- Page 1 NVFN Series Flamstop fuel shut-off valves Technical Data Sheet WattsWater.eu...
- Page 2 Watts Water Technologies, Inc. Description NVFN FLAMSTOP 1/2” and 3/4” liquid and gas fuel shut-off valves, suitable for biodiesel. Positive action with manual resetting. Liquid expansion thermostat. Compact sensor. 1/2”M sensor sheath connection (with 1/2”F x 3/4”M nipple). INAIL approved and set. Compliant with Directives PED 2014/68/EU and ATEX 2014/34/EU.
- Page 3 Watts Water Technologies, Inc. Operation When the setpoint temperature is reached, the heat-sensitive element (4) causes the grooved piston supporting the stem with integral disc (2) to move, causing the stem to drop, thus closing the valve. Valve closing is not gradual: the valve snaps shut when the setpoint temperature is reached, so the fuel flow is not throttled.
- Page 4 The descriptions and photographs contained in this product specification sheet are supplied by way of information only and are not binding. Watts Industries reserves the right to carry out any technical and design improvements to its products without prior notice. Warranty: All sales and contracts for sale are expressly conditioned on the buyer’s assent to Watts terms and conditions found on its website at www.wattsindustries.com.
