Etel DSC Series Operation & Software Manual page 329

M Alias
M63
ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05
Operation & Software Manual
Direct Drives & Systems
Bit # Comment for monitorings M
Values
<P1>
Position captured on digital input (see K182/K178/
K179). This bit is set when the conditions of the digital
4 2
input allow the capture of the position. It is reset when 1
is written in K182
User bit 0, could be modified by trigger functions or by
256 8
K177
User bit 1, could be modified by trigger functions or by
512 9
K177
User bit 2, could be modified by trigger functions or by
1024 10
K177
User bit 3, could be modified by trigger functions or by
2048 11
K177
User bit 4, could be modified by trigger functions or by
4096 12
K177
User bit 5, could be modified by trigger functions or by
8192 13
K177
User bit 6, could be modified by trigger functions or by
16384 14
K177
User bit 7, could be modified by trigger functions or by
32768 15
K177
TEB status
User word bit 0, could be modified by trigger functions or
1 0
by K177
User word bit 1, could be modified by trigger functions or
2 1
by K177
User word bit 2, could be modified by trigger functions or
4 2
by K177
User word bit 3, could be modified by trigger functions or
8 3
by K177
User word bit 4, could be modified by trigger functions or
16 4
by K177
User word bit 5, could be modified by trigger functions or
32 5
by K177
User word bit 6, could be modified by trigger functions or
64 6
by K177
User word bit 7, could be modified by trigger functions or
128 7
by K177
User word bit 8, could be modified by trigger functions or
256 8
by K177
User word bit 9, could be modified by trigger functions or
512 9
by K177
User word bit 10, could be modified by trigger functions
1024 10
or by K177
User word bit 11, could be modified by trigger functions
2048 11
or by K177
User word bit 12, could be modified by trigger functions
4096 12
or by K177
User word bit 13, could be modified by trigger functions
8192 13
or by K177
User word bit 14, could be modified by trigger functions
16384 14
or by K177
User word bit 15, could be modified by trigger functions
32768 15
or by K177
65536 16 The controller is in power on
and <P1> of the DSCDL
329
Def. Val Min. Val Max. Val
<P1> <P1> <P1>
524288 0 4294967295
Chapter E: Appendixes
