Series
995/995RPDA
Reduced Pressure Zone Backflow Preventer/
Reduced Pressure Detector Assemblies
Sizes: 3" - 6"
CALIFORNIA PROPOSITION 65 WARNING
WARNING: This product contains chemicals
known to the State of California to cause cancer
and birth defects or other reproductive harm.
(Installer: California law requires that this
warning be given to the consumer.)
• Installation • Service
• Repair Kits • Maintenance
For field testing procedure, send for IS-TK-DL,
IS-TK-9A, IS-TK-99E and IS-TK-99D.
For troubleshooting guide, send for S-TSG.
For other repair kits and service parts, send for
PL-RP-BPD.
For technical assistance, contact your local Watts
representative on back page.
N995/Z995, N995RPDA, Z995RPDA are identical in
construction to the 995/995RPDA Series, except
include short radius elbows between the backflow
preventer flange and the gate valve flange.
IMPORTANT: Inquire with governing authorities for
local installation requirements.
NOTE: For Australia and New Zealand, line strainers
should be installed between the upstream shutoff
valve and the inlet of the backflow preventer.
LIMITED WARRANTY: Watts Regulator Company warrants each prod-
uct against defects in material and workmanship for a period of one year
from the date of original shipment. In the event of such defects within
the warranty period, the Company will, at its option, replace or recondi-
tion the product without charge. This shall constitute the exclusive
remedy for breach of warranty, and the Company shall not be respon-
sible for any incidental or consequential damages, includ
RP/IS-995/995RPDA
