Page 1: Installation Manual
Installation manual VRV IV heat exchanger unit for indoor installation Installation manual RDXYQ5T7V1B* English VRV IV heat exchanger unit for indoor installation RDXYQ8T7V1B... - Page 2 2PW51591-2B...
- Page 3 2PW51591-2B...
-
Page 4: Table Of Contents
Possible options for the compressor unit and heat Latest revisions of the supplied documentation may be available on exchanger unit ............the regional Daikin website or via your dealer. 4 Preparation The original documentation is written in English. All other languages Preparing installation site ............ -
Page 5: Heat Exchanger Unit
3 About the units and options Filter for debris (delivered as accessory) About the units and options ▪ When. Installation is optional. It is recommended in places where a lot of debris or dirt (example: leafs) can go into the suction About the compressor unit and ducting. -
Page 6: Preparing Electrical Wiring
5 Installation Preparing electrical wiring 4.2.1 Safety device requirements NOTICE When using residual current operated circuit breakers, be sure to use a high-speed type 300 mA rated residual operating current. Power supply: Heat exchanger unit The power supply must be protected with the required safety devices, i.e. -
Page 7: Guidelines When Installing The Drain Piping
5 Installation ▪ Grills. Install grills in the suction ducting entrance and the ▪ Slope. Make sure the drain piping slopes down (at least 1/100) to discharge ducting exit to prevent animals and debris from going prevent air from being trapped in the piping. Use hanging bars as into the ducting. -
Page 8: Connecting The Refrigerant Piping
5 Installation Guidelines when installing a drain pump and drain reservoir If you install a drain pump, you must also install a drain reservoir. The drain pump and drain reservoir are to be field supplied. ▪ Drain pump: ▪ Minimum flow rate: 45 l/h ▪... -
Page 9: Guidelines When Connecting The Electrical Wiring
6 Technical data WARNING Shielded cable. Using shielded cable for the transmission wiring is mandatory for 5 HP, and optional for 8 HP. 5 HP 8 HP RKXYQ5 RDXYQ5 RKXYQ8 RDXYQ8 X1M (A1P) F1 F2 F1 F2 a1, a2 Earth (use the screw delivered as accessory) When using shielded cable: ▪... -
Page 10: Wiring Diagram: Heat Exchanger Unit
6 Technical data Wiring diagram: Heat exchanger unit The wiring diagram is delivered with the unit, located at the inside of the switch box cover. Symbols: Main terminal Earth wiring Wire number 15 Field wire Field cable /12.2 Connection ** continues on page 12 column 2 Several wiring possibilities Option Not mounted in switch box... - Page 12 4P408444-1 B 0000000 4P408444-1B 2016.04...
