Installation Manual
KEHJ5A160E
Read these Safety Considerations carefully before installing
the drain pan heater. After completing the installation, check if
the unit operates properly during the start-up operation.
Meaning of DANGER, WARNING and CAUTION
Indicates an imminently hazardous situation which,
DANGER
if not avoided will result in death or serious injury.
Indicates a potentially hazardous situation which,
WARNING
if not avoided will result in death or serious injury.
Indicates a petentialy hazardous situation which, if
CAUTION
not avoided may result in minor or moderate injury.
It may also be used to alert agianst unsafe practices.
The purpose of this heater is to melt snow that blows in
from the outside and to prevent frost growth on the bot-
tome frame of the outdoor unit.
Do not shut off the power supply of the ground fault circuit
interrupter even while this heater is stopped.
Increasing the size of a power supply wiring (leading wire)
is required depending on the model of the indoor unit.
This product cannot be used in combination with a central
drain plug.
At heavy snowfall regions, also install a snow protection
hood or high stand.
Inform users that they should store this installation manual
for future reference.
After completing the installation, make sure that the unit
operates properly during the startup operation.
All phases of the field installation, including, but not limited
to, electrical, piping, and safety, must be done in accor-
dance with manufacturer's instructions and must comply
with national, state, provincial, and local codes.
IOD-7098A
06/2019
IMPORTANT!
Our continuing commitment to quality products may mean a change in specifications without notice.
© 2019
5151 San Felipe St., Suite 500
Only personnel that have been trained to install, adjust, ser-
vice or repair(hereinafter, "service") the equipment specified
in this manual should service the equipment. The manufac-
turer will not be responsible for any injury or property damage
arising from improper service or servide procedures. If you
service this unit, you assume responsibility for any injury or
property damage which may result. In addition, in jurisdic-
tions that require one or more licenses to service the equip-
ment specified in this manual, only licensed personnel should
servise the equipment.
Improper installation, adjustment, servicing or repair of the
equipment specified in this manual, or attempting to install,
adjust, service or repair the equipment specified in this
manual without proper training may result in product damage,
property damage, personal injury or death.
For the transmission wiring and the power supply
wiring, shape the wirings in such a way that service
covers and other structures do not rise up, and
securely install covers and panels. Incomplete
installation of covers and panels may cause electric
shock or fire.
DANGER
Houston, TX77056
www.daikincomfort.com
INSTALLATION INSTRUCTIONS
WARNING
WARNING
Do not touch the heater unit without wearing gloves.
The temperature of the heater unit will become high
when the heater is turned on.
Touching the heater unit with bare hands will result
in burns or injury.
