page 16: "Reheat" Function

    • At the end of cooking, the buzzer will ring twice “beep beep”, the multicooker will start to simmer and the screen will count down the simmering time: 10 minutes. • After simmering, the buzzer will ring several times, the multicooker will enter keep warm status with the “Keep Warm”...

  • Page 17: "Slow Cook" Function

    “SLOW COOK” FUNCTION • Press “Menu” key to select function “Slow Cook”. The screen displays “--”, the light of “Start” flickers, then press “Start” key. The multicooker enters into “Slow Cook” cooking status. The light of “Start” lights up and the LED screen displays the remaining time.
  • Page 18 CHOICE OF INGREDIENTS FOR YOGURT Milk What milk should you use? • All our recipes (unless otherwise stated) are prepared using cow’s milk. You can use plant milk such as soy milk for example as well as sheep or goat’s milk but, in this case, the firmness of the yogurt may vary depending on the milk used.
  • Page 19 Fermentation time • Your yogurt will need between 6 and 12 hours of fermentation, depending on the basic ingredients and the result you want to achieve. Liquidity Firm Sweet Acidic • Once the yogurt cooking process is finished, the yogurt should be placed in a refrigerator for at least 4 hours and it can be kept max 7 days in refrigerator.

  • Page 20: Keep Warm Function

    “KEEP WARM” FUNCTION • Press the “Keep Warm” key, the appliance will enter into “Keep Warm” status. • At the end of the keep warm process, please stop the machine manually by pressing “Keep Warm/Cancel” key. Recommendation: In order to keep the rice tasting fresh, please limit the holding time within 6 hours.

  • Page 21: Cleaning And Maintenance

    CLEANING AND MAINTENANCE • Always make sure the multicooker is unplugged and completely cooled down before cleaning and maintenance. • It is strongly advised to clean the appliance after each use with a sponge – fig.13. Bowl, steam basket (fig.14) •...
  • Page 22 TECHNICAL TROUBLESHOOTING GUIDE Malfunction Causes Solutions description Plug in appliance. If the lights still don’t come on Any indicator Appliance is not plugged and there is no heat then light is off and send the appliance to an no heat. authorized service center for repair.
  • Page 23 Malfunction Causes Solutions description Rice half cooked or takes Not sufficiently simmered. too long too cook. Send to the authorized Automatic service center for repair. keep warm fails (product stays in cooking program, or no heating). The sensor on the top Stop the appliance and circuit is open or there is a restart the program.
  • Page 24 Conditions & Exclusions TEFAL/T-FAL shall not be obliged to repair or replace any product which is not accompanied by a valid proof of purchase. The product can be taken directly in person or must be adequately packaged and returned, by recorded delivery (or equivalent method of postage), to a TEFAL/T-FAL authorised service centre.

  • Page 25: For Australia Only

    The repair process may require a longer time if the product is not locally sold by TEFAL/T-FAL. If the product is not repairable in the new country, the international TEFAL/ T-FAL guarantee is limited to a replacement by a similar or alternative product at similar cost, where possible.
  • Page 26 TEFAL/T-FAL INTERNATIONAL GUARANTEE: COUNTRY LIST www.tefal.com    GROUPE SEB ARGENTINA S.A. 2 años Billinghurst 1833 3° 0800-122-2732 ARGENTINA 2 years C1425DTK Capital Federal Buenos Aires ՓԲԸ <<ԳՐՈՒՊՊԱ ՍԵԲ>> ՀԱՅԱՍՏԱՆ 010 55-76-07 2 տարի 2 years 125171,ՄՈՍԿՎԱ, ԼԵՆԻՆԳՐԱԴՅԱՆ ARMENIA ԽՃՈՒՂԻ, 16A, ՇԻՆ.3...
  • Page 27 FINLAND 2 years Kutojantie 7 02630 Espoo GROUPE SEB France France Continentale + 1 an Service Consommateur Tefal 09 74 50 47 74 Guadeloupe, Martinique, 1 year 112 Ch. Moulin Carron, TSA 92002 Réunion, Saint-Martin 69134 ECULLY Cedex GROUPE SEB DEUTSCHLAND GmbH /...
  • Page 28 NORGE 815 09 567 Tempovej 27 2 years NORWAY 2750 Ballerup ‫ﻋ ُﻣﺎﻥ ﺳﻠﻁﻧﺔ‬ 24703471 1 year www.tefal-me.com OMAN 801 300 420 2 lata GROUPE SEB POLSKA Sp. z o.o. POLSKA koszt jak za 2 years ul. Bukowińska 22b POLAND połączenie lokalne...
  • Page 29 2 años ESPAÑA 902 31 24 00 C/ Almogàvers, 119-123, Complejo SPAIN 2 years Ecourban 08018 Barcelona TEFAL SVERIGE SUBSIDIARY OF 2 år SVERIGE 08 594 213 30 GROUPE SEB NORDIC SWEDEN 2 years Truckvägen 14 A, 194 52 Upplands Väsby...
  • Page 30 TEFAL/T-FAL INTERNATIONAL GUARANTEE Date of purchase: ....../ Date d'achat / Fecha de compra / Data da compra / Data d'acquisto / Kaufdatum / Aankoopdatum / Købsdato / Inköpsdatum / Kjøpsdato / Ostopäivä...
  • Page 32 p. 1 – 22 NC00131790...
