- Page 1 TJ2PRO LOW PROFILE TROLLEY JACK OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
-
Page 2: Specification
Do not dolly or move the vehicle while it is on the jack. • Lift only on areas as specified by the vehicle manufacturer. • Only attachments and/or adaptors supplied by sgs shall be used. • No alterations to the jack shall be made. •... -
Page 3: Raising A Vehicle
RAISING A VEHICLE 1. Make sure the jack and vehicle are on a hard level surface. 2. Always set the vehicle handbrake and chock the wheels. 3. Consult the vehicle owner’s manual to ascertain the location of jacking points and position the jack beneath the lift point. 4. - Page 4 Visually inspect for oil leaks (only a slight oil seepage is permissible). If a leak is found, take the jack out of service and consult with SGS Engineering. Annually. Check the ram oil level as follows: 1.
-
Page 5: Check The Oil Level
CHECK THE OIL LEVEL 1. Turn the handle clockwise to allow the ram to fully retract. It may be necessary to apply force to the saddle to lower the ram. 2. Remove the inspection plate. 3. With the jack in the level position remove the oil fill plug. The oil should be level with the bottom of the fill hole. -
Page 6: Troubleshooting
SUPPORT SHAFT FLAT PAD 12 RIGHT PLATE BUTTERFLY NUT 8 LEFT PLATE FLAT PAD 16 WASHER 20 NUT 16 NUT 20 HANDLE SOCKET PIN WASHER 14 BACK WHEEL NUT 14 SHAFT DISK TOOLS HANDLE SOCKET PIN SCREW 8X16 WWW.SGS-ENGINEERING.COM PAGE 6... -
Page 7: Replacement Parts Diagram
REPLACEMENT PARTS DIAGRAM PAGE 7... -
Page 8: Warranty
WARRANTY This SGS product is covered by a 24 month warranty from the initial date of purchase. This is a domestic warranty provided directly by SGS Engineering. Please keep a recipt of your pucrchase as this may be required as proof of purchase. - Page 9 SGS Engineering (UK) Ltd West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained MANUFACTURER’S NAME: SGS Engineering (UK) Ltd Hydraulic Trolley Jack TYPE OF EQUIPMENT: TJ2PRO PART NUMBER: APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:...
